Allen-Bradley 2711P-T15C21D8S – 15″ Touch HMI Terminal | PanelView Plus 7 Standard Platform
Engineering Background
The Allen-Bradley 2711P-T15C21D8S is part of Rockwell Automation’s PanelView Plus 7 Standard series — a mature, field-proven HMI platform widely deployed across discrete manufacturing, process control, and infrastructure applications. Designed to integrate natively with Logix-based control architectures, this terminal delivers deterministic visualization performance with a robust industrial-grade enclosure.
Product Positioning
Targeting automation engineers and MRO procurement teams, the 2711P-T15C21D8S occupies the large-format tier of the PanelView Plus 7 Standard lineup. Its 15-inch widescreen touch display, dual-port EtherNet/IP connectivity, and FactoryTalk View ME runtime make it the preferred choice for operator stations requiring high information density and reliable network integration in demanding plant-floor environments.
Complete Technical Specifications
| Part Number | 2711P-T15C21D8S |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Series | PanelView Plus 7 Standard |
| Display Size | 15.0″ Widescreen TFT LCD |
| Display Resolution | 1024 × 768 (XGA) |
| Touch Technology | Analog Resistive Touch Screen |
| Keypad | Touch-only (no function keys) |
| Processor | 800 MHz ARM Cortex-A8 |
| RAM | 512 MB DDR3 |
| Flash Storage | 512 MB internal + SD card slot |
| Operating System | Windows CE 6.0 |
| HMI Runtime | FactoryTalk View Machine Edition (ME) |
| Communication Ports | 2× EtherNet/IP (10/100 Mbps, dual-port switch), 1× USB Type-A, 1× USB Type-B |
| Serial | RS-232 (DH-485 / DF1 via adapter) |
| Input Voltage | 24V DC (18–32V DC operating range) |
| Power Consumption | ≤ 40 W typical |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -20 °C to +70 °C |
| Relative Humidity | 5–95% non-condensing |
| Ingress Protection | IP65 / NEMA 4/4X (front face) |
| Vibration Rating | IEC 60068-2-6: 5–500 Hz, 2G |
| Shock Rating | IEC 60068-2-27: 15G, 11 ms |
| Certifications | UL, CE, RCM, cULus |
| Panel Cutout | Refer to Rockwell Automation Installation Instructions 2711P-IN006 |
| Mounting | Panel mount (front-of-panel installation) |
| Catalog Weight | Approx. 3.2 kg (unit only) |
Proven Application Environments
- Discrete Manufacturing: Automotive assembly lines, machine tool operator stations, robotic cell HMI panels
- Process Industries: Water/wastewater SCADA operator interfaces, chemical batch control, oil & gas skid panels
- Food & Beverage: Washdown-adjacent operator stations (IP65 front face), packaging line control
- Material Handling: Conveyor system supervisory displays, warehouse automation control panels
- Infrastructure: Building automation, power distribution monitoring, utility control rooms
- MRO Replacement: Direct drop-in replacement for legacy PanelView Plus 6 / Plus 7 installations with matching catalog footprint
Engineering Advantages
- Native EtherNet/IP Integration: Dual-port switch topology eliminates the need for external managed switches in linear device-level ring (DLR) or star topologies — reducing panel BOM cost and wiring complexity.
- FactoryTalk View ME Ecosystem: Full compatibility with Studio 5000 Logix Designer tag import, enabling direct controller tag browsing and reducing HMI programming time by eliminating manual tag re-entry.
- Large-Format Visualization: 15″ XGA display supports high-density faceplates, trend displays, and alarm summaries without operator scrolling — critical for complex process overview screens.
- IP65 Front Face: Sealed against dust ingress and water jets — suitable for washdown-adjacent environments without additional enclosure modifications.
- Proven Platform Longevity: PanelView Plus 7 Standard is an established Rockwell platform with broad integrator familiarity, reducing commissioning risk and training overhead.
- USB Peripheral Support: Type-A port supports USB barcode scanners, keyboards, and USB drives for recipe/data transfer without network dependency.
System Architecture & Signal Flow
The 2711P-T15C21D8S operates as an EtherNet/IP Class 1 implicit messaging client, polling ControlLogix, CompactLogix, or Micro800 controllers at configurable RPI rates. The dual-port Ethernet switch allows daisy-chain wiring to adjacent devices, supporting both star and linear topologies. FactoryTalk View ME applications are developed offline in Studio 5000 View Designer or FactoryTalk View Studio and downloaded via USB or Ethernet. Runtime tag updates are handled via CIP (Common Industrial Protocol) with configurable update rates per display element. The USB Type-B port provides a direct PC connection for application download and terminal diagnostics without requiring network access.
Sourcing & Quality Verification
- All units sourced from authorized distributors, certified surplus channels, or verified OEM overstock — no grey-market or counterfeit supply chains.
- Each unit undergoes incoming inspection: visual check, firmware version verification, and power-on functional test prior to listing.
- Original Rockwell Automation firmware retained; no unauthorized modifications.
- Units shipped with original accessories where available (mounting hardware, terminal block connectors).
- Certificate of conformance (CoC) available upon request for regulated industries.
- Traceability documentation available for MRO and OEM procurement requirements.
Procurement Process
- Confirm Part Number: Verify 2711P-T15C21D8S matches your panel cutout dimensions and communication requirements against Rockwell Automation catalog 2711P-TD001.
- Request Quote: Contact [email protected] for volume pricing, lead time confirmation, and availability of accessories.
- Place Order: Purchase directly via Konmask.com checkout or via PO for B2B accounts (net terms available upon credit approval).
- Shipping: Units ship within 1–3 business days from Hong Kong. DHL Express, FedEx International Priority, and sea freight options available. Export documentation (commercial invoice, packing list, COO) provided.
- Incoming Inspection: Recommend verifying firmware version and performing power-on test upon receipt before panel installation.
Technical FAQ
Q: Is this unit compatible with FactoryTalk View ME v10 and later?
A: Yes. The 2711P-T15C21D8S supports FactoryTalk View ME v6.0 through the latest available version. Firmware updates are available via Rockwell Automation’s Product Compatibility and Download Center (PCDC).
Q: Can this terminal communicate with non-Rockwell PLCs?
A: Yes, via the RS-232 serial port using DF1 or DH-485 protocols, or via third-party EtherNet/IP drivers. Modbus TCP communication requires a third-party driver add-on.
Q: What is the difference between the 2711P-T15C21D8S and the 2711P-T15C22D8S?
A: The suffix digit indicates the display brightness tier. The -T15C21D8S is the standard brightness variant; the -T15C22D8S is the high-brightness variant for high-ambient-light environments. Verify your application’s ambient light conditions before selecting.
Q: Is a replacement backlight available?
A: The PanelView Plus 7 Standard uses an LED backlight assembly. Replacement is a depot-level repair; contact Rockwell Automation Repair Services or a certified repair center.
Q: What warranty applies to surplus units?
A: Konmask provides a 90-day functional warranty on all surplus units. Extended warranty options are available upon request. New-in-box units carry the original Rockwell Automation warranty where applicable.
