Yokogawa ADV551-P13-S2 – Smart Transmitter Interface Module | CENTUM VP DCS Platform
Engineering Background
The Yokogawa ADV551-P13-S2 is a field-proven Smart Transmitter Interface (STI) module designed for integration within Yokogawa’s CENTUM VP Distributed Control System architecture. It serves as the critical bridge between intelligent field instruments (BRAIN/HART-compatible transmitters) and the DCS controller, enabling bidirectional digital communication, remote configuration, and real-time diagnostics without interrupting process control loops.
Product Positioning
Targeted at process automation engineers in refining, petrochemical, power generation, and specialty chemical industries, the ADV551-P13-S2 is the preferred choice when upgrading legacy analog I/O infrastructure to smart field device management. Its compact form factor and plug-in compatibility with CENTUM VP field control stations (FCS) make it a drop-in solution for both greenfield projects and brownfield retrofits.
Complete Technical Specifications
| Part Number / SKU | ADV551-P13-S2 |
| Manufacturer | Yokogawa Electric Corporation |
| Series / Platform | CENTUM VP – Versatile Production |
| Module Type | Smart Transmitter Interface (STI) Module |
| Communication Protocol | BRAIN / HART (Highway Addressable Remote Transducer) |
| I/O Configuration | Analog Input with superimposed digital communication |
| Suffix -P13 | Power supply specification variant (24 VDC loop power) |
| Suffix -S2 | Safety/SIL option or special build designation (confirm with datasheet) |
| Mounting | Plug-in card, CENTUM VP FCS node unit |
| Operating Temperature | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature | -20°C to +70°C |
| Power Consumption | Per CENTUM VP node specification |
| Weight | 260 g (approx.) |
| Compliance | CE, RoHS; CENTUM VP system-certified |
| Country of Origin | Japan |
Proven Application Environments
- Oil & Gas Refining: Pressure, temperature, and flow transmitter interfacing in hazardous process areas
- Petrochemical Plants: Multi-loop HART device management across large-scale FCS networks
- Power Generation: Boiler and turbine instrumentation loops requiring remote diagnostics
- Specialty Chemicals: Batch process control with frequent transmitter reconfiguration needs
- Brownfield Upgrades: Replacing legacy analog-only I/O cards while retaining existing field wiring
Engineering Advantages
- Bidirectional HART/BRAIN Communication: Enables remote parameter setting, self-diagnostics, and device identification without loop interruption
- Seamless CENTUM VP Integration: Native plug-in compatibility eliminates custom wiring adapters and reduces commissioning time
- Predictive Maintenance Ready: Continuous device health monitoring feeds directly into Yokogawa’s Plant Resource Manager (PRM) for proactive maintenance scheduling
- Loop Power Supply Integrated (-P13): Eliminates need for separate field power supply units, simplifying panel design
- High Signal Integrity: Designed to reject common-mode noise in industrial environments, ensuring accurate 4–20 mA signal transmission
System Architecture & Signal Flow
The ADV551-P13-S2 resides in the CENTUM VP Field Control Station (FCS) node unit. Field transmitters connect via standard 2-wire 4–20 mA loops. The module simultaneously reads the analog process variable and decodes superimposed HART/BRAIN digital signals. Decoded data is passed to the FCS processor via the internal V-net/IP or ESB bus, and is accessible to the Human Interface Station (HIS) and Plant Resource Manager (PRM) for real-time monitoring and asset management.
Field Transmitter (HART/BRAIN)
│ 4–20 mA + Digital Signal
▼
ADV551-P13-S2 (STI Module)
│ Analog PV + Device Data
▼
CENTUM VP FCS Node
│ V-net/IP / ESB Bus
▼
HIS / PRM / DCS Controller
Sourcing & Quality Verification
- All ADV551-P13-S2 units sourced through authorized Yokogawa distribution channels or verified surplus with full traceability documentation
- Each unit undergoes incoming inspection: visual check, label verification, firmware version confirmation, and functional power-on test where applicable
- Serialization and lot traceability records maintained for every shipment
- Counterfeit-prevention protocol: units with tampered labels, mismatched serial numbers, or non-OEM packaging are rejected and quarantined
- Certificate of Conformance (CoC) available upon request
Procurement Process
- Confirm Part Number: Verify ADV551-P13-S2 against your CENTUM VP system BOM and I/O assignment list
- Request Quote: Contact support@konmask.com or call +0086 19859288691 for volume pricing and lead time
- Order Placement: Purchase directly via this listing or submit a PO for NET terms (qualified accounts)
- Shipping: DHL / FedEx Express international; EXW Xiamen or CIF destination available
- Documentation: Commercial invoice, packing list, CoC, and test report included with every shipment
Technical FAQ
Q: Is the ADV551-P13-S2 compatible with CENTUM CS 3000?
A: The ADV551 series is designed for CENTUM VP. Compatibility with CS 3000 depends on the specific FCS hardware generation — consult your Yokogawa system engineer or contact us for verification.
Q: Can this module communicate with third-party HART devices?
A: Yes. The module supports standard HART protocol (revision 5/6/7), enabling communication with any HART-compliant field device regardless of manufacturer.
Q: What is the difference between -P13 and other power suffix variants?
A: The -P13 suffix designates the loop power supply configuration. Different suffixes correspond to different input voltage ranges or power delivery specifications. Always match the suffix to your system’s field power architecture.
Q: Do you provide warranty on surplus/refurbished units?
A: Yes. Konmask.com provides a 90-day functional warranty on all tested units. New-in-box OEM units carry the original Yokogawa warranty terms.
Q: Can I return a unit if it is incompatible with my system?
A: Yes, within 30 days of receipt, subject to our returns policy. Units must be in original, uninstalled condition.
