Discrete I/O Control Solution — Allen-Bradley 1762-L24BXB | MicroLogix 1100 Series
Where This Product Is Used
The Allen-Bradley 1762-L24BXB MicroLogix 1100 is a compact, high-performance programmable logic controller deployed across a wide range of industrial automation environments. Engineers specify this unit in applications including:
- Conveyor & Material Handling Systems — Sequencing, speed control, and fault detection on production lines.
- Packaging Machinery — Coordinating fill, seal, label, and reject stations with deterministic I/O response.
- HVAC & Building Automation — Monitoring discrete sensor inputs for damper position, fan status, and alarm conditions.
- Water & Wastewater Treatment — Pump sequencing, level control, and remote monitoring via built-in Ethernet/RS-232.
- Food & Beverage Processing — Hygienic-environment control panels requiring compact DIN-rail footprint and relay output isolation.
- OEM Machine Builders — Embedded controller for standalone machines requiring a cost-effective, field-proven PLC platform.
- Panel Upgrade & Retrofit Projects — Drop-in replacement for legacy MicroLogix 1000/1100 installations without rewiring.
Technical Specifications
| Parameter | Value |
|---|---|
| Catalog Number | 1762-L24BXB |
| Series / Family | MicroLogix 1100 |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Total I/O Points | 24 (14 Inputs + 10 Outputs) |
| Input Type | 24V DC Sink/Source |
| Output Type | Relay (Form A, 2A per point) |
| Communication Ports | RS-232 (Channel 0), RS-232/485 (Channel 1), Ethernet/IP (RJ-45) |
| Program Memory | 8 KB (user program + data) |
| Power Supply | 24V DC |
| Operating Temperature | 0 °C to 55 °C (32 °F to 131 °F) |
| Storage Temperature | -40 °C to 85 °C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Mounting | DIN Rail or Panel Mount |
| Dimensions (H × W × D) | 90 × 180 × 87 mm (approx.) |
| Weight | 500 g (approx.) |
| Protection Rating | IP20 |
| Programming Software | RSLogix 500 / Studio 5000 Logix Designer (Micro Starter Lite — free) |
| Expansion Modules | Up to 4 × 1762-series expansion I/O modules |
Why Engineers Specify This Model
- Integrated Ethernet/IP — Native EtherNet/IP port enables direct connection to SCADA, HMI, and enterprise MES systems without an additional communication module.
- Relay Outputs for Mixed Loads — Relay contacts handle AC and DC loads up to 240V AC / 30V DC, eliminating external interposing relays in many panel designs.
- Dual Serial Ports — Channel 0 (RS-232) for programming/HMI; Channel 1 (RS-232/485) for Modbus RTU, DF1, or DH-485 device networks.
- LCD Display & Keypad — Onboard operator interface for status monitoring and minor parameter adjustments without a laptop on the plant floor.
- Compact Footprint — 24 I/O points in a single base unit reduces panel real estate and wiring complexity versus modular rack systems.
- Proven Ecosystem — Fully compatible with the 1762-series expansion library (analog, RTD, thermocouple, high-speed counter modules).
- Free Programming Software — RSLogix Micro Starter Lite is available at no cost, lowering total project cost for OEMs and integrators.
Complete System Bill of Materials
A typical MicroLogix 1100 control panel build includes the following components. Contact Konmask for bundle pricing.
- 1762-L24BXB — Base controller (this unit)
- 1762-IQ16 — 16-point 24V DC input expansion module
- 1762-OW16 — 16-point relay output expansion module
- 1762-IF4 — 4-channel analog input module (4–20 mA / 0–10V)
- 1762-OF4 — 4-channel analog output module
- 1763-MM1 — 64 KB memory module (data logging / backup)
- 1761-CBL-PM02 — RS-232 programming cable
- 1762-IQ8OW6 — Combination 8-input / 6-relay output expansion
- 24V DC DIN-rail power supply (Phoenix Contact or equivalent)
- Ethernet patch cable (Cat5e or Cat6, shielded recommended)
Compliance & Industry Standards
- UL Listed (UL 508) — Industrial Control Equipment
- CE Marked — EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- RoHS Compliant — Directive 2011/65/EU
- cUL Listed (Canadian market)
- EtherNet/IP conformance tested — ODVA certified
- Suitable for use in Pollution Degree 2 environments per IEC 60664-1
Quality Assurance & Sourcing
Konmask.com sources Allen-Bradley components through verified industrial distribution channels. Every unit offered on this listing is:
- Inspected for physical integrity, label authenticity, and firmware revision upon receipt.
- Stored in ESD-safe, climate-controlled warehousing to preserve component longevity.
- Traceable to original manufacturer documentation and revision history.
- Backed by our standard warranty and return policy — see store policy page for details.
We do not list counterfeit, cloned, or grey-market product. If you require a Certificate of Conformance (CoC) or third-party inspection report, please contact us before ordering.
How to Source This Part
- Add to Cart — For standard in-stock orders, proceed directly to checkout.
- Request a Quote — For quantities ≥ 5 units or project BOM pricing, email support@konmask.com with your project details.
- Lead Time — In-stock units ship within 1–3 business days. Out-of-stock items: contact us for current lead time from our supplier network.
- Export & Cross-Border Orders — We support international shipments. Provide your destination country and we will confirm applicable duties, HS code documentation, and shipping options.
- Phone / WhatsApp — Reach our technical sales team at +0086 19859288691 for urgent requirements.
Application-Specific FAQ
Q: Can the 1762-L24BXB communicate with a Siemens HMI via Modbus RTU?
A: Yes. Channel 1 supports Modbus RTU (slave mode) via RS-485, making it compatible with most third-party HMI panels that support Modbus.
Q: How many expansion modules can I add to this base unit?
A: Up to 4 × 1762-series expansion modules, providing a maximum of 144 additional I/O points depending on module selection.
Q: Is this unit suitable for outdoor enclosures?
A: The 1762-L24BXB is rated IP20 and must be installed inside a sealed enclosure (minimum IP54) for outdoor or wash-down environments.
Q: What is the difference between 1762-L24BXB and 1762-L24BXBA?
A: The “A” suffix denotes a later hardware revision with minor firmware enhancements. Both are functionally equivalent for most applications. Contact us to confirm revision availability.
Q: Can I use Studio 5000 to program this controller?
A: No. The MicroLogix 1100 is programmed with RSLogix 500 (or the free Micro Starter Lite edition). Studio 5000 is for ControlLogix/CompactLogix families only.
Q: Do you provide programming or integration support?
A: We supply hardware. For programming services, we can refer you to certified Rockwell Automation system integrators in your region.
