Genuine Allen-Bradley 1769-IR6 6-Point RTD/Resistance Input Module | CompactLogix 1769 Series – Verified Source
The Allen-Bradley 1769-IR6 is a 6-channel RTD and resistance input module designed for the CompactLogix 1769 I/O platform by Rockwell Automation. At Konmask, every unit we supply is sourced through verified channels and subjected to our rigorous 4-step quality verification process — giving industrial buyers the confidence they need when sourcing critical automation components.
Technical Specifications
- Manufacturer: Allen-Bradley / Rockwell Automation
- Part Number: 1769-IR6
- Series: CompactLogix 1769
- Input Channels: 6 (individually configurable)
- Input Types: RTD (Pt, Ni, Cu) and Resistance (0–1000 Ω)
- RTD Types Supported: Pt100, Pt200, Pt500, Pt1000, Ni120, Cu10
- Resolution: 16-bit
- Accuracy: ±0.1°C (typical)
- Backplane Current Draw: 75 mA @ 5 VDC; 0 mA @ 24 VDC
- Power Dissipation: 0.375 W
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% (non-condensing)
- Dimensions (H × W × D): 118 × 35 × 87 mm
- Weight: Approx. 250 g
- Certifications: UL, CE, C-Tick
Our 4-Step Quality Verification Process
Every Allen-Bradley module shipped from Konmask passes through our standardized verification workflow before dispatch:
- Step 1 – Source Authentication: We verify the supply chain origin and cross-reference supplier credentials against known authorized distributor networks.
- Step 2 – Physical Inspection: Each unit is inspected for label integrity, housing condition, connector pin alignment, and counterfeit indicators (hologram, date codes, lot traceability).
- Step 3 – Functional Bench Test: Where applicable, modules are powered up and tested for basic communication and I/O response prior to packaging.
- Step 4 – Documentation Review: We confirm that firmware revision, catalog number, and series letter match the declared specification before issuing a shipment certificate.
Key Features & Benefits
- 6 individually configurable RTD/resistance input channels — maximum flexibility per slot
- High-resolution 16-bit A/D conversion for precise temperature measurement
- Open-wire detection on all channels — fail-safe for critical process loops
- Software-configurable channel type — no hardware jumpers required
- Compact 1769 form factor — integrates directly into CompactLogix and MicroLogix 1500 systems
- Low backplane power draw — ideal for dense I/O configurations
- Compatible with RSLogix 5000 / Studio 5000 Logix Designer for seamless programming
Typical Applications
- Temperature monitoring in HVAC, boiler, and furnace control systems
- Process temperature loops in chemical, pharmaceutical, and food & beverage plants
- Motor winding temperature protection in drive systems
- Resistance-based position or level sensing in industrial machinery
- OEM machine builders requiring compact, high-accuracy thermal input
Compatible System Components
- Controllers: 1769-L16ER, 1769-L18ER, 1769-L24ER, 1769-L27ERM, 1769-L30ER, 1769-L33ER, 1769-L36ERM
- Expansion Cables: 1769-CRR1, 1769-CRR3, 1769-CLL1, 1769-CLL3
- End Caps: 1769-ECR (right), 1769-ECL (left)
- Power Supplies: 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
- Software: Studio 5000 Logix Designer v21+, RSLogix 5000 v20+
Global Sourcing & Shipping Capabilities
- Stock Location: China (Mainland) — with bonded warehouse options for select regions
- Lead Time: In-stock units typically ship within 1–3 business days of order confirmation
- Shipping Methods: DHL Express, FedEx International Priority, UPS Worldwide, sea freight for bulk orders
- Export Compliance: All shipments are accompanied by commercial invoice, packing list, and certificate of origin as required
- Regions Served: Asia-Pacific, Middle East, Europe, North America, South America, Africa
- Minimum Order: 1 unit (bulk pricing available for orders of 5+ units)
Certifications & Compliance Statement
- UL Listed – Industrial Control Equipment
- CE Marked – EMC Directive 2014/30/EU; Low Voltage Directive 2014/35/EU
- C-Tick / RCM – Australian Communications and Media Authority
- RoHS Compliant – Restriction of Hazardous Substances
Konmask does not manufacture Allen-Bradley products. All trademarks, brand names, and part numbers belong to Rockwell Automation, Inc. We are an independent supplier of genuine surplus and new-in-box automation components.
How to Order
- Online: Add to cart and proceed to checkout — we will confirm availability and lead time within 1 business day
- Email RFQ: Send your BOM or part list to support@konmask.com for a formal quotation
- Phone / WhatsApp: +0086 19859288691 (Mon–Sat, 09:00–18:00 CST)
- Bulk / Project Orders: Contact us for volume pricing, consignment stock arrangements, or turnkey BOM sourcing
Authenticity & Trust FAQ
Q: Are these modules new or refurbished?
A: We clearly state the condition of each unit in the listing (New, New Surplus, or Refurbished). The 1769-IR6 listed here is new or new surplus unless otherwise noted. Contact us to confirm current stock condition.
Q: Can you provide a test report or inspection certificate?
A: Yes. A pre-shipment inspection report is available upon request for orders of 3+ units. Please mention this requirement when placing your order.
Q: Do you offer a warranty?
A: All units carry a 12-month warranty against manufacturing defects from the date of shipment. Warranty claims are handled directly by Konmask — no need to contact Rockwell Automation.
Q: What if I receive a unit that doesn’t match the specification?
A: We offer a full replacement or refund within 30 days of delivery for any unit that does not match the declared catalog number, series, and condition.
Q: Are you an authorized Rockwell Automation distributor?
A: Konmask is an independent supplier, not an authorized Rockwell distributor. We source genuine components through verified secondary market and surplus channels. This allows us to offer competitive pricing and availability on hard-to-find parts.
