Allen-Bradley 2711P-RP1X – PanelView Plus Logic Module | PanelView Plus 6 / PanelView Plus Platform
Engineering Background
The Allen-Bradley 2711P-RP1X is a replacement logic module designed for the PanelView Plus and PanelView Plus 6 family of Human-Machine Interface (HMI) terminals manufactured by Rockwell Automation. As the computational core of the PanelView Plus platform, this module houses the processor, memory, and communication interfaces that drive runtime visualization, operator interaction, and network connectivity. It is field-replaceable, enabling maintenance teams to restore HMI functionality without replacing the entire terminal assembly.
Product Positioning
Targeted at maintenance engineers, system integrators, and MRO procurement specialists operating Allen-Bradley PanelView Plus installations, the 2711P-RP1X is the authoritative spare for minimizing unplanned downtime in production environments. Konmask.com sources this module through verified industrial distribution channels, providing procurement teams with a reliable, traceable supply path for critical HMI infrastructure.
Complete Technical Specifications
| Part Number | 2711P-RP1X |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Family | PanelView Plus / PanelView Plus 6 |
| Module Type | Logic / Processor Replacement Module |
| Compatible Terminals | PanelView Plus 6 terminals (2711P series); select PanelView Plus terminals |
| Operating System | Windows CE (embedded) |
| Application Software | FactoryTalk View ME (Machine Edition) |
| Communication Ports | USB (Type A & Type B), RS-232 Serial, Ethernet 10/100 Base-T (RJ-45) |
| Network Protocols | EtherNet/IP, DH-485, DF1 |
| Memory | Integrated flash storage for application and OS |
| Power Supply | Supplied via host terminal backplane |
| Operating Temperature | 0 °C to +55 °C (32 °F to 131 °F) |
| Storage Temperature | -20 °C to +70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| Enclosure Rating | IP20 (module); host terminal rating applies to panel face |
| Certifications | UL Listed, CE Marked, cUL |
| Weight | Approx. 700 g |
| Country of Origin | USA / Mexico (Rockwell Automation manufacturing) |
Proven Application Environments
- Discrete Manufacturing — Automotive assembly lines, machine tool control panels, and robotic cell HMI stations running FactoryTalk View ME applications.
- Process Industries — Food & beverage, pharmaceutical batch processing, and chemical plant operator workstations integrated with Allen-Bradley PLCs via EtherNet/IP.
- Material Handling — Conveyor control, palletizing systems, and warehouse automation where PanelView Plus terminals serve as primary operator interfaces.
- Water & Wastewater — SCADA-connected HMI nodes in pump stations and treatment facilities requiring long-term parts availability.
- MRO / Spare Parts Programs — Facilities maintaining PanelView Plus fleets as part of planned preventive maintenance and emergency repair inventories.
Engineering Advantages
- Field-Replaceable Design — The logic module separates from the display assembly, allowing processor replacement without disturbing panel wiring or display hardware.
- Platform Continuity — Maintains compatibility with existing FactoryTalk View ME application files, eliminating re-engineering costs associated with terminal replacement.
- Dual Ethernet & Serial Support — Supports simultaneous EtherNet/IP network connectivity and legacy RS-232/DF1 communication for mixed-generation control architectures.
- USB Application Transfer — Enables rapid application loading and firmware updates via USB without requiring a dedicated programming workstation on the plant floor.
- Rockwell Ecosystem Integration — Native compatibility with Studio 5000, FactoryTalk Diagnostics, and RSLinx Classic for seamless commissioning and remote diagnostics.
System Architecture & Signal Flow
The 2711P-RP1X logic module interfaces directly with the PanelView Plus terminal backplane, receiving DC power and display signals from the host chassis. The embedded processor executes the FactoryTalk View ME runtime, rendering operator graphics and processing tag data received over EtherNet/IP or serial communication links from connected Allen-Bradley PLCs (ControlLogix, CompactLogix, MicroLogix, SLC 500 series). Operator inputs (touchscreen or keypad) are processed locally and translated into PLC tag writes over the configured communication path. The USB ports support peripheral devices and application/firmware management. All configuration and application data is stored in onboard non-volatile flash memory, ensuring retention through power cycles.
Sourcing & Quality Verification
- Supply Chain — Konmask.com procures 2711P-RP1X modules through established industrial distribution channels with documented traceability to authorized Rockwell Automation distributors and verified MRO surplus sources.
- Inspection Protocol — Each unit undergoes visual inspection for physical integrity, label authenticity verification (part number, date code, serial number format), and packaging condition assessment prior to listing.
- Authenticity Assurance — Counterfeit risk mitigation is a core procurement standard. Modules exhibiting inconsistent labeling, non-standard packaging, or anomalous date codes are rejected.
- Warranty — Covered by Konmask.com’s standard 90-day functional warranty. Original Rockwell Automation warranty terms apply to new/sealed units where applicable.
Procurement Process
- Verify Compatibility — Confirm your PanelView Plus terminal model number (found on the terminal nameplate) is compatible with the 2711P-RP1X logic module. Refer to Rockwell Automation publication 2711P-IN009 for compatibility matrix.
- Request a Quote — Contact Konmask.com via email or phone for volume pricing, lead time confirmation, and export documentation requirements.
- Place Order — Orders accepted via the Konmask.com storefront, purchase order (NET terms available for qualified accounts), or direct bank transfer for international buyers.
- Shipping & Documentation — Standard shipment includes commercial invoice, packing list, and certificate of conformance. Export documentation (EAR99 classification) available upon request.
- Incoming Inspection — Recommended: verify part number label, inspect for physical damage, and confirm firmware version compatibility with your FactoryTalk View ME application before installation.
Technical FAQ
Q: Is the 2711P-RP1X compatible with all PanelView Plus terminal sizes?
A: The 2711P-RP1X is compatible with select PanelView Plus 6 and PanelView Plus terminal models. Compatibility depends on the terminal chassis generation. Always verify against the Rockwell Automation compatibility guide (publication 2711P-IN009) using your terminal’s model number.
Q: Will my existing FactoryTalk View ME application run on a replacement 2711P-RP1X?
A: Yes, provided the firmware version on the replacement module is compatible with your application’s FactoryTalk View ME version. Firmware updates can be applied via USB using FactoryTalk View ME Station software.
Q: Does the module retain application data after replacement?
A: Application data is stored on the logic module’s flash memory. A replacement module will not contain your existing application — you must reload your .MER application file via USB or network transfer after installation.
Q: Can Konmask.com provide export documentation for international shipments?
A: Yes. The 2711P-RP1X is classified EAR99 under US Export Administration Regulations. Konmask.com can provide commercial invoice, packing list, and certificate of conformance. Contact support@konmask.com for specific export requirements.
Q: What is the lead time for in-stock units?
A: In-stock units typically ship within 1–3 business days. Contact Konmask.com for real-time availability confirmation before placing time-critical orders.
