Critical Process Control Solution — YOKOGAWA PSCCM22AAN | CENTUM CS/VP Series
Where This Product Is Used
The YOKOGAWA PSCCM22AAN is a Critical Control Module (CCM) designed for deployment in the CENTUM CS and CENTUM VP Distributed Control System (DCS) platforms. It serves as the central processing unit within Field Control Stations (FCS), executing real-time control logic, managing I/O communication, and maintaining process continuity in mission-critical environments.
Typical deployment sites include:
- Oil & Gas Upstream/Downstream: Wellhead control, separator automation, refinery distillation column regulation
- Petrochemical & Chemical Plants: Reactor temperature/pressure loop control, batch process sequencing
- Power Generation: Boiler combustion control, turbine governor interfacing, load dispatch automation
- Pulp & Paper / Pharmaceuticals: Continuous process control requiring high-availability CPU redundancy
- Water & Wastewater Treatment: Multi-loop PID control for dosing, filtration, and flow management
Technical Specifications
| Part Number | PSCCM22AAN |
| Manufacturer | YOKOGAWA Electric Corporation |
| Series | CENTUM CS / CENTUM VP DCS |
| Module Type | Critical Control Module (CCM) |
| Function | Real-time process control CPU for Field Control Station (FCS) |
| Redundancy Support | Dual-redundant CPU configuration (Primary + Secondary) |
| Communication | V-net / Vnet/IP control bus interface |
| Control Execution | Continuous, batch, and sequence control |
| I/O Capacity | Up to 2,048 I/O points per FCS (system-dependent) |
| Operating Temperature | 0°C to 55°C |
| Power Supply | 24 VDC (via FCS backplane) |
| Weight | 1,960 g |
| Mounting | FCS node unit rack (CENTUM CS/VP compatible) |
| Firmware | Compatible with CENTUM VP R5.x / R6.x engineering environment |
Why Engineers Specify This Model
- Proven Redundancy Architecture: The PSCCM22AAN supports hot-standby dual-CPU redundancy, enabling bumpless switchover in under 1 second — critical for processes where downtime costs exceed tens of thousands of dollars per hour.
- Seamless CENTUM Ecosystem Integration: Plug-compatible with existing CENTUM CS and VP FCS racks, eliminating costly re-engineering when replacing aging CCM modules.
- High-Throughput Control Execution: Handles complex multi-loop PID, cascade, ratio, and feedforward control schemes within a single module, reducing rack footprint.
- Long-Term Supportability: YOKOGAWA’s extended lifecycle support policy ensures spare parts availability and firmware compatibility for 10+ year plant lifecycles.
- Deterministic Scan Cycle: Fixed-cycle execution guarantees predictable control response — essential for safety-instrumented and regulatory-compliance applications.
Complete System Bill of Materials
For a fully operational CENTUM VP Field Control Station using the PSCCM22AAN, engineers typically specify the following complementary components:
- PSCCM22AAN — Critical Control Module (this item, qty ×2 for redundancy)
- PFCS-xxx — FCS Node Unit Chassis / Rack
- PSCPU-xxx — CPU Bus Coupler (if applicable)
- PSIO-xxx / AAI-xxx / ADV-xxx — Analog/Digital I/O modules
- PSPWD-xxx — FCS Power Supply Module (redundant pair recommended)
- PVNET-xxx — Vnet/IP Communication Interface Card
- CENTUM VP Engineering Workstation (EWS) — For configuration and commissioning
- HIS (Human Interface Station) — Operator console for runtime monitoring
Contact support@konmask.com for complete BOM quotation and cross-reference assistance.
Compliance & Industry Standards
- CE Marking — Compliant with EU Machinery and EMC Directives
- UL / cUL Listed — North American safety certification
- IEC 61511 / IEC 61508 — Functional safety compatibility (SIL-rated configurations available)
- ATEX / IECEx — Hazardous area compatibility via certified I/O modules
- ISA-5.1 / ISA-88 — Batch and continuous control standard compliance
- RoHS Compliant — Restriction of Hazardous Substances
Quality Assurance & Sourcing
Konmask.com sources YOKOGAWA modules through verified industrial supply channels. Every PSCCM22AAN unit offered is:
- Inspected for physical integrity and label authenticity upon receipt
- Stored in ESD-safe, climate-controlled warehousing
- Traceable to original manufacturer documentation where available
- Shipped with anti-static packaging and shock-absorbing materials
- Backed by our 30-day return policy for DOA (Dead on Arrival) units
We specialize in hard-to-find, obsolete, and long-lead-time YOKOGAWA DCS components for MRO (Maintenance, Repair & Operations) procurement teams.
How to Source This Part
- Add to Cart — Proceed directly if quantity and lead time meet your requirements.
- Request a Quote — For bulk orders (3+ units), OEM pricing, or project-based procurement, email support@konmask.com with your PO number and delivery schedule.
- Cross-Reference Check — If you are unsure whether PSCCM22AAN is the correct replacement for your existing CCM, provide your current part number and FCS firmware version for compatibility verification.
- Expedited Shipping — DHL Express, FedEx International Priority, and sea freight options available. Contact us for freight quotes to your destination port.
- Export Compliance — We handle export documentation (commercial invoice, packing list, COO) for international shipments. HS Code: 8537.10 (indicative).
Application-Specific FAQ
Q: Is the PSCCM22AAN compatible with both CENTUM CS and CENTUM VP systems?
A: Yes. The PSCCM22AAN is designed for use across the CENTUM CS and CENTUM VP FCS platforms. Always verify your FCS firmware version and rack type before installation to confirm slot compatibility.
Q: Can I use a single PSCCM22AAN without redundancy?
A: Yes, simplex (non-redundant) operation is supported. However, for SIL-rated or continuous-process applications, dual-redundant CCM configuration is strongly recommended per IEC 61511 guidelines.
Q: What is the typical lead time for this module?
A: In-stock units ship within 1–3 business days. For out-of-stock scenarios, lead time is typically 4–12 weeks depending on global supply. Contact us for real-time availability.
Q: Do you provide a warranty?
A: We offer a 30-day DOA guarantee. For extended warranty coverage or on-site commissioning support, please inquire via email.
Q: Can Konmask assist with CENTUM VP system migration or upgrade projects?
A: Yes. Our technical team can assist with BOM compilation, cross-referencing legacy CENTUM CS modules to VP equivalents, and sourcing complete FCS node assemblies. Reach out with your project scope.
