Allen-Bradley 80190-380-02-R Signal Conditioning Board | Replacement, Equivalent & Selection Guide
The Allen-Bradley (AB) 80190-380-02-R is a Signal Conditioning Board designed for use in industrial automation and process control systems. This board conditions raw analog signals from field sensors into clean, stable signals suitable for PLC and DCS processing. Konmask.com supplies both original and verified-equivalent units, backed by rigorous sourcing and quality inspection.
Technical Specifications
- Part Number: 80190-380-02-R
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Product Type: Signal Conditioning Board
- Function: Analog signal conditioning for industrial control systems
- Weight: 320 g (approx.)
- Compatibility: Allen-Bradley PLC / DCS platforms (see System Compatibility below)
- Condition Available: New, Refurbished, Tested Used
- Lead Time: In-stock units ship within 1–3 business days
Note: Full datasheet available upon request. Contact support@konmask.com for detailed electrical specifications.
Compatible Replacement & Equivalent Models
If the 80190-380-02-R is discontinued, on long lead time, or outside budget, the following models may serve as functional equivalents depending on your system configuration. Always verify electrical and mechanical compatibility before substitution.
- 80190-380-01-R — Earlier revision; verify firmware compatibility
- 80190-380-03-R — Later revision; may offer enhanced noise immunity
- 1771-IFE — Allen-Bradley analog input module with signal conditioning capability (verify channel count and range)
- 1746-NI4 — SLC 500 series analog input; suitable for lower-density applications
- Third-party equivalents — Available on request; Konmask evaluates pin-compatibility and signal range on a case-by-case basis
⚠ Disclaimer: Replacement suitability depends on your specific system architecture. Konmask’s technical team can assist with compatibility verification — contact us before ordering a substitute.
Why Choose the Original Model
- OEM-certified performance: Designed and validated by Rockwell Automation for precise signal fidelity
- Drop-in replacement: No firmware changes or re-wiring required when replacing like-for-like
- Long service life: Industrial-grade components rated for harsh environments
- Warranty & traceability: Original units come with full manufacturer traceability documentation
- Reduced commissioning risk: Eliminates compatibility unknowns associated with third-party substitutes
Typical Applications
- Process manufacturing: chemical, petrochemical, and pharmaceutical plants
- Power generation and utilities
- Water and wastewater treatment facilities
- Automotive and discrete manufacturing lines
- Oil & gas upstream and downstream control systems
- Building automation and HVAC control panels
System Compatibility
The 80190-380-02-R is designed for integration within Allen-Bradley control architectures. Verified compatible platforms include:
- Allen-Bradley PLC-5 series
- Allen-Bradley SLC 500 series (with appropriate adapter)
- Rockwell Automation ControlLogix / CompactLogix (via legacy bridge modules)
- Third-party DCS systems with standard analog I/O backplanes (verify signal range and connector type)
Contact Konmask for cross-platform compatibility assessment if your system is not listed above.
Selection Guide
Use the following criteria to determine whether the 80190-380-02-R is the right choice for your application:
- Signal type: Confirm your field sensors output signals within the board’s accepted range (4–20 mA / 0–10 V typical — verify with datasheet)
- Channel count: Match the number of input channels to your I/O requirements
- Revision level: Check your existing system’s revision to ensure backward compatibility (-R suffix denotes a specific hardware revision)
- Environment rating: Confirm operating temperature and humidity ratings match your installation environment
- Redundancy needs: For critical loops, consider ordering a spare unit simultaneously
- Budget vs. risk: Original OEM units minimize integration risk; refurbished units offer cost savings with tested performance
Quality Assurance & Sourcing
All units supplied by Konmask.com undergo the following process:
- Source verification: Procured from authorized distributors, OEM surplus, or certified refurbishers
- Visual inspection: Board-level inspection for physical damage, corrosion, and component integrity
- Functional testing: Powered bench test where applicable; results documented
- Anti-static packaging: Shipped in ESD-safe bags with protective foam
- Documentation: Test reports and sourcing certificates available on request
How to Order
- Add the 80190-380-02-R to your cart and proceed to checkout, or
- Contact us directly for bulk orders, custom lead times, or compatibility consultation:
- 📧 Email: support@konmask.com
- 📞 Phone/WhatsApp: +0086 19859288691
- 🌐 Website: https://Konmask.com
Please provide your PLC/DCS model, application description, and required quantity when inquiring for fastest response.
Replacement & Compatibility FAQ
Q: Can I use the 80190-380-02-R as a direct replacement for the -01-R revision?
A: In most cases yes, but verify firmware and backplane connector compatibility with your system documentation or contact Konmask for confirmation.
Q: Do you supply refurbished units?
A: Yes. All refurbished units are bench-tested and inspected. Condition is clearly stated in the listing and on the invoice.
Q: What is the lead time for out-of-stock units?
A: Typically 5–15 business days depending on sourcing. Contact us for a firm lead time quote.
Q: Can Konmask help identify a compatible third-party replacement?
A: Yes. Our technical team evaluates signal range, connector type, and channel count to recommend validated alternatives.
Q: Is a warranty provided?
A: New OEM units carry manufacturer warranty. Refurbished and tested-used units carry a 90-day Konmask functional warranty.
