SLC 500 Communication Solution — Allen-Bradley 1747-KFC15 | DF1/DH-485 Interface Module
Where This Product Is Used
The Allen-Bradley 1747-KFC15 is a serial communication interface module designed for SLC 500 fixed and modular chassis systems. It is widely deployed in the following industrial environments:
- Automotive assembly lines — point-to-point DF1 communication between PLCs and SCADA hosts
- Food & beverage processing plants — DH-485 multi-drop networks linking SLC 500 controllers to HMI panels (PanelView series)
- Water & wastewater treatment facilities — remote monitoring via RS-232/RS-485 serial links to RTUs
- Pharmaceutical manufacturing — validated serial communication paths in 21 CFR Part 11 environments
- Material handling & conveyor systems — coordinating multiple SLC 500 nodes on a DH-485 token-passing network
- OEM machine builders — embedded serial gateway between SLC 500 and third-party devices (drives, barcode readers, weighing systems)
- Building automation & HVAC — legacy integration of SLC 500 controllers with BMS systems via DF1 protocol
Technical Specifications
| Part Number | 1747-KFC15 |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Product Series | SLC 500 |
| Module Type | Serial Communication Interface Module |
| Supported Protocols | DF1 Full-Duplex, DF1 Half-Duplex, DH-485 |
| Communication Ports | Channel 0: RS-232 (DF1); Channel 1: RS-485 (DH-485) |
| Baud Rate | 110 bps – 19.2 Kbps (configurable) |
| DH-485 Node Capacity | Up to 32 nodes |
| Backplane Current Draw | 250 mA @ 5 VDC |
| Operating Temperature | 0 °C to 60 °C (32 °F to 140 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% – 95% non-condensing |
| Chassis Compatibility | SLC 500 modular chassis (1746-A4, A7, A10, A13) |
| Weight | 250 g (approx.) |
| Firmware | Configurable via RSLinx / RSLogix 500 |
Why Engineers Specify This Model
- Dual-protocol flexibility: Supports both DF1 (RS-232) and DH-485 simultaneously, eliminating the need for external converters in mixed-network architectures.
- Proven SLC 500 ecosystem fit: Native backplane integration — no external power supply or gateway hardware required.
- RSLinx & RSLogix 500 compatibility: Fully configurable through standard Rockwell software toolchain, reducing commissioning time.
- Long-term availability: Critical spare for installed SLC 500 base; widely stocked for MRO and emergency replacement scenarios.
- Deterministic token-passing on DH-485: Ensures predictable scan times in multi-node HMI/PLC networks.
- Compact single-slot form factor: Preserves chassis slots in space-constrained panels.
Complete System Bill of Materials
A typical SLC 500 serial communication node using the 1747-KFC15 includes:
| Cat. No. | Description | Role |
|---|---|---|
| 1747-KFC15 | Interface Module | Serial communication (this item) |
| 1746-A7 | 7-Slot SLC 500 Chassis | Module housing |
| 1747-L543 | SLC 5/04 CPU | Controller (DH+/DH-485 capable) |
| 1746-P4 | Power Supply | Chassis power |
| 2711-NC13 | DH-485 Cable | HMI to PLC network wiring |
| 1747-CP3 | RS-232 Programming Cable | PC to Channel 0 configuration |
Compliance & Industry Standards
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- RoHS Compliant — Directive 2011/65/EU
- ATEX / IECEx: Not rated for hazardous locations; install in purged/pressurized enclosures where required
- IEC 61131-2 — Programmable controllers: equipment requirements and tests
- ODVA / DF1 Protocol: Conforms to Rockwell DF1 protocol specification
Quality Assurance & Sourcing
All units sourced and listed by Konmask.com undergo the following verification process:
- Visual inspection for label authenticity, date codes, and physical condition
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator cards
- Traceability documentation available on request (batch records, test reports)
- Units are sourced from authorized distributors, OEM surplus, or verified MRO channels — never from unverified grey-market sources
How to Source This Part
- Add to cart and complete checkout — secure payment via major cards and bank transfer (T/T).
- Request a quote for volume orders (>5 units) or urgent delivery — email support@konmask.com.
- Lead time: In-stock units ship within 1–3 business days; ex-stock orders confirmed within 24 hours.
- Export documentation: Commercial invoice, packing list, and CO available for international shipments.
- Technical pre-sales support: Our engineers can verify compatibility with your existing SLC 500 chassis and firmware revision before purchase.
Application-Specific FAQ
Q: Can the 1747-KFC15 replace a 1747-KE or 1747-KFC module?
A: The KFC15 is the enhanced revision of the KFC series. It is backward-compatible with most SLC 500 applications using DF1 or DH-485. Verify firmware revision requirements in your RSLogix 500 project before substitution.
Q: Does this module support EtherNet/IP or DeviceNet?
A: No. The 1747-KFC15 is a serial-only module (RS-232/RS-485). For EtherNet/IP connectivity, consider the 1747-AENTR or 1756-ENBT (ControlLogix). For DeviceNet, use the 1747-SDN scanner module.
Q: How many HMI panels can be connected on DH-485?
A: DH-485 supports up to 32 nodes. In practice, 8–16 nodes is typical for reliable performance at 19.2 Kbps. Each PanelView terminal counts as one node.
Q: Is RSLinx Classic required for configuration?
A: RSLinx Classic (or RSLinx Enterprise) is required to configure the driver and establish communication. RSLogix 500 is used for ladder logic programming. Both are Rockwell Automation software products.
Q: What is the warranty on this part?
A: Konmask.com provides a 90-day functional warranty on all tested units. Extended warranty and exchange programs are available — contact us for details.
Q: Can you supply a Certificate of Conformance (CoC)?
A: Yes. CoC and inspection reports are available upon request for quality-critical procurement processes.
