Process Automation & Safety Monitoring Solution — YOKOGAWA NFDV151-P10 | STARDOM FCN/FCJ Series
Where This Product Is Used
The YOKOGAWA NFDV151-P10 is a 16-channel isolated digital input module engineered for the STARDOM FCN/FCJ Distributed Control System (DCS). It is deployed across demanding industrial environments where reliable discrete signal acquisition is critical:
- Oil & Gas Facilities — Wellhead monitoring, pipeline valve position feedback, emergency shutdown (ESD) signal collection
- Chemical & Petrochemical Plants — Reactor interlock status, pump run/stop feedback, level switch inputs
- Power Generation — Turbine protection logic, breaker status monitoring, generator control panels
- Water & Wastewater Treatment — Pump station automation, flow switch monitoring, alarm aggregation
- Pharmaceutical Manufacturing — Clean-room equipment status, batch process interlocks, GMP-compliant signal isolation
- Pulp & Paper / Food & Beverage — Conveyor status, agitator run feedback, safety gate monitoring
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | NFDV151-P10 |
| Series | STARDOM FCN/FCJ |
| Manufacturer | YOKOGAWA Electric Corporation |
| Module Type | Digital Input (DI) |
| Number of Channels | 16 channels |
| Input Voltage | 24 VDC (nominal) |
| Isolation | Channel-to-channel & channel-to-bus isolation |
| Input Signal | Dry contact / wet contact (configurable) |
| Communication Bus | STARDOM FCN/FCJ internal I/O bus |
| Mounting | DIN rail / FCN/FCJ base unit slot |
| Operating Temperature | 0°C to 55°C |
| Weight | Approx. 100 g |
| Compliance | CE, UL, IEC 61131-2 |
Why Engineers Specify This Model
- True Channel Isolation — Eliminates ground loops and protects the controller backplane from field-side transients, critical in high-noise industrial environments.
- Plug-and-Play STARDOM Integration — Recognized natively by FCN/FCJ CPUs; no additional configuration drivers required, reducing commissioning time.
- High Channel Density — 16 DI points per slot maximizes cabinet space utilization and lowers per-point installed cost.
- Proven YOKOGAWA Reliability — MTBF-rated for continuous 24/7 operation in process-critical applications with YOKOGAWA’s global service network backing.
- Backward Compatibility — Compatible with existing STARDOM FCN/FCJ infrastructure, enabling incremental system expansion without full platform migration.
Complete System Bill of Materials
For a complete STARDOM FCN/FCJ digital input subsystem, engineers typically specify:
- NFDV151-P10 — Digital Input Module (this item)
- FCN-500 / FCJ CPU Unit — STARDOM controller base
- NFBU05S / NFBU10S — I/O Base Unit (5-slot or 10-slot)
- NFPS05 — Power Supply Module
- NFET100 — Ethernet Communication Module (for SCADA integration)
- Terminal blocks & field wiring accessories (customer-supplied)
Compliance & Industry Standards
- IEC 61131-2 — Programmable Controllers: Equipment Requirements & Tests
- CE Marking — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- UL Listed — Industrial Control Equipment
- RoHS Compliant — Restriction of Hazardous Substances
- ATEX / IECEx — Consult factory for hazardous area variants
Quality Assurance & Sourcing
All YOKOGAWA modules supplied by Konmask.com are:
- Sourced from authorized distributors or verified surplus channels with full traceability documentation
- Inspected for physical integrity, label authenticity, and firmware version prior to dispatch
- Shipped with anti-static packaging and humidity indicator cards
- Backed by our 30-day return policy and post-sale technical support
How to Source This Part
Ready to order the YOKOGAWA NFDV151-P10? Here’s how to proceed:
- Add to Cart — Immediate checkout for in-stock units
- Request a Quote — For bulk orders (>5 units) or project-based procurement, contact us for volume pricing
- Lead Time — Typically ships within 3–7 business days; expedited options available
- Export & Customs — We handle export documentation for international shipments (CN, US, EU, SEA)
📧 support@konmask.com | 📞 +0086 19859288691
Application-Specific FAQ
Q: Is the NFDV151-P10 compatible with STARDOM FCN-100 as well as FCN-500?
A: The NFDV151-P10 is designed for the STARDOM FCN/FCJ platform. Compatibility with specific CPU generations (FCN-100 vs FCN-500) should be verified against the YOKOGAWA STARDOM I/O compatibility matrix or confirmed with our technical team before ordering.
Q: Can this module accept 120VAC field signals?
A: No. The NFDV151-P10 is rated for 24VDC input signals. For 120VAC or 240VAC field inputs, an interposing relay or signal conditioner is required.
Q: What is the scan time for 16 DI channels?
A: Scan time is determined by the FCN/FCJ CPU task configuration. The module itself introduces negligible latency; refer to the FCN/FCJ CPU datasheet for task cycle specifications.
Q: Do you supply the module with a warranty?
A: Yes. We offer a 30-day inspection and return guarantee. For extended warranty coverage, please contact our sales team.
Q: Can I use this module in a SIL-rated safety loop?
A: The standard NFDV151-P10 is not SIL-certified. For functional safety applications, YOKOGAWA’s ProSafe-RS safety system should be specified instead.
