Data Acquisition & Process Monitoring Solution — YOKOGAWA MX2*D | MX100 Series I/O Card
Where This Product Is Used
The YOKOGAWA MX2*D is an I/O expansion card designed for integration into the YOKOGAWA MX100 DAQSTATION modular data acquisition system. It is deployed across a wide range of industrial and laboratory environments where high-density, high-accuracy signal measurement is critical:
- Chemical & Petrochemical Plants — continuous process variable monitoring (temperature, pressure, flow) with multi-channel I/O expansion
- Power Generation & Utilities — turbine, boiler, and grid parameter logging with synchronized multi-point acquisition
- Pharmaceutical Manufacturing — GMP-compliant batch data recording and environmental monitoring
- Automotive & Aerospace Test Benches — high-speed transient capture and endurance test data logging
- Steel & Metals Processing — furnace temperature profiling and rolling-mill process analytics
- Water & Wastewater Treatment — SCADA-integrated multi-parameter monitoring with alarm management
- Research & Development Laboratories — precision multi-channel signal acquisition for experimental validation
Technical Specifications
| Manufacturer | YOKOGAWA Electric Corporation |
| Model / Part Number | MX2*D |
| Series | MX100 DAQSTATION Modular Data Acquisition System |
| Module Type | I/O Expansion Card (Existing / Legacy Compatible) |
| Compatible Platform | YOKOGAWA MX100 / DAQSTATION Series |
| Signal Types Supported | Thermocouple, RTD, DC voltage, DC current, pulse (model-dependent) |
| Isolation | Channel-to-channel isolation (model-dependent) |
| Weight | 600 g (approx.) |
| SKU | MX2*D |
| Condition | New / Surplus / Refurbished (specify at inquiry) |
* The asterisk in MX2*D denotes a sub-model suffix. Contact us to confirm the exact variant (e.g., MX2AD, MX2BD, MX2CD) and its channel count, input type, and accuracy class.
Why Engineers Specify This Model
- Proven MX100 Ecosystem Compatibility — drop-in replacement or expansion for existing MX100 installations without system redesign
- High Measurement Accuracy — YOKOGAWA’s precision analog front-end ensures low drift and high repeatability across industrial temperature ranges
- Modular Scalability — the MX100 platform supports multiple I/O cards per mainframe, enabling channel count expansion without additional hardware infrastructure
- Reduced Downtime Risk — sourcing a genuine MX2*D card maintains OEM firmware compatibility and avoids recalibration overhead
- Long Service Life — YOKOGAWA’s industrial-grade components are rated for continuous 24/7 operation in harsh environments
- Regulatory Traceability — supports calibration certificate documentation required in FDA 21 CFR Part 11, ISO 9001, and IEC 61511 environments
Complete System Bill of Materials
For a fully operational MX100 data acquisition node using the MX2*D I/O card, the following components are typically required:
- YOKOGAWA MX100 Mainframe / Base Unit
- MX2*D I/O Expansion Card (this item)
- MX150 or compatible power supply module
- Terminal block / wiring adapter for field signal connection
- DAQSTANDARD or DAQLOGGER software license (for PC-based configuration)
- Ethernet or RS-232C communication cable
- DIN rail mounting hardware (if panel-mounted)
- Calibration certificate (traceable to national standards)
Contact [email protected] for bundled BOM pricing and availability checks.
Compliance & Industry Standards
- CE Marking — compliant with EU EMC and Low Voltage Directives
- UL / cUL Listed — recognized for use in North American industrial installations
- RoHS Compliant — meets EU Directive 2011/65/EU on restriction of hazardous substances
- IEC 61010-1 — safety requirements for electrical equipment for measurement and control
- ISO 9001 — manufactured under YOKOGAWA’s certified quality management system
- FDA 21 CFR Part 11 — data integrity features support electronic records compliance in pharmaceutical applications
Quality Assurance & Sourcing
Konmask.com specializes in the procurement of genuine, traceable industrial automation components. Every MX2*D unit we supply undergoes the following process:
- Origin Verification — sourced from authorized distributors, OEM surplus channels, or certified refurbishers
- Visual & Functional Inspection — checked for physical integrity, connector condition, and firmware label authenticity
- Serialization Check — serial numbers cross-referenced against known counterfeit databases where applicable
- Packaging Integrity — shipped in anti-static packaging with desiccant to prevent moisture damage in transit
- Documentation Package — calibration certificate, datasheet, and test report available upon request
How to Source This Part
- Confirm your exact sub-model — share your MX100 mainframe model number and current I/O card configuration so we can verify compatibility
- Request a quote — email [email protected] or call +0086 19859288691 with your required quantity and delivery timeline
- Receive availability & lead time — we confirm stock status, condition (new/surplus/refurbished), and estimated ship date within 1 business day
- Place order & receive documentation — order confirmation, proforma invoice, and shipping tracking provided at each stage
- After-sales support — our technical team is available for installation guidance and compatibility troubleshooting
Application-Specific FAQ
Q: Is the MX2*D compatible with all MX100 mainframe versions?
A: The MX2*D series is designed for the MX100 platform. Compatibility depends on the specific sub-model suffix and mainframe firmware version. Please share your mainframe model number for confirmation.
Q: Can I mix MX2*D cards with other MX100 I/O card types in the same mainframe?
A: Yes. The MX100 modular architecture supports mixed I/O card configurations within a single mainframe, subject to slot and channel count limits defined in the MX100 hardware manual.
Q: Do you supply calibration certificates with the MX2*D?
A: Calibration certificates traceable to national standards are available upon request. Please specify this requirement at the time of inquiry.
Q: What is the typical lead time for the MX2*D?
A: Lead time varies by stock availability. In-stock units typically ship within 3–5 business days. For out-of-stock items, lead time is 2–6 weeks depending on sourcing channel.
Q: Can Konmask.com assist with MX100 system integration or configuration?
A: Yes. Our technical team can provide guidance on I/O card slot assignment, DAQSTANDARD software configuration, and field wiring recommendations for common application types.
Q: Is this product available for international shipment?
A: Yes. We ship globally. Import duties, taxes, and customs documentation are the buyer’s responsibility unless otherwise agreed. Contact us for freight options and Incoterms.
