Allen-Bradley 2711-T9C1X PanelView 900 Touch Terminal | Replacement, Equivalent & Selection Guide
The Allen-Bradley 2711-T9C1X is a 9-inch color touch screen operator interface terminal from Rockwell Automation’s PanelView 900 series, powered by 100–240V AC. Designed for demanding industrial environments, it provides a reliable human-machine interface (HMI) for machine control, process monitoring, and operator interaction. This page serves as a comprehensive selection, replacement, and compatibility reference for procurement engineers and automation system integrators.
Technical Specifications
- Part Number: 2711-T9C1X
- Brand / Manufacturer: Allen-Bradley (Rockwell Automation)
- Series: PanelView 900
- Display Type: 9-inch Color Touch Screen (CRT)
- Input Interface: Touch Screen
- Power Supply: 100–240V AC, 50/60 Hz
- Communication Ports: RS-232 / RS-422 / DH-485 (model-dependent)
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Storage Temperature: –40°C to 85°C
- Protection Rating: NEMA 4/4X, 12, 13 (front panel)
- Programming Software: PanelBuilder 1400e / RSView ME
- Weight: Approx. 3.6 kg
- Certifications: UL, CE, CSA
Compatible Replacement & Equivalent Models
When the 2711-T9C1X is discontinued or unavailable, the following models are commonly evaluated as functional replacements or equivalents. Always verify communication protocol and panel cutout dimensions before substitution.
- 2711P-T9C4D8 – PanelView Plus 900, 9″ color touch, DC power; direct functional upgrade with enhanced processing
- 2711P-T9C4A8 – PanelView Plus 900, 9″ color touch, AC power; closest AC-powered modern equivalent
- 2711P-T9W22D9P – PanelView Plus 7 Standard, 9″ widescreen touch; next-generation replacement
- 2711-T9C3 – Same series, DH+ communication variant; verify protocol compatibility
- 2711-T9C16 – Same series, ControlNet communication variant
- 2711-T9C1L1 – Same series, alternate firmware/language variant
- Siemens TP900 Comfort (6AV2124-0JC01-0AX0) – Cross-brand equivalent for mixed-fleet environments (requires application re-engineering)
Note: Cross-brand replacements require application migration. Konmask recommends consulting your system integrator before substituting with non-AB hardware.
Why Choose the Original Model
- Drop-in compatibility: Identical panel cutout and mounting footprint — no mechanical modification required
- Protocol continuity: Native DH-485 / RS-232 communication preserves existing PLC wiring and ladder logic
- Proven field reliability: Thousands of units deployed globally in automotive, food & beverage, and discrete manufacturing
- Minimal re-commissioning: Existing PanelBuilder application files transfer directly without re-programming
- Regulatory compliance: Maintains UL/CE certification status for validated production lines
Typical Applications
- Discrete manufacturing machine control panels
- Conveyor and material handling system HMI stations
- Packaging line operator interfaces
- Automotive assembly line control terminals
- Water/wastewater treatment process monitoring
- HVAC and building automation control panels
- Oil & gas upstream/midstream skid-mounted control systems
System Compatibility
The 2711-T9C1X is designed to integrate with the following Rockwell Automation control platforms:
- PLC-5 series (via DH+/DH-485)
- SLC 500 series (via DH-485 / RS-232 DF1)
- MicroLogix 1000 / 1100 / 1200 / 1500 (via RS-232 DF1)
- ControlLogix / CompactLogix (via serial bridge or gateway adapter)
- Third-party PLCs via RS-232 generic ASCII protocol (with custom driver)
Selection Guide
Use the following criteria to confirm the 2711-T9C1X is the correct model for your application, or to select an appropriate alternative:
- Power source: Confirm 100–240V AC availability at the panel. If DC-only, consider 2711-T9C1 (DC variant) or 2711P-T9C4D8.
- Communication protocol: Match to your PLC network — DH-485, RS-232 DF1, DH+, or ControlNet.
- Display size: 9″ is standard for mid-size panels. For smaller enclosures, consider 2711-T6C1X (6″); for larger, 2711-T12C1X (12″).
- Application software: Existing PanelBuilder 1400e files are directly compatible. Migration to PanelView Plus requires RSView ME conversion.
- Environmental rating: NEMA 4/4X suitable for washdown and dust environments. Confirm gasket integrity on refurbished units.
- Lifecycle status: 2711-T9C1X is end-of-life (EOL). For new installations, Konmask recommends PanelView Plus 7 (2711P series) for long-term support.
Quality Assurance & Sourcing
- Source: Authorized distributor stock, surplus OEM inventory, and certified refurbished units
- Inspection: Each unit undergoes functional power-on test, display verification, and communication port check prior to shipment
- Warranty: 12-month replacement warranty on all units shipped by Konmask
- Traceability: Serial number and firmware version documented for every order
- Packaging: Anti-static ESD packaging with foam cushioning; export carton rated for international freight
- Lead time: In-stock units ship within 1–3 business days; sourced units 5–15 business days
How to Order
- Confirm your part number: 2711-T9C1X (or specify your required variant/replacement model)
- Specify quantity and required delivery timeline
- Contact Konmask via email or phone for a formal quotation
- Submit purchase order — we accept T/T wire transfer, PayPal, and major credit cards
- Receive order confirmation with tracking number within 24 hours of payment
📧 support@konmask.com | 📞 +0086 19859288691
Replacement & Compatibility FAQ
Q: Is the 2711-T9C1X still in production?
A: No. This model is end-of-life (EOL). Konmask supplies new-surplus and certified refurbished stock. For new projects, we recommend the PanelView Plus 7 series.
Q: Can I use a 2711P-T9C4A8 as a direct replacement?
A: The panel cutout dimensions are similar but not identical. Application files must be converted using RSView ME Studio. Communication wiring may require adapter cables.
Q: What is the difference between 2711-T9C1X and 2711-T9C1?
A: The “X” suffix typically denotes an export/international firmware variant with multi-language support. Core hardware and communication are identical.
Q: Do you provide a warranty on refurbished units?
A: Yes — all units carry a 12-month replacement warranty. Defective units are replaced at no charge within the warranty period.
Q: Can Konmask source other PanelView models not listed here?
A: Yes. Contact us with your part number and we will provide availability and pricing within 24 hours.
