ABB 3BHE033067R0102 – Digital I/O Module | AC800M / Symphony Plus DCS Platform
Engineering Background
The ABB 3BHE033067R0102 is a high-density digital I/O module engineered for ABB’s AC800M controller family and Symphony Plus distributed control system (DCS) platform. Designed to meet the rigorous demands of continuous process industries, this module provides reliable, deterministic signal handling for both discrete input acquisition and output actuation in safety-critical and production-critical environments.
Product Positioning
As a field-proven I/O card within ABB’s modular DCS architecture, the 3BHE033067R0102 serves as the interface layer between field instrumentation and the AC800M controller. It is the preferred choice for procurement engineers sourcing replacement or expansion I/O capacity in existing ABB DCS installations across power generation, oil & gas, chemical processing, and pulp & paper industries.
Complete Technical Specifications
| Part Number / SKU | 3BHE033067R0102 |
| Manufacturer | ABB Ltd. |
| Product Series | AC800M / Symphony Plus |
| Module Type | Digital I/O Module |
| Form Factor | Rack-mount, DIN-rail compatible |
| Communication Interface | S800 I/O Bus (ModuleBus) |
| Operating Voltage | 24 VDC (nominal) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5% to 95% RH, non-condensing |
| Protection Class | IP20 |
| Weight | Approx. 400 g |
| Certifications | CE, UL, cUL |
| Compatibility | AC800M PM851, PM856, PM860, PM861, PM864, PM866; Symphony Plus S800 I/O |
| Condition Available | New (OEM), Refurbished, Tested Used |
Proven Application Environments
- Power Generation: Turbine control, boiler management, and auxiliary system I/O expansion in coal, gas, and hydro plants.
- Oil & Gas: Wellhead control, pipeline SCADA integration, and compressor station automation.
- Chemical & Petrochemical: Reactor interlock systems, valve position feedback, and batch process sequencing.
- Pulp & Paper: Digester control, bleaching line automation, and machine drive coordination.
- Water & Wastewater: Pump station control, filtration process management, and remote I/O expansion.
- Pharmaceutical: Clean-room process control with validated DCS configurations.
Engineering Advantages
- Hot-swap Capable: Supports online module replacement without system shutdown, minimizing process interruption.
- Deterministic Scan Cycle: Synchronized with AC800M controller scan for precise, repeatable I/O response times.
- Galvanic Isolation: Channel-to-channel and channel-to-bus isolation protects controller backplane from field-side transients.
- Diagnostic LED Indicators: Per-channel status LEDs enable rapid field fault identification without test equipment.
- Compact Density: High channel count per module reduces rack space requirements and total installed cost.
- Long Product Lifecycle: ABB’s extended support commitment ensures spare parts availability for 10+ year plant lifecycles.
System Architecture & Signal Flow
The 3BHE033067R0102 connects to the AC800M controller via the S800 ModuleBus, a high-speed, deterministic fieldbus optimized for I/O communication within the ABB DCS cabinet. Field signals enter through the module’s terminal block, are conditioned and isolated, then transmitted to the controller CPU for processing within the configured scan cycle. Output commands follow the reverse path, with the module providing the necessary drive capability for field actuators.
The module integrates seamlessly with ABB’s Control Builder M engineering tool, allowing full configuration, diagnostics, and firmware management from the engineering workstation without physical access to the module.
Sourcing & Quality Verification
- All units sourced through verified ABB authorized channels or certified industrial surplus networks.
- Each module undergoes functional power-on testing and visual inspection prior to shipment.
- Refurbished units are restored to OEM specification with full diagnostic verification.
- Original ABB part labels, firmware version, and hardware revision are documented and provided with shipment.
- Anti-static packaging and shock-protected shipping cartons used for all orders.
- Certificate of conformance available upon request for regulated industries.
Procurement Process
- Confirm Compatibility: Verify your AC800M controller model and firmware version against the 3BHE033067R0102 compatibility matrix. Contact our engineering team if confirmation is needed.
- Request Quote: Submit your RFQ via support@konmask.com or +0086 19859288691 for volume pricing, lead time, and condition options.
- Order & Payment: Secure checkout via Konmask.com with T/T bank transfer, PayPal, or credit card accepted.
- Shipping: DHL / FedEx / UPS express worldwide. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- After-Sales Support: 90-day warranty on all tested units. Technical support available for installation and commissioning queries.
Technical FAQ
Q: Is the 3BHE033067R0102 compatible with the AC800M PM864 controller?
A: Yes. The 3BHE033067R0102 is compatible with the full AC800M PM8xx controller family including PM851, PM856, PM860, PM861, PM864, and PM866 via the S800 ModuleBus.
Q: Can this module be replaced online without shutting down the DCS?
A: Yes. The module supports hot-swap replacement when the system is configured for redundant I/O operation. Consult your ABB Control Builder M project configuration before performing online replacement.
Q: What is the difference between new OEM and refurbished condition?
A: New OEM units are unused, in original ABB packaging. Refurbished units have been professionally restored to OEM specification, fully tested, and carry the same 90-day warranty. Both options are available — contact us for current stock and pricing.
Q: Do you provide export documentation for international orders?
A: Yes. All international shipments include commercial invoice, packing list, country of origin certificate, and HS code declaration. We support customs clearance for all major import markets.
Q: What is the lead time for the 3BHE033067R0102?
A: In-stock units ship within 1–3 business days. For out-of-stock situations, typical sourcing lead time is 2–4 weeks. Contact us for real-time availability.
