Allen-Bradley 80190-560-02-R Analog Input Board | Replacement, Equivalent & Selection Guide
The Allen-Bradley (AB) 80190-560-02-R is a precision analog input board designed for industrial control systems requiring reliable signal acquisition and processing. This page provides full technical specifications, verified compatible replacements, and a structured selection guide to help engineers and procurement teams make confident sourcing decisions.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 80190-560-02-R |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Module Type | Analog Input Board |
| Signal Type | Analog Input (voltage / current) |
| Form Factor | Board-level module |
| Weight | Approx. 200 g |
| Condition Available | New, Refurbished, Tested |
| Compliance | CE, RoHS (verify with datasheet) |
Note: Full electrical specifications (input range, resolution, channel count, isolation) are available upon request. Contact our technical team for the official datasheet.
Compatible Replacement & Equivalent Models
When the original 80190-560-02-R is unavailable or discontinued, the following models may serve as functional equivalents depending on your system configuration. Always verify pin-out, signal range, and firmware compatibility before substitution.
- Allen-Bradley 1746-NI4 – 4-channel analog input module; compatible with SLC 500 series; verify signal range match
- Allen-Bradley 1756-IF8 – ControlLogix 8-channel analog input; suitable for higher-density applications
- Allen-Bradley 1769-IF4 – CompactLogix 4-channel analog input; compact form factor alternative
- Third-party equivalents – Contact Konmask for vetted cross-reference options with full compatibility documentation
⚠ Important: Replacement suitability depends on your specific PLC platform, backplane, and software version. Konmask’s technical team can assist with cross-reference validation at no charge.
Why Choose the Original Model
- Guaranteed compatibility – Drop-in fit for existing Allen-Bradley control architectures without firmware or wiring changes
- Validated signal integrity – Factory-calibrated analog input channels ensure measurement accuracy from day one
- Reduced commissioning risk – No re-engineering or re-validation required in regulated or safety-critical environments
- Long-term spare parts strategy – Stocking original parts protects against future obsolescence and unplanned downtime
- OEM documentation support – Full Rockwell Automation documentation, wiring diagrams, and firmware notes available
Typical Applications
- Process control systems requiring analog signal acquisition (temperature, pressure, flow, level)
- Manufacturing automation lines with multi-channel sensor integration
- Oil & gas, chemical, and water treatment plant control panels
- HVAC and building management systems using Allen-Bradley PLCs
- Machine tool and motion control applications with analog feedback loops
- Legacy system maintenance and MRO (Maintenance, Repair & Operations) sourcing
System Compatibility
- PLC Platforms: Allen-Bradley / Rockwell Automation control systems (verify specific series with Konmask)
- Software: RSLogix / Studio 5000 (version compatibility to be confirmed per installation)
- Backplane: Compatible with standard Allen-Bradley backplane configurations for this board series
- Communication: Integrates with existing I/O trees; no additional gateway required in native AB environments
Selection Guide
Use the following decision framework to determine whether the 80190-560-02-R is the right choice for your application:
- Step 1 – Confirm your PLC platform: Identify the exact Allen-Bradley PLC series and chassis in your system.
- Step 2 – Verify channel requirements: Determine the number of analog input channels needed and the signal type (0–10 V, 4–20 mA, thermocouple, RTD).
- Step 3 – Check resolution needs: Match the required measurement resolution (12-bit, 16-bit) to your process accuracy requirements.
- Step 4 – Assess isolation requirements: Determine if channel-to-channel or channel-to-backplane isolation is required for your application.
- Step 5 – Evaluate replacement vs. original: If the original is available, prefer it for zero-risk integration. If substituting, request Konmask’s compatibility report.
- Step 6 – Request a quote: Contact Konmask with your PLC model, application details, and required quantity for a tailored sourcing recommendation.
Quality Assurance & Sourcing
- Multi-source procurement: Konmask maintains relationships with authorized distributors, OEM surplus channels, and certified refurbishers globally.
- Inspection protocol: All units undergo visual inspection, functional testing, and packaging integrity checks before dispatch.
- Traceability: Batch records and sourcing documentation available for regulated industries upon request.
- Warranty: Standard 90-day warranty on tested units; extended warranty options available — contact us for details.
- Anti-counterfeit measures: Konmask employs component authentication checks to screen for counterfeit or remarked parts.
How to Order
- Online: Add to cart directly on this page and proceed to checkout.
- Email RFQ: Send your part number, quantity, and required delivery timeline to support@konmask.com.
- Phone / WhatsApp: Call or message +0086 19859288691 for urgent requirements or technical pre-sales consultation.
- Bulk / Project orders: Request a formal quotation with volume pricing, lead time, and logistics options.
- Export orders: Konmask supports international shipping with full export documentation (commercial invoice, packing list, COO).
Replacement & Compatibility FAQ
Q: Is the 80190-560-02-R still in production?
A: This part may be in limited production or available through surplus channels. Contact Konmask to confirm current stock and lead time.
Q: Can I use a 1746-NI4 as a direct replacement?
A: The 1746-NI4 is a potential functional equivalent for SLC 500 platforms, but wiring, configuration, and software mapping must be verified. Konmask can provide a compatibility assessment.
Q: Do you supply refurbished units?
A: Yes. All refurbished units are tested to functional specification and clearly labeled. New and refurbished options are available — specify your preference when ordering.
Q: Can you provide a certificate of conformance?
A: Yes, certificates of conformance and test reports are available for quality-critical procurement. Request at time of order.
Q: What is your typical lead time?
A: In-stock items ship within 1–3 business days. Out-of-stock items are sourced within 5–15 business days depending on global availability.
Q: Do you accept returns?
A: Yes, within 30 days for unused items in original condition. Tested/refurbished units are covered under our 90-day warranty policy.
