Allen-Bradley 1746-NI4/B High Resolution Analog Input Module | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1746-NI4/B is a high-resolution analog input module designed for the SLC 500 programmable controller platform. It provides four differential analog input channels with 16-bit resolution, enabling precise measurement of voltage and current signals in demanding industrial environments. This page serves as a comprehensive selection, replacement, and compatibility reference for engineers and procurement teams.
Technical Specifications
- Part Number: 1746-NI4/B
- Series / Revision: B
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Platform: SLC 500
- Number of Input Channels: 4 differential analog inputs
- Resolution: 16-bit (high resolution)
- Input Signal Types: ±10 V DC, 0–10 V DC, 0–5 V DC, 1–5 V DC, 0–20 mA, 4–20 mA
- Input Impedance (Voltage): ≥ 10 MΩ
- Input Impedance (Current): 249 Ω
- Conversion Time: Approximately 5 ms per channel
- Isolation: 250 V AC channel-to-channel and channel-to-backplane
- Backplane Current Draw: 150 mA @ 5 V DC; 75 mA @ 24 V DC
- Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F)
- Storage Temperature: −40 °C to 85 °C
- Relative Humidity: 5–95% non-condensing
- Dimensions (H × W × D): 111 mm × 40 mm × 87 mm (approx.)
- Weight: Approx. 300 g
- Certifications: UL, CE, CSA
Compatible Replacement & Equivalent Models
When the 1746-NI4/B is unavailable or end-of-life, the following models are commonly evaluated as replacements. Always verify electrical and software compatibility before substitution.
- 1746-NI4 (Series A) — Earlier revision; functionally equivalent but verify firmware compatibility with your SLC 5/xx processor.
- 1746-NI8 — 8-channel version; drop-in upgrade when additional I/O density is required; same signal types and resolution.
- 1746-NI16I — 16-channel current-only input module; suitable when all channels use 4–20 mA signals.
- 1746-NI16V — 16-channel voltage-only input module; suitable for high-density voltage measurement applications.
- 1756-IF4 (ControlLogix) — Cross-platform migration option when upgrading from SLC 500 to ControlLogix; requires platform migration planning.
- 1769-IF4 (CompactLogix) — Compact platform equivalent; suitable for system modernization projects.
- Third-party equivalents — Modules from Spectrum Controls, ProSoft Technology, and other SLC 500-compatible vendors may offer pin-compatible replacements. Contact us for verified alternatives.
Why Choose the Original Model
- Proven field reliability — Deployed in thousands of SLC 500 installations across process, manufacturing, and utilities sectors.
- Native RSLogix 500 integration — Full support for ladder logic configuration, online monitoring, and diagnostics without additional drivers.
- 16-bit resolution — Superior measurement accuracy compared to standard 12-bit or 14-bit alternatives, critical for PID loops and precision control.
- Differential inputs — Excellent common-mode noise rejection, essential in electrically noisy industrial environments.
- Broad signal range — Supports both voltage and current inputs on the same module, reducing spare-parts inventory.
- Long service history — Extensive documentation, community knowledge, and replacement parts availability.
Typical Applications
- Temperature monitoring via 4–20 mA transmitters (pressure, flow, level)
- Analog feedback for PID control loops in process industries
- Tension and load cell signal acquisition in material handling
- Speed reference and feedback in variable-frequency drive (VFD) systems
- Batch process control in food & beverage, chemical, and pharmaceutical plants
- Water and wastewater treatment plant instrumentation
- HVAC control systems with analog sensors
System Compatibility
- Compatible Racks: 1746-A4, 1746-A7, 1746-A10, 1746-A13 (all SLC 500 chassis)
- Compatible Processors: SLC 5/01, 5/02, 5/03, 5/04, 5/05
- Programming Software: RSLogix 500 (v5.0 and above recommended)
- Communication: Backplane only — no standalone Ethernet or serial port
- Power Supply: Powered via SLC 500 backplane; no external 24 V DC required for module logic
Selection Guide
Use the following criteria to determine whether the 1746-NI4/B is the right module for your application:
- Channel count needed ≤ 4? → 1746-NI4/B is optimal. For 5–8 channels, consider 1746-NI8.
- Mixed voltage and current signals? → 1746-NI4/B supports both on the same module. Dedicated current (1746-NI16I) or voltage (1746-NI16V) modules are more cost-effective for single-type applications.
- High accuracy required (e.g., PID, weighing)? → 16-bit resolution of the NI4/B is preferred over standard 12-bit modules.
- Existing SLC 500 system? → Direct slot replacement; no hardware or software migration required.
- Planning a platform upgrade? → Consider 1769-IF4 (CompactLogix) or 1756-IF4 (ControlLogix) with a full migration plan.
- Budget-constrained replacement? → Refurbished or surplus 1746-NI4/B units are widely available; contact us for tested stock.
Quality Assurance & Sourcing
- All units sourced through authorized distributors or verified surplus channels.
- New, refurbished, and tested-used stock available — condition clearly stated on each listing.
- Functional testing performed prior to shipment: power-on, channel verification, and backplane communication check.
- Original Rockwell Automation firmware; no third-party modifications.
- Packaging: anti-static bag, foam-lined box, with inspection report on request.
- Warranty: 12 months on new units; 90 days on refurbished units (terms apply).
How to Order
- Step 1: Confirm your SLC 500 chassis model and available slot count.
- Step 2: Verify your signal types (voltage / current) and channel requirements.
- Step 3: Select stock condition: New / Refurbished / Tested-Used.
- Step 4: Add to cart or contact us for bulk pricing and lead time.
- Step 5: Provide your shipping address — we support worldwide export with proper documentation.
📧 Email: support@konmask.com
📞 Phone / WhatsApp: +0086 19859288691
🌐 Website: https://Konmask.com
Replacement & Compatibility FAQ
Q: Is the 1746-NI4/B still in production?
A: Rockwell Automation has transitioned this product to limited availability. New stock may be available through authorized distributors; surplus and refurbished units are widely available.
Q: Can I replace a Series A (1746-NI4) with a Series B (1746-NI4/B)?
A: Yes, in most cases. Series B introduced minor hardware revisions. Verify with your RSLogix 500 project file that the module definition matches.
Q: Will the 1746-NI4/B work in any slot of the SLC 500 chassis?
A: Yes, it can be installed in any I/O slot. Slot 0 is reserved for the processor; all other slots are compatible.
Q: Can I use this module with a MicroLogix controller?
A: No. The 1746-NI4/B is designed exclusively for the SLC 500 backplane and is not compatible with MicroLogix systems.
Q: What is the difference between 1746-NI4/B and 1746-NI8?
A: The NI8 provides 8 input channels versus 4 on the NI4/B. Both share the same resolution and signal types. The NI8 occupies the same single slot width.
Q: Do you provide a certificate of conformance or test report?
A: Yes, available on request for new and refurbished units. Contact support@konmask.com.
