YOKOGAWA MW100-E-1H Ethernet Communication Module | Replacement, Equivalent & Selection Guide
The YOKOGAWA MW100-E-1H is an Ethernet communication module designed for the MW100 Data Acquisition (DAQ) Station series. It enables high-speed network connectivity for real-time data monitoring, remote configuration, and seamless integration into industrial automation and measurement systems. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make informed decisions.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | MW100-E-1H |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series | MW100 DAQ Station |
| Module Type | Ethernet Communication Module |
| Interface | 10BASE-T / 100BASE-TX (Auto-negotiation) |
| Connector | RJ-45 |
| Protocol Support | Modbus/TCP, FTP, HTTP, SNTP, SMTP |
| Communication Speed | 10/100 Mbps |
| Power Supply | Supplied via MW100 backplane |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (W×H×D) | Conforms to MW100 module form factor |
| Weight | Approx. 200 g |
| Certifications | CE, UL (refer to YOKOGAWA datasheet for latest) |
| Country of Origin | Japan |
Compatible Replacement & Equivalent Models
When the MW100-E-1H is unavailable or discontinued, the following models may serve as functional replacements or equivalents depending on your system configuration:
- YOKOGAWA MW100-E-1H/M — Extended memory variant; direct functional equivalent with additional data storage capacity.
- YOKOGAWA MW100-E-2H — Dual-port Ethernet variant; suitable when redundant network paths are required.
- YOKOGAWA MW100-E-1H/C — Conformal-coated version for harsh environments; same electrical specifications.
- YOKOGAWA MX100 Series Ethernet Modules — Next-generation platform; requires MX100 mainframe; not a drop-in replacement but functionally equivalent for new installations.
- Third-party Modbus/TCP Ethernet Gateways — For legacy system integration where original YOKOGAWA modules are unavailable; protocol compatibility must be verified.
Note: Always verify firmware version, backplane compatibility, and communication protocol support before substituting modules. Contact Konmask.com for pre-sales compatibility verification.
Why Choose the Original MW100-E-1H
- Guaranteed Compatibility: Engineered specifically for the MW100 DAQ Station backplane — no configuration workarounds required.
- Proven Reliability: YOKOGAWA’s industrial-grade design ensures stable 24/7 operation in demanding environments.
- Full Protocol Support: Native support for Modbus/TCP, FTP, HTTP, SNTP, and SMTP without additional gateways.
- Seamless Integration: Works directly with YOKOGAWA DAQSTANDARD and DAQLOGGER software.
- Long-term Support: YOKOGAWA provides firmware updates and technical documentation for the MW100 platform.
- Regulatory Compliance: CE and UL certified for global deployment.
Typical Applications
- Industrial process monitoring and data logging in manufacturing plants
- Environmental monitoring systems (temperature, humidity, pressure)
- Energy management and power quality measurement
- Laboratory and R&D data acquisition systems
- Building automation and HVAC monitoring
- Pharmaceutical and food & beverage production compliance logging
- Remote monitoring via Ethernet/LAN in distributed control systems
System Compatibility
- Mainframe: YOKOGAWA MW100 DAQ Station (all variants)
- Software: DAQSTANDARD, DAQLOGGER, custom SCADA via Modbus/TCP
- Network: Standard 10/100 Ethernet LAN; compatible with industrial managed switches
- I/O Modules: Compatible with all MW100 analog and digital I/O modules (MX110, MX112, MX115, MX120, MX125, etc.)
- Not Compatible With: MW100 RS-232C/RS-422 serial slots (different slot type); MX100 mainframe without adapter
Selection Guide
Use the following criteria to determine whether the MW100-E-1H is the right module for your application:
- ✔ Choose MW100-E-1H if: You have an existing MW100 DAQ Station and require standard single-port Ethernet connectivity with Modbus/TCP support.
- ✔ Choose MW100-E-1H/M if: You need extended onboard data storage in addition to Ethernet communication.
- ✔ Choose MW100-E-2H if: Your application requires dual Ethernet ports for network redundancy or segmentation.
- ✔ Choose MW100-E-1H/C if: Your installation environment involves corrosive gases, high humidity, or extreme dust exposure.
- ✔ Consider MX100 Series if: You are designing a new system and require higher channel density or advanced features — plan for a full platform migration.
Quality Assurance & Sourcing
- Authentic Parts: Konmask.com sources MW100-E-1H modules from authorized distributors and verified industrial surplus channels.
- Inspection: All units undergo visual inspection and functional verification before shipment.
- Warranty: 90-day replacement warranty on all modules sold through Konmask.com.
- Traceability: Batch records and sourcing documentation available upon request for regulated industries.
- Anti-counterfeit: We do not source from unverified grey-market channels. Authenticity guaranteed.
How to Order
- Confirm your MW100 mainframe model and available module slot type.
- Verify required Ethernet protocol (Modbus/TCP, FTP, HTTP, etc.).
- Add MW100-E-1H to cart or contact us for bulk/OEM pricing.
- Provide your shipping address — we ship worldwide with DHL, FedEx, and UPS.
- Receive order confirmation and tracking within 1 business day.
