Factory Automation & Process Control Solution — YOKOGAWA F3YD32-1A | FA-M3 Series
Where This Product Is Used
The YOKOGAWA F3YD32-1A is a 32-point transistor digital output (DO) module designed for the FA-M3 Range-free Multi-controller platform. It is deployed across a wide range of demanding industrial environments where high-density, reliable discrete output control is essential:
- Automotive Assembly Lines — Controls solenoid valves, conveyor drives, and pneumatic actuators in body-welding and paint-shop automation cells.
- Chemical & Petrochemical Plants — Drives on/off valve actuators and pump starters in DCS-integrated safety loops.
- Food & Beverage Processing — Manages filling machine actuators, labeling heads, and reject gates in hygienic production lines.
- Semiconductor Fab Equipment — Interfaces with wafer-handling robots and vacuum valve controllers requiring fast, noise-immune transistor switching.
- Water & Wastewater Treatment — Operates pump stations, blower controls, and UV-disinfection systems in SCADA-supervised networks.
- Pharmaceutical Manufacturing — Supports GMP-compliant batch control systems with precise, repeatable output switching.
- Pulp & Paper Mills — Controls roll-press drives, steam valve actuators, and web-break detection outputs.
Technical Specifications
| Model | F3YD32-1A |
| Series / Platform | YOKOGAWA FA-M3 Range-free Multi-controller |
| Module Type | Digital Output (DO) — Transistor Sink Type |
| Number of Output Points | 32 points |
| Output Voltage Range | 12–24 V DC |
| Max Load Current per Point | 0.1 A |
| Max Total Load Current | 3.2 A (all points ON) |
| Isolation Method | Photocoupler isolation |
| Response Time (OFF→ON) | ≤ 1 ms |
| Response Time (ON→OFF) | ≤ 1 ms |
| Connector Type | 40-pin connector |
| Module Width | Single slot |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | −25 °C to +70 °C |
| Relative Humidity | 10% to 90% RH (non-condensing) |
| Weight | Approx. 214 g |
| Applicable Standard | IEC 61131-2 |
Why Engineers Specify This Model
- High-Density I/O in a Single Slot — 32 transistor outputs in one module slot minimizes rack space and wiring complexity in compact control panels.
- Fast Transistor Switching — Sub-millisecond response times support high-speed sequencing and motion-coordination tasks that relay-output modules cannot achieve.
- Photocoupler Isolation — Galvanic isolation between the controller bus and field wiring protects the CPU from inductive load spikes and ground loops.
- FA-M3 Ecosystem Compatibility — Hot-swap capable within the FA-M3 rack; integrates natively with YOKOGAWA ToolBox and WideField3 programming environments.
- Proven Field Reliability — YOKOGAWA FA-M3 modules are installed in thousands of process and factory automation sites globally, with documented MTBF exceeding 200,000 hours.
- Sink-Type Output Flexibility — NPN transistor sink configuration is compatible with the majority of industrial sensors, solenoids, and indicator lamps used in Asian and European markets.
Complete System Bill of Materials
To build a functional FA-M3 control system around the F3YD32-1A, engineers typically specify the following companion components:
- CPU Module — F3SP28-3N / F3SP38-6N / F3SP53-4H (application-dependent)
- Power Supply Module — F3PU20-0S (24 V DC input) or F3PU10-0S (100–240 V AC input)
- Base Unit / Rack — F3BU04-0N (4-slot) / F3BU06-0N (6-slot) / F3BU16-0N (16-slot)
- Digital Input Module — F3XD32-1A (32-point DI, transistor source) — paired with F3YD32-1A for full I/O complement
- Analog I/O Module — F3AD04-1N (4-ch AI) / F3DA04-1N (4-ch AO) for process variable loops
- Communication Module — F3LE01-5T (Ethernet) / F3LP02-0N (PROFIBUS-DP) for network integration
- Terminal Block / Connector Cable — Compatible 40-pin flat cable and screw-terminal breakout board
Compliance & Industry Standards
- IEC 61131-2: Programmable Controllers — Equipment Requirements and Tests
- CE Marking (EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU)
- UL Listed (applicable YOKOGAWA FA-M3 platform certifications)
- RoHS 2 Compliant (Directive 2011/65/EU)
- SEMI S2 / S8 compatible for semiconductor equipment integration
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA F3YD32-1A modules exclusively through verified industrial distribution channels. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, pin integrity, and label authenticity
- Firmware / revision-level verification against YOKOGAWA official documentation
- Anti-static packaging with humidity indicator card
- Traceability documentation available on request (batch records, country of origin)
We do not supply grey-market, refurbished, or counterfeit components. All products carry the original YOKOGAWA manufacturer warranty where applicable.
How to Source This Part
The F3YD32-1A is available for immediate inquiry. Lead times vary by regional stock availability. To place an order or request a formal quotation:
- Email: support@konmask.com
- Phone / WhatsApp: +0086 19859288691
- Website: https://Konmask.com
Please include your required quantity, delivery destination, and any project timeline constraints when contacting us. Volume pricing is available for OEM and system-integrator accounts.
Application-Specific FAQ
Q: Can the F3YD32-1A drive 24 V DC solenoid valves directly?
A: Yes. Each output point supports up to 0.1 A at 12–24 V DC, which is sufficient for most standard solenoid valves. For higher-current loads, an interposing relay or solid-state relay (SSR) is recommended.
Q: Is this module compatible with FA-M3 racks from earlier production years?
A: The F3YD32-1A is compatible with all standard FA-M3 base units (F3BU series). Confirm the CPU firmware revision supports the module revision level — consult YOKOGAWA ToolBox compatibility tables.
Q: What is the difference between F3YD32-1A and F3YD32-3A?
A: The -1A suffix denotes the standard transistor sink-type output version. The -3A variant typically offers extended temperature range or enhanced surge protection. Verify your environmental specification before substituting.
Q: Can this module be used in a SIL-rated safety application?
A: The standard F3YD32-1A is not SIL-certified. For functional safety applications, YOKOGAWA offers dedicated safety I/O modules within the ProSafe-RS platform.
Q: How do I configure the output points in WideField3?
A: In WideField3, assign the module slot position in the I/O configuration editor. Output coils are addressed as Y-register bits corresponding to the slot and point number. Refer to YOKOGAWA IM 34M06H11-01E for detailed addressing.
