ABB 3HAC042494-002 / 3HAC042495-002 / 3HAC046232-006 – IRB6700 Series Axis Servo Motor | ABB Robotics Drive Platform
Engineering Background: The ABB IRB 6700 is ABB Robotics’ flagship heavy-payload industrial robot platform, engineered for automotive body-in-white, foundry, and large-part handling applications. The axis servo motors—referenced under part numbers 3HAC042494-002, 3HAC042495-002, and 3HAC046232-006—are OEM-specified drive units that deliver the torque, precision, and thermal resilience required for continuous 24/7 production cycles.
Product Positioning: Konmask.com supplies these servo motor assemblies as verified OEM-equivalent replacements and genuine ABB spare parts for maintenance engineers, system integrators, and MRO procurement teams operating IRB 6700 robot cells. Each unit is sourced through traceable supply channels and undergoes pre-shipment inspection before dispatch.
Complete Technical Specifications
- Part Numbers: 3HAC042494-002 | 3HAC042495-002 | 3HAC046232-006
- Compatible Platform: ABB IRB 6700 Series (all payload variants: 150/200/235/300/500 kg)
- Component Type: Axis Servo Motor / Drive Unit Assembly
- Manufacturer: ABB Robotics (Sweden)
- Country of Origin: Sweden (SE)
- Weight: 420 g (unit weight; shipping weight may vary)
- Feedback Device: Integrated resolver / encoder (axis-dependent)
- Insulation Class: Class F (155 °C)
- Protection Rating: IP67 (sealed for foundry and wash-down environments)
- Controller Compatibility: IRC5 / IRC5 Compact / OmniCore (with appropriate drive module)
- Axis Application: Axes 1–6 (refer to IRB 6700 spare parts manual for axis-specific mapping)
- Mounting Interface: OEM flange pattern per ABB mechanical drawing
- Connector Type: ABB proprietary multi-pin motor/resolver connector
Proven Application Environments
- Automotive body-in-white welding and stamping lines
- Heavy-part palletizing and machine tending (up to 500 kg payload)
- Foundry and die-casting environments (IP67 rated)
- Large-structure assembly in aerospace and rail manufacturing
- Continuous-duty press-tending and forging automation
- MRO replacement for field-failed axis motors during planned shutdowns
Engineering Advantages
- OEM Dimensional Accuracy: Drop-in replacement with no mechanical modification required
- Thermal Stability: Class F insulation sustains performance in high-ambient foundry environments
- Sealed Construction: IP67 rating prevents coolant, dust, and metal particulate ingress
- Resolver Integrity: Factory-calibrated feedback device ensures immediate IRC5 recognition without re-parameterization
- Reduced Downtime: Ready-to-install units minimize robot cell downtime during corrective maintenance
- Multi-PN Cross-Reference: 3HAC042494-002, 3HAC042495-002, and 3HAC046232-006 cover the full IRB 6700 axis motor family from a single supplier
System Architecture & Signal Flow
In the IRB 6700 drive architecture, each axis servo motor interfaces with the IRC5 Drive Module via a shielded motor cable (power) and a resolver/encoder cable (feedback). The IRC5 Main Computer issues motion commands through the Drive Module, which regulates current to the servo motor windings. Position feedback from the integrated resolver is returned to the Drive Module for closed-loop torque and velocity control. The 3HAC042494-002 / 3HAC042495-002 / 3HAC046232-006 units are plug-compatible with this signal chain, requiring only standard ABB commissioning procedures (motor calibration via RobotStudio or FlexPendant) after installation.
Sourcing & Quality Verification
- Supply Chain: Sourced from authorized ABB distributors and verified OEM surplus channels
- Inspection: Each unit undergoes visual, dimensional, and connector-integrity inspection prior to shipment
- Traceability: Batch and serial documentation available upon request for regulated industries
- Packaging: Anti-static, moisture-barrier packaging with foam cushioning for international freight
- Warranty: 12-month limited warranty against manufacturing defects (see Terms & Conditions)
Procurement Process
- Confirm the required part number(s): 3HAC042494-002, 3HAC042495-002, or 3HAC046232-006
- Verify axis assignment against your IRB 6700 spare parts manual (document 3HAC044266-001)
- Submit your order or RFQ via Konmask.com or email support@konmask.com
- Receive order confirmation with lead time and tracking information within 1 business day
- Expedited shipping available for critical production downtime situations
Technical FAQ
Q: Are 3HAC042494-002, 3HAC042495-002, and 3HAC046232-006 interchangeable?
A: No. Each part number corresponds to a specific axis or variant within the IRB 6700 family. Consult the ABB spare parts manual to confirm the correct PN for your robot serial number and axis.
Q: Is re-calibration required after motor replacement?
A: Yes. ABB requires axis calibration (fine calibration or revolution counter update) after any servo motor replacement. This is performed via the FlexPendant or RobotStudio.
Q: What IRC5 software version is required?
A: RobotWare 6.x or later is recommended. Confirm compatibility with your IRC5 system version before installation.
Q: Can you supply the motor cable and resolver cable as well?
A: Yes. Contact support@konmask.com with your robot serial number for a complete cable kit quotation.
Q: Do you offer exchange/core return programs?
A: Core exchange options may be available for qualified accounts. Contact us for details.
