Allen-Bradley 1784-KTX ISA Communication Module – ControlLogix DH+/RIO Series
When a critical communication link between your PLC and field devices goes down, production halts — conveyor lines stop, batch processes abort mid-cycle, and maintenance teams scramble under pressure. In DH+ and Remote I/O (RIO) network environments, the ISA-bus communication card is the invisible backbone that keeps data flowing between your PC workstation and the Allen-Bradley control system. Without a reliable, compatible module in that ISA slot, your entire SCADA interface, programming terminal, and diagnostic visibility disappear instantly.
The Allen-Bradley 1784-KTX is a factory-original ISA-form-factor communication module engineered specifically for Rockwell Automation’s Data Highway Plus (DH+) and Remote I/O (RIO) network architectures. Within the 1784 series — Rockwell’s dedicated PC-based communication card family — the KTX variant occupies the dual-port, ISA-bus position, making it the go-to solution for legacy and hybrid automation environments worldwide where ISA-slot workstations remain in active service. Its continued demand in global industrial markets reflects the enormous installed base of Allen-Bradley PLC-5, SLC 500, and MicroLogix systems still running in manufacturing, oil & gas, water treatment, and automotive plants across North America, Europe, and Asia.
Technical Specifications
- Part Number: 1784-KTX
- Manufacturer: Allen-Bradley / Rockwell Automation
- Form Factor: ISA Bus (16-bit)
- Network Support: Data Highway Plus (DH+), Remote I/O (RIO)
- Series: 1784 PC Communication Cards
- Compatible OS: Windows (via RSLinx Classic driver)
- Interface Ports: Dual-port (DH+ and RIO simultaneously)
- Weight: Approx. 200 g
- Condition Available: New / Refurbished / Tested Surplus
Note: All specifications are sourced from official Rockwell Automation documentation. Konmask.com does not fabricate or alter manufacturer data.
Key Features & Benefits
- Dual-Network Capability: Simultaneously supports DH+ and RIO on a single ISA card, reducing slot consumption and wiring complexity.
- Seamless RSLinx Integration: Fully compatible with Rockwell’s RSLinx Classic, enabling RSWho browsing, RSLogix 5/500 programming, and FactoryTalk diagnostics without additional drivers.
- Legacy System Continuity: Extends the operational life of PLC-5 and SLC 500 installations, protecting capital investment in proven control architectures.
- High-Speed DH+ Communication: Supports DH+ baud rates up to 57.6 Kbps for reliable, deterministic data exchange in time-sensitive control loops.
- Plug-and-Play ISA Installation: Standard 16-bit ISA edge connector with jumper-configurable IRQ and I/O address settings for straightforward integration.
- Robust Industrial Design: Built to Rockwell Automation’s industrial-grade standards for continuous 24/7 operation in demanding plant environments.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white assembly lines, paint shop conveyors, and powertrain test cells using PLC-5 or SLC 500 controllers.
- Oil & Gas: Pipeline SCADA systems, compressor station controls, and wellhead automation with legacy DH+ networks.
- Water & Wastewater Treatment: Pump station control, filtration process management, and remote I/O telemetry over RIO networks.
- Food & Beverage: Batch processing, filling lines, and CIP (Clean-in-Place) systems integrated with Allen-Bradley PLCs.
- Pulp & Paper / Metals: Rolling mill drives, winder controls, and process monitoring stations requiring stable DH+ connectivity.
- Building Automation & Utilities: HVAC control panels and energy management systems with existing ISA-slot industrial PCs.
System Integration & Compatible Parts
The 1784-KTX is designed to work within the broader Allen-Bradley / Rockwell Automation ecosystem. Commonly paired and compatible components include:
- PLCs: Allen-Bradley PLC-5 series, SLC 500 series, MicroLogix 1500
- Software: RSLinx Classic (required driver), RSLogix 5, RSLogix 500, FactoryTalk View
- Network Accessories: 1770-CD (DH+ cable), 1784-KTX/B (enhanced revision), 1784-PCMK (PCMCIA alternative)
- Related Communication Cards: 1784-KT, 1784-KT2, 1784-PKTX (PCI variant), 1784-U2DHP (USB-to-DH+ adapter)
- Remote I/O Adapters: 1771-ASB, 1747-ASB for SLC RIO scanner configurations
If you need help confirming compatibility with your existing control system architecture, our technical team is ready to assist — contact us before ordering.
Our Quality Assurance Process
Every Allen-Bradley 1784-KTX unit shipped from Konmask.com passes through a structured inspection and verification process:
- Visual Inspection: PCB, connectors, and edge contacts checked for physical damage, corrosion, or component anomalies.
- Functional Testing: Module is bench-tested for DH+ and RIO communication handshake with RSLinx Classic to confirm driver recognition and network enumeration.
- Firmware / Revision Verification: Hardware revision and firmware version documented and disclosed prior to shipment.
- ESD-Safe Packaging: All units are packed in anti-static bags with foam cushioning to prevent transit damage.
- Traceability: Each unit is logged with inspection date, test result, and technician ID for full accountability.
How to Order
- Submit an Inquiry: Use the contact form or email support@konmask.com with your required quantity and any revision preferences.
- Receive a Quote: Our team will respond within 1 business day with pricing, lead time, and stock availability.
- Confirm & Pay: We accept T/T (bank transfer), PayPal, and other B2B payment methods. Proforma invoice provided upon request.
- Shipment & Tracking: Orders are dispatched via DHL, FedEx, or UPS with full tracking. Export documentation (commercial invoice, packing list) included.
- After-Sales Support: 90-day warranty on tested units. Technical support available post-delivery.
Why Choose Konmask.com?
- Specialized Industrial Focus: We exclusively source and supply industrial automation components — PLCs, DCS modules, drives, and communication cards — not consumer electronics.
- Global B2B Experience: Serving engineering firms, system integrators, and plant maintenance teams across Asia, Europe, the Middle East, and the Americas.
- Transparent Stock & Condition Disclosure: We clearly state whether a unit is new, refurbished, or tested surplus — no surprises.
- Technical Pre-Sales Support: Our team includes engineers with hands-on PLC and DCS experience who can validate compatibility before you commit.
- Fast Quotation Response: Most inquiries receive a detailed quote within 24 hours, including lead time and shipping options.
- Secure Export Compliance: All international shipments are handled with proper export documentation and customs compliance.
Frequently Asked Questions
Q: Is the 1784-KTX compatible with Windows 10 or Windows 11?
A: The 1784-KTX is an ISA-bus card and requires a physical ISA slot, which is not present in modern PCs. It is designed for use with older industrial workstations running Windows XP or Windows 7 with RSLinx Classic. For modern PC connectivity to DH+ networks, consider the 1784-U2DHP USB adapter instead.
Q: What is the difference between the 1784-KTX and 1784-KTX/B?
A: The 1784-KTX/B is a later hardware revision of the same card with minor component updates. Both support the same DH+ and RIO functionality and use the same RSLinx driver. Functionally, they are interchangeable in most applications.
Q: Can the 1784-KTX communicate with ControlLogix (1756) systems?
A: The 1784-KTX connects to DH+ and RIO networks. ControlLogix systems use EtherNet/IP or ControlNet natively. However, if your ControlLogix system includes a 1756-DHRIO bridge module, the 1784-KTX can communicate with it via the DH+ network segment.
Q: Do you provide a warranty on the 1784-KTX?
A: Yes. All tested and refurbished units carry a 90-day functional warranty. New/sealed units follow the manufacturer’s original warranty terms. Please contact us for details specific to your order.
Q: How long does international shipping take?
A: Standard express shipping (DHL/FedEx) typically takes 3–7 business days to most destinations. We ship from China and provide full tracking and export documentation.
