Allen-Bradley 1756-RMC10 Cable – Motion Controller Interface Cable | ControlLogix Platform
Engineering Background
The Allen-Bradley 1756-RMC10 is a dedicated interface cable designed for use with the Rockwell Automation ControlLogix RMC (Remote Motion Controller) module series. In high-precision motion control architectures, signal integrity between the controller backplane and external drive/encoder interfaces is critical. This cable provides the physical layer connection that ensures deterministic, low-latency communication between the 1756-RMC motion controller and field devices, maintaining the timing accuracy required for coordinated multi-axis motion sequences.
Product Positioning
Targeted at OEM machine builders, system integrators, and MRO procurement teams operating Rockwell Automation ControlLogix-based motion systems, the 1756-RMC10 Cable is an essential spare and commissioning component. Whether replacing a worn cable in a production environment or stocking for new machine builds, this part ensures uninterrupted motion controller operation across demanding industrial cycles.
Complete Technical Specifications
| Part Number | 1756-RMC10 |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Family | ControlLogix RMC Motion Controller Accessories |
| Cable Type | Motion Controller Interface Cable |
| Compatible Module | 1756-RMC10 (ControlLogix Remote Motion Controller, 10-axis) |
| Platform | ControlLogix 1756 Series |
| Connector Type | Per Rockwell Automation 1756-RMC10 module specification |
| Weight | 160 g (approx.) |
| Shipping Requirement | Physical shipment required |
| Compliance | RoHS-compatible; CE-marked system compatible |
| Country of Origin | USA (Rockwell Automation manufacturing) |
Proven Application Environments
- Automotive Assembly Lines — Multi-axis servo coordination requiring deterministic cable signal paths between RMC modules and servo drives
- Packaging Machinery — High-cycle motion sequences where cable integrity directly impacts throughput and reject rates
- CNC & Machining Centers — Precision axis interpolation dependent on clean encoder/drive feedback through the RMC interface
- Semiconductor & Electronics Manufacturing — Low-vibration, high-accuracy positioning systems using ControlLogix motion platforms
- Material Handling & Robotics — Coordinated pick-and-place and conveyor systems integrated with 1756-RMC10 controllers
- MRO / Spare Parts Inventory — Critical spare stocking for facilities running ControlLogix motion systems to minimize unplanned downtime
Engineering Advantages
- OEM-Specification Compliance — Designed to Rockwell Automation’s exact electrical and mechanical interface requirements for the 1756-RMC10 module, eliminating compatibility risk
- Signal Integrity Assurance — Shielded construction and precision termination maintain signal fidelity across the full operating bandwidth of the RMC motion controller
- Plug-and-Play Replacement — Direct drop-in replacement for existing installations; no firmware changes or parameter adjustments required
- Industrial-Grade Durability — Rated for continuous flexing, vibration, and temperature cycling typical of production floor environments
- Reduced Commissioning Risk — Using the correct OEM cable eliminates a common root cause of motion faults, encoder errors, and drive communication alarms during startup
System Architecture & Signal Flow
In a ControlLogix motion system, the 1756-RMC10 module resides in the 1756 chassis and communicates with the Logix controller via the backplane. The 1756-RMC10 Cable connects the module’s front-panel interface to external servo drives or encoder feedback devices. Signal flow is as follows:
ControlLogix Backplane → 1756-RMC10 Module → [1756-RMC10 Cable] → Servo Drive / Encoder Interface
The cable carries both command signals (velocity/torque references or digital step/direction) and feedback signals (encoder counts, drive status) depending on the drive interface type configured in the RMC module. Maintaining cable integrity at this junction is essential for closed-loop motion accuracy and fault-free operation.
Sourcing & Quality Verification
- Authorized & Verified Supply Chain — Konmask.com sources 1756-series components through verified industrial distributors and OEM-authorized channels
- Pre-Shipment Inspection — Each unit undergoes visual inspection for connector integrity, cable jacket condition, and label/part number verification before dispatch
- Traceability Documentation — Certificate of conformance and sourcing documentation available upon request for regulated industries
- Counterfeit Risk Mitigation — All Allen-Bradley parts are cross-referenced against Rockwell Automation part number databases; suspected non-genuine parts are quarantined and not listed
- Packaging Integrity — Ships in anti-static, protective packaging to prevent transit damage to connectors and cable jacket
Procurement Process
- Confirm Part Number — Verify 1756-RMC10 against your BOM or existing cable label; contact us if you need cross-reference assistance
- Request Quote — Submit your quantity and required delivery timeline via support@konmask.com or +0086 19859288691
- Order Confirmation — Receive proforma invoice with lead time, shipping method, and tracking commitment
- Quality Documentation — Request CoC or inspection report at order placement if required by your QMS
- Shipment & Tracking — Express and standard international shipping available; DDP/DAP Incoterms supported for cross-border orders
- After-Sales Support — Technical support available for installation verification and compatibility confirmation post-delivery
