CNC Machine Tool & Servo Motion Solution — Allen-Bradley 2098-DSD-HV030-SE | Ultra 3000 SERCOS Series
Where This Product Is Used
The Allen-Bradley 2098-DSD-HV030-SE is a high-voltage SERCOS-interface servo drive engineered for precision motion control in demanding industrial environments. Typical deployment scenarios include:
- CNC Machine Tools — Multi-axis milling, turning, and grinding centers requiring tight synchronization via SERCOS fiber-optic ring.
- Packaging Machinery — High-speed pick-and-place, form-fill-seal, and cartoning lines where deterministic motion timing is critical.
- Printing & Converting Equipment — Web-tension control and register correction on offset, flexo, and digital presses.
- Semiconductor & Electronics Assembly — Wafer handling, PCB drilling, and SMT placement requiring sub-micron repeatability.
- Robotics & Gantry Systems — Coordinated multi-axis Cartesian and SCARA robots integrated with Logix motion controllers.
- Test & Measurement Rigs — Dynamic load simulation and material-testing machines demanding precise torque and velocity profiles.
Technical Specifications
| Catalog Number | 2098-DSD-HV030-SE |
| Brand / OEM | Allen-Bradley (Rockwell Automation) |
| Series | Ultra 3000 Digital Servo Drive |
| Drive Type | Digital AC Servo Drive with SERCOS Interface |
| Continuous Output Current | 30 A RMS |
| Peak Output Current | 60 A RMS (2× continuous) |
| Input Voltage | High Voltage (HV) — 230/460 V AC, 3-Phase, 50/60 Hz |
| Communication Interface | SERCOS I/II Fiber-Optic Ring (SE suffix) |
| Feedback Supported | Incremental Encoder, Absolute Encoder (Stegmann Hi-Res), Resolver |
| Control Modes | Position, Velocity, Torque (via SERCOS IDN commands) |
| Compatible Controllers | ControlLogix, CompactLogix, SoftLogix (with SERCOS motion module) |
| Enclosure Rating | IP20 (panel-mount) |
| Operating Temperature | 0 °C to +45 °C (derating above 40 °C) |
| Weight | 8.6 kg |
| Part Number / SKU | 2098-DSD-HV030-SE |
Why Engineers Specify This Model
- SERCOS Determinism — Fiber-optic SERCOS ring eliminates EMI-induced jitter, delivering ≤1 µs cycle-time synchronization across all axes — mandatory for CNC interpolation.
- High-Voltage Architecture — HV input (460 V AC) reduces bus current, shrinks cable cross-sections, and lowers installation cost in large multi-axis cabinets.
- 30 A Continuous / 60 A Peak — Handles high-inertia loads and aggressive acceleration profiles without thermal derating during production cycles.
- Seamless Logix Integration — Native Rockwell motion instruction set (MAM, MAS, MAPC) eliminates custom motion code; commissioning time is measured in hours, not days.
- Multi-Feedback Compatibility — Single drive platform supports encoder, resolver, and Stegmann absolute feedback — reducing spare-parts SKU count across mixed motor fleets.
- Proven Field Reliability — Ultra 3000 platform has 20+ years of global installed base in harsh manufacturing environments.
Complete System Bill of Materials
A fully operational Ultra 3000 SERCOS servo axis typically requires the following components:
- 2098-DSD-HV030-SE — Servo Drive (this unit)
- 2098-DSD-HVxxx-SE — Additional axis drives (matched current rating to motor)
- 1756-M08SE / 1756-M16SE — ControlLogix SERCOS Motion Module
- MPL / MPM / TL Series — Allen-Bradley Servo Motor (matched to drive current)
- 2090-XXXX-XXXX — Motor Power & Feedback Cable Set
- 2098-UWCPW-Dxxx — Ultra 3000 Common Bus Power Supply (if shared DC bus topology)
- 1756-L7x / 1756-L8x — ControlLogix CPU with Motion Task
- Panel-mount 24 V DC control power supply
- SERCOS fiber-optic patch cables (ST connector, 660 nm)
Compliance & Industry Standards
- UL 508C — Power Conversion Equipment
- CE Marking — Low Voltage Directive (LVD) 2014/35/EU & EMC Directive 2014/30/EU
- IEC 61800-3 — Adjustable Speed Electrical Power Drive Systems (EMC)
- IEC 61800-5-1 — Safety requirements for adjustable speed drive systems
- SERCOS I/II Protocol Standard (IEC 61491)
- RoHS Compliant
Quality Assurance & Sourcing
Every unit offered through Konmask.com undergoes the following quality process:
- Visual & Physical Inspection — Label integrity, connector condition, housing damage check, and firmware version verification.
- Functional Power-On Test — Drive is energized and fault-code status confirmed clear prior to shipment.
- Authentic OEM Traceability — Units sourced from authorized distributors or verified surplus channels with documented chain of custody.
- Secure Anti-Static Packaging — ESD-safe bags, foam-lined cartons, and shock-indicator labels for international freight.
- 90-Day Warranty — Covers manufacturing defects and functional failure under normal operating conditions.
How to Source This Part
To place an order or request a formal quotation for the 2098-DSD-HV030-SE:
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Online: https://Konmask.com
Please provide your required quantity, delivery timeline, and destination country. We respond to all inquiries within 1 business day (UTC+8).
Application-Specific FAQ
Q: Can the 2098-DSD-HV030-SE operate on a 230 V AC supply instead of 460 V?
A: Yes. The HV designation supports both 230 V and 460 V three-phase input. Verify the drive’s internal jumper/parameter configuration matches your supply voltage before commissioning.
Q: Which SERCOS generation does the -SE suffix support — SERCOS I or SERCOS II?
A: The -SE suffix supports both SERCOS I and SERCOS II protocols. The operating generation is selected by the SERCOS motion module on the controller side.
Q: Is this drive compatible with the 1756-M02AE (analog) motion module?
A: No. The -SE suffix is exclusively SERCOS fiber-optic. For analog ±10 V interface, you would require the 2098-DSD-HV030 (without -SE suffix).
Q: What servo motors are rated for use with this drive?
A: Rockwell-published motor/drive compatibility tables (publication 2098-IN003) list approved MPL, MPM, and TL-Series motors. Always cross-reference motor continuous stall current against the drive’s 30 A continuous rating.
Q: Can I use this drive as a replacement in an existing Ultra 3000 SERCOS system without re-commissioning?
A: In most cases, yes — provided the replacement drive is the same catalog number and firmware is matched. Drive parameters can be uploaded/downloaded via UltraWare software to restore the original axis configuration.
Q: Do you offer expedited shipping for urgent production downtime situations?
A: Yes. Contact us directly at support@konmask.com or +0086 19859288691 and specify your urgency. We can arrange DHL/FedEx express freight with same-day or next-day dispatch in most cases.
