HMI Network Communication Solution – Allen-Bradley 2711P-RN6 | PanelView Plus Series
The Allen-Bradley 2711P-RN6 is a dedicated communication module engineered for PanelView Plus HMI terminals, enabling seamless integration into EtherNet/IP and ControlNet industrial networks. Designed for demanding factory-floor environments, this module extends the connectivity of PanelView Plus 6 and PanelView Plus terminals, allowing engineers to build robust, real-time operator interface systems across distributed control architectures.
Where This Product Is Used
The 2711P-RN6 is deployed across a wide range of industrial automation environments where reliable HMI-to-controller communication is mission-critical:
- Automotive Assembly Lines — Operator panels communicating with ControlLogix PLCs for real-time process monitoring and fault acknowledgment.
- Food & Beverage Processing Plants — HMI terminals networked over EtherNet/IP for recipe management, batch control, and CIP cycle visualization.
- Water & Wastewater Treatment Facilities — Remote operator stations connected to CompactLogix controllers for pump control and alarm management.
- Oil & Gas Upstream/Midstream — Panel terminals in hazardous-area enclosures requiring reliable network communication to SCADA-integrated PLCs.
- Pharmaceutical Manufacturing — GMP-compliant HMI systems requiring validated, deterministic network communication for batch record integrity.
- Material Handling & Conveyor Systems — Distributed HMI nodes across conveyor lines communicating with Logix-family controllers.
- Power Generation & Utilities — Substation and turbine control rooms using PanelView Plus terminals for operator interface.
Technical Specifications
- Part Number: 2711P-RN6
- Manufacturer: Allen-Bradley / Rockwell Automation
- Product Family: PanelView Plus Communication Module
- Compatible Terminals: PanelView Plus 6, PanelView Plus (2711P series)
- Network Protocol: EtherNet/IP
- Communication Standard: IEEE 802.3 (10/100 Mbps)
- Connector Type: RJ-45
- Module Form Factor: Plug-in communication card for PanelView Plus terminal
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Humidity: 5% to 95% non-condensing
- Weight: Approx. 600 g (module + packaging)
- Certifications: CE, UL, cUL
- Country of Origin: USA / Mexico (Rockwell Automation manufacturing)
Why Engineers Specify This Model
- Native EtherNet/IP Integration — Plug-and-play compatibility with the entire Logix controller family (ControlLogix, CompactLogix, GuardLogix) without additional configuration gateways.
- Deterministic Communication — Supports CIP (Common Industrial Protocol) for real-time, deterministic data exchange critical in process and discrete manufacturing.
- Hot-Swap Capable — Module can be replaced without full terminal disassembly, minimizing downtime during maintenance windows.
- Rockwell Ecosystem Compatibility — Fully supported within Studio 5000 / FactoryTalk View ME environment, ensuring seamless tag browsing and diagnostics.
- Long Product Lifecycle — Rockwell Automation’s extended lifecycle support policy ensures spare parts availability for installed base protection.
- Compact Form Factor — Designed to fit within the PanelView Plus terminal housing without external wiring or additional panel space.
Complete System Bill of Materials
For a complete PanelView Plus networked HMI system, engineers typically specify the following alongside the 2711P-RN6:
- PanelView Plus Terminal — e.g., 2711P-T10C4D8 (10″ color touch), 2711P-T7C4D8 (7″ color touch)
- ControlLogix / CompactLogix PLC — e.g., 1756-L71, 1769-L33ER
- EtherNet/IP Managed Switch — e.g., Stratix 5700 (1783-BMS10CGP)
- 24VDC Power Supply — e.g., 1606-XLP95E
- Panel Enclosure — NEMA 12 or IP54-rated steel enclosure
- Cat5e / Cat6 Industrial Ethernet Cable — Shielded, rated for flex/drag chain if required
- FactoryTalk View ME Software License — For HMI application development
Compliance & Industry Standards
- CE Marking — Compliant with EU Low Voltage Directive and EMC Directive
- UL / cUL Listed — Recognized for use in North American industrial installations
- EtherNet/IP Conformance — ODVA-conformant CIP implementation
- RoHS Compliant — Restriction of Hazardous Substances Directive
- IEC 61131 — Compatible with IEC 61131-3 compliant controller environments
- ATEX / IECEx — Consult factory for hazardous location variants
Quality Assurance & Sourcing
Konmask.com sources the 2711P-RN6 through verified industrial automation distributors and authorized channel partners. Every unit undergoes the following before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition
- Verification of manufacturer date codes and firmware revision markings
- Anti-static packaging with humidity indicator cards for long-term storage protection
- Documentation package: datasheet, declaration of conformity, and packing list
We do not source from grey-market or unverified secondary channels. All stock is traceable to authorized distribution.
How to Source This Part
- In-Stock Orders: Add to cart and complete checkout — standard lead time 1–3 business days for domestic CN shipments.
- International Orders: Contact us for DDP/DAP pricing, export documentation, and freight options.
- Bulk / Project Quantities: Request a formal quotation via email for volume pricing and reserved allocation.
- Urgent Requirements: Call or WhatsApp +0086 19859288691 for same-day quotation and expedited shipping options.
- OEM / System Integrator Accounts: Inquire about NET-30 terms and dedicated account management.
Application-Specific FAQ
Q: Is the 2711P-RN6 compatible with PanelView Plus 7 terminals?
A: The 2711P-RN6 is designed for the PanelView Plus and PanelView Plus 6 (2711P) series. PanelView Plus 7 terminals (2711R series) use a different communication architecture. Verify your terminal catalog number before ordering.
Q: Can this module communicate with non-Rockwell PLCs?
A: The 2711P-RN6 uses EtherNet/IP (CIP). While EtherNet/IP is an open standard, FactoryTalk View ME is optimized for Logix-family controllers. Third-party PLC connectivity may require additional configuration or gateway devices.
Q: Does the module support redundant network topologies?
A: The 2711P-RN6 provides a single EtherNet/IP port. For redundant network topologies (DLR — Device Level Ring), a managed switch with ring protocol support (e.g., Stratix 5700) is required at the network level.
Q: What firmware version is required on the PanelView Plus terminal?
A: Refer to Rockwell Automation’s compatibility matrix (Publication 2711P-TD001). Generally, FactoryTalk View ME v5.0 or later is recommended for full feature support with this module.
Q: Is this a new or refurbished unit?
A: Konmask.com stocks both new (factory-sealed) and professionally refurbished units. Product listing will specify condition. Contact us if you require new-only supply for warranty or compliance purposes.
Q: What is the warranty on this module?
A: New units carry Rockwell Automation’s standard 1-year limited warranty. Konmask.com additionally provides a 90-day functional guarantee on all shipped units.
