YOKOGAWA 16418-541/1 PSCCM24AAN – Power Supply & Critical Control Module | CENTUM VP / CS 3000
Engineering Background
The YOKOGAWA CENTUM VP and CS 3000 platforms represent the gold standard in distributed control system (DCS) architecture for process-critical industries including oil & gas, petrochemical, power generation, and pharmaceutical manufacturing. Within these platforms, the power supply and critical control module (PSCCM) series serves as the backbone of field controller cabinet power integrity — ensuring uninterrupted 24 VDC regulated output to all downstream I/O and processor modules.
Product Positioning
The 16418-541/1 PSCCM24AAN is a factory-configured power supply critical control module designed for direct integration into YOKOGAWA FCS (Field Control Station) cabinets. It is engineered for procurement engineers and system integrators who require a verified, drop-in replacement or expansion unit with full compatibility assurance for live production environments.
Complete Technical Specifications
- Part Number: 16418-541/1
- Model Code: PSCCM24AAN
- Manufacturer: YOKOGAWA Electric Corporation
- Compatible Platforms: CENTUM VP, CENTUM CS 3000
- Module Function: Power Supply & Critical Control Module
- Output Voltage: 24 VDC (regulated)
- Form Factor: DIN-rail / cabinet-mount module
- Weight: 1,960 g (as shipped)
-
Suffix Code Breakdown:
- PSC = Power Supply Critical
- CM = Control Module
- 24 = 24 VDC output
- A = Standard revision
- AN = No redundancy option (single unit)
- Compliance: Designed to YOKOGAWA factory QA standards; CE-compatible platform
- Condition: Surplus / refurbished — tested and verified prior to shipment
Proven Application Environments
- Oil & Gas upstream/downstream FCS cabinet power supply replacement
- Petrochemical plant DCS expansion projects requiring additional 24 VDC rail capacity
- Power generation control room CENTUM VP system maintenance
- Pharmaceutical batch control systems with CENTUM CS 3000 architecture
- Pulp & paper and water treatment facilities running legacy YOKOGAWA DCS
- Emergency spare parts inventory for critical process control infrastructure
Engineering Advantages
- Direct OEM Compatibility: Factory part number ensures zero integration risk with existing CENTUM VP / CS 3000 cabinets
- Regulated 24 VDC Output: Stable power delivery protects downstream I/O modules from voltage transients
- Compact Module Design: Optimized for high-density FCS cabinet layouts without additional mounting hardware
- Proven Field Reliability: PSCCM series modules have documented multi-year MTBF in continuous process environments
- Immediate Availability: Surplus stock held at Konmask warehouse — no lead time dependency on OEM production schedules
- Pre-shipment Verification: Each unit undergoes functional inspection and packaging audit before dispatch
System Architecture & Signal Flow
Within the CENTUM VP FCS cabinet, the PSCCM24AAN receives AC mains input (via the cabinet power distribution unit) and converts it to a regulated 24 VDC bus. This bus feeds:
- Field Control Unit (FCU) processor cards
- Analog and digital I/O modules (ALF111, AAI141, ADV151, etc.)
- Communication interface modules (ESB bus, ER bus)
- Redundant module pairs where applicable
The PSCCM module integrates with the cabinet’s power monitoring logic, providing status signals to the system’s self-diagnostic layer for predictive maintenance alerting.
Sourcing & Quality Verification
- Origin: Decommissioned from operational CENTUM VP installations — not counterfeit or grey-market
- Inspection Protocol: Visual inspection (housing, connectors, label integrity) + functional power-on test
- Packaging: Anti-static bag + foam-lined export carton with desiccant
- Documentation: Certificate of conformity available upon request; original YOKOGAWA labeling intact
- Traceability: Batch records maintained for 24 months post-shipment
Procurement Process
- Submit RFQ — Email support@konmask.com with quantity, delivery address, and required lead time
- Receive Quotation — Formal quotation issued within 1 business day including unit price, shipping cost, and ETA
- Order Confirmation — Purchase order accepted via email; proforma invoice issued for payment
- Payment & Dispatch — Payment via T/T bank transfer or agreed terms; dispatch within 2–5 business days
- Shipping & Tracking — DHL / FedEx / SF Express with full tracking; export documentation (commercial invoice, packing list, COO) included
- After-Sales Support — 90-day warranty on verified units; technical support available via email or phone
Technical FAQ
Q: Is the 16418-541/1 PSCCM24AAN compatible with both CENTUM VP and CS 3000?
A: Yes. The PSCCM24AAN module is cross-compatible with both CENTUM VP R4/R5/R6 and CENTUM CS 3000 R3 FCS cabinet configurations. Verify your cabinet revision with YOKOGAWA documentation before installation.
Q: Can this module operate in a redundant power supply configuration?
A: The suffix “AN” denotes a non-redundant (single) unit. For redundant configurations, two PSCCM24AAN units are installed in parallel with a load-sharing diode assembly — consult your CENTUM VP hardware manual (IM 33J01B10-01E) for wiring details.
Q: What is the typical lead time for this part?
A: Konmask maintains surplus stock. Standard dispatch is 2–5 business days after payment confirmation. Express dispatch (next business day) available upon request.
Q: Do you provide a test report or certificate of conformity?
A: Yes. A functional test report and certificate of conformity are available upon request at no additional charge.
Q: What warranty terms apply?
A: All verified surplus units carry a 90-day warranty covering functional defects. Units must be returned in original packaging with fault description for warranty assessment.
