ABB 2N1408 DSQC624 3HAC020150-001 3HAC025562-001 Bell Cup D50 916102 – High-Speed Rotary Atomizer for ABB IRC5 Painting Robot System
When a Bell Cup fails mid-production on an automotive painting line, the consequences are immediate and costly: uneven coating, paint defects, unplanned downtime, and scrapped body panels. In high-throughput environments where a single painting robot handles hundreds of units per shift, even a 30-minute stoppage can cascade into thousands of dollars in lost output. The ABB Bell Cup D50 (Part No. 916102) is the precision rotary atomizer at the heart of ABB’s painting robot system — without it, the entire spray process halts.
The ABB 2N1408 / DSQC624 / 3HAC020150-001 / 3HAC025562-001 Bell Cup D50 916102 is a factory-specification rotary atomizer designed exclusively for ABB IRC5-series painting robots. With a 50mm bell diameter optimized for fine-finish automotive and industrial coating applications, this component occupies a critical position in ABB’s global painting automation ecosystem — deployed across automotive OEM plants, tier-1 suppliers, and general industrial coating lines worldwide. Its precision-balanced titanium alloy construction and high-RPM capability make it one of the most specified bell cups in the industry.
Technical Specifications
- Part Numbers: 2N1408 / DSQC624 / 3HAC020150-001 / 3HAC025562-001 / 916102
- Bell Cup Diameter: D50 (50 mm)
- Compatible System: ABB IRC5 Painting Robot (e.g., IRB 5500, IRB 5400, IRB 580)
- Application: High-speed rotary atomization for liquid paint / coating
- Material: Precision-machined titanium alloy (OEM specification)
- Weight: 420 g
- Condition: New / Refurbished (specify on inquiry)
- Origin: ABB OEM / Authorized Supply Chain
Key Features & Benefits
- OEM-Matched Geometry: Exact D50 bell profile ensures consistent atomization angle and droplet size distribution, maintaining coating quality standards.
- High-RPM Stability: Precision-balanced for operation at 10,000–60,000 RPM without vibration-induced coating defects.
- Corrosion & Solvent Resistance: Titanium alloy construction withstands aggressive solvent-borne and waterborne paint chemistries.
- Drop-In Replacement: Direct fit for ABB IRC5 painting robot applicator heads — no modification required.
- Reduced Downtime: Stocking this part eliminates multi-week OEM lead times during emergency breakdowns.
- Traceable Supply: Each unit sourced through verified channels with documentation available on request.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white painting lines, bumper coating, interior trim finishing at OEM and tier-1 plants.
- General Industrial Coating: Appliance, furniture, and metal component painting with ABB IRC5 robots.
- Aerospace Surface Treatment: Precision coating applications requiring tight film thickness control.
- Compatible Robot Models: ABB IRB 5500, IRB 5400, IRB 580, IRB 52 (painting variants with IRC5 controller).
System Integration & Compatible Parts
The Bell Cup D50 916102 integrates with the ABB IRC5 painting robot applicator assembly. Commonly ordered alongside:
- ABB Turbine Unit / Air Bearing Assembly (IRC5 painting applicator)
- ABB Paint Valve / Needle Valve sets for IRC5
- ABB Shaping Air Ring compatible with D50 bell cups
- ABB DSQC652 / DSQC643 I/O modules for IRC5 controller integration
- ABB 3HAC series servo drive and controller boards
Our Quality Assurance Process
- Source Verification: All parts are sourced from OEM production lines, authorized distributors, or certified refurbishers — never grey-market unknowns.
- Visual & Dimensional Inspection: Each Bell Cup is inspected for surface integrity, thread condition, and dimensional conformance before dispatch.
- Documentation: Test reports, origin certificates, and traceability documents available upon request for quality-critical procurement.
- Packaging: Anti-static, shock-protected packaging to prevent transit damage to precision-machined surfaces.
How to Order
- Submit your inquiry via the Contact / RFQ form on Konmask.com with your required part number and quantity.
- Our technical team confirms availability, condition, and lead time within 24 business hours.
- Receive a formal quotation with pricing, shipping options, and payment terms.
- Confirm order — we arrange secure international shipping with full tracking.
- Parts dispatched with packing list and available documentation.
Contact us: support@konmask.com | +0086 19859288691
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, robot, and automation spare parts — not a generalist marketplace.
- Global B2B Supply: Serving maintenance engineers, procurement teams, and system integrators across 40+ countries.
- Fast Emergency Response: Priority sourcing for urgent breakdown situations — contact us for expedited options.
- Technical Support: Our team includes experienced automation engineers who can assist with part identification and compatibility verification.
- Competitive Pricing: Direct supply chain relationships enable pricing well below typical distributor markups.
Frequently Asked Questions
Q: Is the ABB 3HAC020150-001 the same as 3HAC025562-001?
A: These are related part numbers within the same Bell Cup assembly family for ABB IRC5 painting robots. Please provide your robot model and applicator serial number when inquiring so we can confirm the exact compatible part for your application.
Q: What is the difference between DSQC624 and 2N1408?
A: 2N1408 is the ABB ordering number (catalog reference) while DSQC624 is the module designation. Both refer to the same component in ABB’s parts system.
Q: Can I use a D50 bell cup on a robot currently fitted with a D40 or D70?
A: Bell cup diameter must match the applicator turbine design. Substituting diameters without applicator modification is not recommended. Contact our technical team for guidance.
Q: Do you offer refurbished Bell Cups?
A: Yes. We can supply both new OEM and professionally refurbished units. Refurbished units undergo dimensional inspection and balancing. Please specify your preference in your inquiry.
Q: What is the lead time for ABB 916102 Bell Cup?
A: Lead time depends on current stock. In-stock units ship within 2–5 business days internationally. For out-of-stock items, typical sourcing lead time is 2–4 weeks. Contact us for real-time availability.
Q: Do you ship to [my country]?
A: We ship globally via DHL, FedEx, UPS, and freight forwarders. Contact us with your destination for a shipping quote.
