Process & Motion Control Solution — Allen-Bradley 1756-L82E | ControlLogix 5580 Series
Where This Product Is Used
The Allen-Bradley 1756-L82E ControlLogix 5580 controller is deployed across demanding industrial environments where deterministic control, high-speed data exchange, and scalable I/O architecture are non-negotiable. Typical application sites include:
- Oil & Gas Processing Plants — pipeline SCADA, compressor control, and emergency shutdown (ESD) integration
- Automotive Assembly Lines — multi-axis servo coordination, weld cell sequencing, and conveyor synchronization
- Water & Wastewater Treatment — pump station automation, chemical dosing, and SCADA-linked remote I/O
- Food & Beverage Production — batch processing, CIP cycle management, and hygienic line control
- Pharmaceutical Manufacturing — validated process control under 21 CFR Part 11 and GAMP 5 frameworks
- Power Generation & Utilities — turbine control, substation automation, and load management
- Mining & Minerals Processing — crusher control, conveyor drives, and plant-wide DCS integration
Technical Specifications
| Parameter | Specification |
|---|---|
| Catalog Number | 1756-L82E |
| Series | ControlLogix 5580 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| User Memory | 5 MB |
| I/O Capacity | Up to 128,000 I/O points |
| Communication Port | 1× EtherNet/IP (dual-port, DLR capable) |
| Backplane Communication | ControlLogix backplane (1756 chassis) |
| Programming Software | Studio 5000 Logix Designer v21+ |
| Supported Languages | Ladder Diagram, Function Block, Structured Text, Sequential Function Chart, Motion |
| Task Types | Continuous, Periodic, Event |
| Motion Axes | Up to 256 axes (coordinated motion) |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Power Supply | Via 1756 chassis power supply (1756-PA72 / 1756-PB72) |
| Weight | 400 g (approx.) |
| Certifications | UL, CE, cUL, ATEX Zone 2 (with approved enclosure) |
Why Engineers Specify This Model
The 1756-L82E occupies the mid-to-high tier of the ControlLogix 5580 family, offering a compelling balance between memory capacity and cost for complex, multi-discipline applications:
- 5 MB User Memory — sufficient for large ladder programs, motion profiles, and extensive data logging without requiring the top-tier L85E
- Integrated EtherNet/IP Port — eliminates the need for a separate 1756-EN2T communication module in single-network topologies, reducing chassis slot consumption and BOM cost
- Device Level Ring (DLR) Support — built-in network redundancy for EtherNet/IP without additional hardware
- Scalable I/O Architecture — supports local 1756 chassis I/O, remote 1756/1794/1734 I/O, and third-party EtherNet/IP devices
- Firmware Revision Flexibility — field-upgradeable firmware via ControlFLASH; backward-compatible with existing Studio 5000 projects
- High-Speed Task Execution — periodic tasks down to 1 ms for time-critical control loops
Complete System Bill of Materials
A fully operational 1756-L82E control system typically requires the following components. Konmask stocks or can source all items below:
| Cat. No. | Description | Qty |
|---|---|---|
| 1756-L82E | ControlLogix 5580 Controller, 5MB, EtherNet/IP | 1 |
| 1756-A7 / A10 / A13 / A17 | ControlLogix Chassis (7, 10, 13, or 17 slots) | 1 |
| 1756-PA72 / 1756-PB72 | ControlLogix Power Supply (120/240 VAC or 18–32 VDC) | 1 |
| 1756-EN2T / 1756-EN2TR | EtherNet/IP Communication Module (additional networks) | As required |
| 1756-IB16 / 1756-OB16E | Digital Input / Output Modules | As required |
| 1756-IF8 / 1756-OF8 | Analog Input / Output Modules | As required |
| 1756-M02AE | Servo Drive Interface Module (motion applications) | As required |
| 1756-EWEB | EtherNet/IP Web Server Module (HMI/data publishing) | Optional |
| 1784-SD1 / 1784-SD2 | SD Memory Card (program backup) | 1 |
Compliance & Industry Standards
- UL 508 — Industrial Control Equipment
- IEC 61131-3 — PLC Programming Languages
- IEC 61784 / IEC 61158 — EtherNet/IP Fieldbus Standard
- ATEX Directive 2014/34/EU — Zone 2 hazardous area use (with certified enclosure)
- RoHS Compliant — Restriction of Hazardous Substances
- CE Marking — EU Machinery and EMC Directives
- ISA-99 / IEC 62443 — Industrial Cybersecurity (EtherNet/IP network segmentation recommended)
Quality Assurance & Sourcing
Konmask operates a rigorous incoming inspection and traceability protocol for all Allen-Bradley ControlLogix modules:
- Visual Inspection — label integrity, connector condition, firmware revision label verification
- Functional Power-On Test — module self-diagnostics confirmed via Studio 5000 online connection
- Firmware Version Documentation — revision recorded and disclosed prior to shipment
- Traceability — lot number, inspection date, and technician ID logged for every unit
- Packaging — ESD-safe anti-static bag, foam-lined carton; original Rockwell packaging preserved where available
- Warranty — 12-month operational warranty against manufacturing defects
How to Source This Part
- Submit an RFQ — email support@konmask.com with your required quantity, target delivery date, and any firmware revision requirements
- Receive a Quotation — our team responds within 1 business day with pricing, lead time, and stock availability
- Order Confirmation — purchase order accepted via email; proforma invoice issued for prepayment or net terms (approved accounts)
- Inspection & Dispatch — unit passes QA protocol; ships via DHL / FedEx / SF Express with tracking number provided
- After-Sales Support — technical assistance available for integration, firmware upgrade, and Studio 5000 configuration queries
For urgent requirements or large-volume orders, call us directly: +0086 19859288691
Application-Specific FAQ
Q: Can the 1756-L82E run safety logic alongside standard control?
A: The L82E is a standard (non-safety) controller. For integrated safety, specify the 1756-L82ES (GuardLogix 5580). The L82E can, however, communicate with a GuardLogix controller over the same chassis backplane.
Q: Is the 1756-L82E backward-compatible with older ControlLogix L7x projects?
A: Yes, with minor conversion steps in Studio 5000. The 5580 series uses a different processor architecture; Rockwell provides a migration guide (Publication 1756-RM100) for L7x-to-L8x project conversion.
Q: What is the maximum number of EtherNet/IP nodes this controller can manage?
A: The 1756-L82E supports up to 100 CIP connections on its onboard EtherNet/IP port. Additional 1756-EN2T modules expand this capacity per slot.
Q: Can I use this controller in a redundant CPU configuration?
A: Yes. Pair two 1756-L82E controllers with a 1756-RM2 redundancy module and 1756-SYNCH fiber cable for a hot-standby redundant system (requires ControlLogix Redundancy firmware bundle).
Q: What Studio 5000 version is required?
A: Studio 5000 Logix Designer v28 or later is recommended for full 5580-series feature support. Earlier versions (v21+) support basic functionality.
Q: Does Konmask provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and HS code documentation (HS 8537.10) for all international orders.
