Allen-Bradley 1747-AENTR SLC 500 Ethernet/IP Adapter | Replacement, Equivalent & Selection Guide
The Allen-Bradley 1747-AENTR is a dedicated Ethernet/IP adapter module for the SLC 500 chassis, enabling seamless integration of legacy SLC 500 systems into modern EtherNet/IP networks. Whether you are maintaining an existing installation, sourcing a direct replacement, or evaluating compatible alternatives, this guide provides the technical depth and selection criteria you need.
Technical Specifications
| Part Number | 1747-AENTR |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Series | SLC 500 |
| Function | EtherNet/IP Remote I/O Adapter |
| Communication Protocol | EtherNet/IP (CIP) |
| Network Speed | 10/100 Mbps, Auto-negotiate |
| Connector | RJ-45 (2 ports, embedded switch) |
| Backplane Current Draw | 250 mA @ 5 VDC |
| Power Supply | Supplied via SLC 500 backplane |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | Occupies 1 slot in SLC 500 chassis |
| Certifications | UL, CE, cUL |
| Firmware | Upgradeable via RSLogix 500 / Studio 5000 |
Compatible Replacement & Equivalent Models
When the 1747-AENTR is unavailable or end-of-life, the following models are commonly evaluated as replacements or functional equivalents. Always verify compatibility with your specific SLC 500 chassis revision and firmware version before substitution.
| Model | Manufacturer | Protocol | Notes |
|---|---|---|---|
| 1747-AENTR (this unit) | Allen-Bradley | EtherNet/IP | Original OEM — direct fit |
| 1747-AENTR/B | Allen-Bradley | EtherNet/IP | Revised firmware version; backward compatible |
| 1747-AENTR/A | Allen-Bradley | EtherNet/IP | Earlier revision; check firmware compatibility |
| 1747-SN | Allen-Bradley | Remote I/O | Legacy RIO adapter; not EtherNet/IP — protocol migration required |
| ProSoft MVI56E-MNET | ProSoft Technology | Modbus TCP / EtherNet/IP gateway | Third-party gateway option for protocol bridging |
| Anybus X-gateway AB7007 | HMS Networks | EtherNet/IP ↔ PROFIBUS | For cross-protocol migration projects |
Note: Third-party equivalents may require additional configuration. Konmask recommends OEM replacements for safety-critical applications.
Why Choose the Original Model
- Guaranteed backplane compatibility — designed specifically for SLC 500 chassis slots with no mechanical or electrical adaptation required.
- Native RSLogix 500 / Studio 5000 support — plug-and-play configuration with Rockwell Automation software toolchain.
- Embedded dual-port switch — enables linear and Device Level Ring (DLR) topologies without additional hardware.
- Proven field reliability — widely deployed in automotive, food & beverage, and discrete manufacturing environments.
- Rockwell Automation lifecycle support — firmware updates and technical documentation available through RA support portal.
Typical Applications
- Retrofitting legacy SLC 500 systems onto modern EtherNet/IP plant networks
- Remote I/O expansion for distributed SLC 500 chassis in large-scale manufacturing lines
- Integration with ControlLogix or CompactLogix controllers via EtherNet/IP messaging
- SCADA and HMI connectivity (FactoryTalk View, Ignition, WonderWare)
- Automotive body-shop and paint-line automation
- Food & beverage packaging and conveyor control
- Water/wastewater treatment remote monitoring
System Compatibility
- Chassis: SLC 500 modular chassis (1746-A4, 1746-A7, 1746-A10, 1746-A13)
- Power Supplies: All standard SLC 500 power supply modules
- Controllers: SLC 5/03, 5/04, 5/05 (with appropriate firmware)
- Software: RSLogix 500 v8.0+, RSLinx Classic, Studio 5000 (for MSG instructions)
- Network Topology: Star, linear, and DLR (Device Level Ring)
- Scanner Compatibility: ControlLogix 1756-EN2T/EN3TR, CompactLogix 1769-L3x series
Selection Guide
Use the following criteria to determine whether the 1747-AENTR is the right module for your application:
| Requirement | Recommended Choice |
|---|---|
| Direct OEM replacement for existing 1747-AENTR | ✅ 1747-AENTR (same or higher revision) |
| Need EtherNet/IP on SLC 500 chassis | ✅ 1747-AENTR |
| Migrating from Remote I/O (RIO) to EtherNet/IP | ✅ 1747-AENTR (replaces 1747-SN) |
| Bridging SLC 500 to PROFIBUS or DeviceNet | ⚠️ Consider ProSoft or Anybus gateway |
| Full system migration away from SLC 500 | ⚠️ Evaluate CompactLogix 5380 platform |
| Budget-constrained retrofit with protocol flexibility | ⚠️ Third-party gateway — consult Konmask engineering |
Quality Assurance & Sourcing
- Authenticity: All units sourced through authorized distribution channels or verified surplus with full traceability documentation.
- Inspection: Each module undergoes visual inspection, label verification, and functional power-on testing prior to shipment.
- Warranty: 90-day replacement warranty on all stocked units; extended warranty available on request.
- Condition: New, refurbished, and tested-used grades available — specify your requirement at inquiry.
- Lead Time: In-stock units ship within 1–3 business days; sourced units typically 5–15 business days.
How to Order
- Add the 1747-AENTR to your cart and proceed to checkout, or
- Contact us directly for volume pricing, urgent requirements, or custom sourcing:
📧 support@konmask.com
📞 +0086 19859288691 - Provide your chassis model, current firmware version, and required quantity for fastest response.
- Request a proforma invoice or technical datasheet at any time — no obligation.
Replacement & Compatibility FAQ
Q: Is the 1747-AENTR/B a direct drop-in replacement for the 1747-AENTR/A?
A: Yes, in most cases. The /B revision includes firmware improvements and is backward compatible with /A installations. Verify your RSLogix 500 version supports the /B revision EDS file.
Q: Can I use the 1747-AENTR with a SLC 5/03 processor?
A: The 1747-AENTR is primarily designed for SLC 5/05 processors with native Ethernet capability. For SLC 5/03 and 5/04, the adapter functions as a remote I/O chassis adapter — confirm your network architecture with Rockwell Automation documentation.
Q: What is the difference between 1747-AENTR and 1747-AENT?
A: The 1747-AENTR features an embedded dual-port switch enabling ring topology (DLR), while the 1747-AENT has a single RJ-45 port. The AENTR is the preferred choice for new installations requiring network redundancy.
Q: Can I connect this module to a ControlLogix system?
A: Yes. The 1747-AENTR allows a ControlLogix controller to communicate with SLC 500 I/O via EtherNet/IP MSG instructions, enabling hybrid architectures during phased migration projects.
Q: Do you provide a certificate of conformance or test report?
A: Yes. Documentation packages including CoC, inspection reports, and where available, original manufacturer test data, can be provided upon request.
