Machine Control & Process Visualization Solution — Allen-Bradley 2711-B6C5 | PanelView 600 Series
Where This Product Is Used
The Allen-Bradley 2711-B6C5 PanelView 600 is a field-proven Human-Machine Interface (HMI) terminal deployed across a wide range of industrial environments where reliable operator interaction and real-time process visualization are critical:
- Discrete Manufacturing Lines — Automotive assembly, packaging machinery, and conveyor control panels requiring color status feedback and keypad entry.
- Food & Beverage Processing — Wash-down-adjacent control stations where a compact, sealed HMI reduces operator error and improves line throughput.
- Water & Wastewater Treatment — SCADA-adjacent local operator panels for pump stations, valve control, and alarm acknowledgment.
- Oil & Gas Upstream/Midstream — Remote skid-mounted control panels where a standalone HMI provides local override and status display without a full SCADA workstation.
- Material Handling & Palletizing — Integrated into PLC-controlled sorter and palletizer systems for recipe selection and fault diagnostics.
- HVAC & Building Automation — Chiller plant and air-handling unit control panels requiring a compact touchscreen with keypad backup.
Technical Specifications
| Part Number | 2711-B6C5 |
| Brand / Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | PanelView 600 |
| Display Size | 6-inch Color STN LCD |
| Input Type | Touch Screen + Keypad (Combination) |
| Resolution | 320 × 240 pixels (QVGA) |
| Communication Protocol | DH-485 / RS-232 (DF1) |
| Power Supply | 24 VDC |
| Operating Temperature | 0 °C to 55 °C (32 °F to 131 °F) |
| Storage Temperature | -20 °C to 70 °C |
| Enclosure Rating | NEMA 4/4X, 12, 13 (front face) |
| Memory | 512 KB Application Memory |
| Weight | Approx. 2.3 kg |
| Catalog Number | 2711-B6C5 |
Why Engineers Specify This Model
- Dual Input Redundancy — The combination of touch screen and physical keypad ensures operators can interact with the panel even in gloved-hand environments or when the touch surface is contaminated.
- Color Display for Alarm Differentiation — Color coding of process states (green/yellow/red) reduces operator response time versus monochrome alternatives.
- Native DH-485 Integration — Direct communication with SLC 500 and MicroLogix PLCs without additional gateway hardware, reducing BOM cost and panel footprint.
- NEMA 4/4X Front-Face Rating — Suitable for wash-down and dust-laden environments without additional enclosure engineering.
- PanelBuilder 32 Compatibility — Widely supported by existing engineering teams; no retraining required for facilities already using Rockwell software.
- Proven Field Longevity — Thousands of units remain in active service globally, with a robust aftermarket supply chain for spares and replacements.
Complete System Bill of Materials
For a complete PanelView 600 operator station, engineers typically specify the following alongside the 2711-B6C5:
- PLC Controller — Allen-Bradley SLC 5/03, 5/04, or MicroLogix 1100/1400 (DH-485 port required)
- Communication Cable — 1747-CP3 (DH-485 to RS-232 adapter) or 2711-NC13 (PanelView to SLC cable)
- Power Supply — 24 VDC panel power supply (e.g., 1606-XLP95E or equivalent)
- Panel Cutout Hardware — Stainless mounting studs and gasket kit per 2711-B6C5 installation drawing
- Programming Software — PanelBuilder 32 (v3.83 or later) for application development and transfer
- Memory Card (optional) — 2711-NM3 for application backup and rapid replacement
Compliance & Industry Standards
- UL Listed (UL 508)
- CE Marked — EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU
- NEMA 4, 4X, 12, 13 (front panel)
- RoHS Compliant
- Manufactured under ISO 9001 Quality Management System
Quality Assurance & Sourcing
At Konmask, every 2711-B6C5 unit is subject to a documented incoming inspection process before dispatch:
- Visual Inspection — Housing integrity, connector condition, label legibility, and screen surface check.
- Power-On Verification — Unit is powered at 24 VDC to confirm display initialization and keypad response.
- Communication Port Test — DH-485 and RS-232 ports verified with loopback or live PLC connection where applicable.
- Traceability — Serial number and firmware revision recorded against each order for full supply chain traceability.
- Packaging — Anti-static bag, foam-lined carton, and moisture-barrier seal for international shipment.
Units are sourced from authorized distributors, certified resellers, and verified industrial surplus channels. Counterfeit-risk screening is applied to all non-OEM supply paths.
How to Source This Part
- Add to Cart — Click the purchase button above to place an order directly through Konmask.com.
- Request a Quote — For volume orders (5+ units), OEM replacement programs, or project-based procurement, contact support@konmask.com for a formal quotation within 24 hours.
- Lead Time — In-stock units ship within 1–3 business days. Out-of-stock units are subject to sourcing lead time; contact us for current availability.
- Export & Customs — We support international shipments with full commercial invoice, packing list, and HS code documentation. Contact us for export compliance requirements specific to your destination country.
Application-Specific FAQ
Q: Is the 2711-B6C5 compatible with ControlLogix or CompactLogix PLCs?
A: Not natively. The 2711-B6C5 communicates via DH-485 and RS-232 (DF1), which are native to SLC 500 and MicroLogix families. For ControlLogix/CompactLogix integration, consider the PanelView Plus series (e.g., 2711P) with EtherNet/IP support.
Q: Can I reuse an existing PanelBuilder 32 application on a replacement 2711-B6C5?
A: Yes. Applications developed in PanelBuilder 32 are transferable to any compatible PanelView 600 unit via RS-232 download cable or memory card (2711-NM3).
Q: What is the difference between 2711-B6C5 and 2711-B6C8?
A: The suffix digit indicates the communication protocol variant. The -C5 uses DH-485; the -C8 uses RS-232 (DF1 Full-Duplex). Verify your PLC’s available communication port before ordering.
Q: Is this unit suitable for hazardous (classified) locations?
A: The standard 2711-B6C5 is not rated for Class I Division 1 or ATEX Zone 1 environments. For hazardous location applications, a purged/pressurized enclosure or an intrinsically safe barrier system is required.
Q: Do you offer a warranty on this unit?
A: Yes. Konmask provides a 90-day functional warranty on all verified units. Extended warranty and exchange programs are available for volume customers — contact us for details.
