ABB 3HAC043569-001 Motor with Pinion Type C – IRB 4600 Robot Axis Drive Unit
When a critical axis motor fails on an ABB IRB 4600 robot, the entire production line comes to a halt. Automotive welding cells, material handling systems, and precision assembly stations all depend on the uninterrupted torque delivery of each axis drive unit. A missing or degraded motor with pinion assembly means unplanned downtime, missed production targets, and costly emergency maintenance windows — risks no plant manager can afford.
The ABB 3HAC043569-001 (also referenced as 3HAC043569-004) is the OEM-specified Motor with Pinion Type C designed exclusively for the IRB 4600 robot series. The IRB 4600 is one of ABB’s most widely deployed 6-axis industrial robots, trusted across automotive, electronics, food & beverage, and general manufacturing sectors worldwide. This motor assembly governs precise axis rotation, and its Type C pinion configuration ensures correct gear mesh engagement within the gearbox — making exact part matching non-negotiable for safe and accurate robot operation.
Technical Specifications
- Part Number: 3HAC043569-001
- Cross Reference: 3HAC043569-004
- Robot Series: ABB IRB 4600
- Component Type: Motor with Pinion, Type C
- OEM Brand: ABB Robotics
- Condition: New / Refurbished (specify on inquiry)
- Compatibility: IRB 4600 axis drive system
- Weight: ~100 g (module only; packaging excluded)
Key Features & Benefits
- OEM-Matched Pinion Type C: Ensures correct gear engagement geometry — no shimming or field modification required.
- Drop-In Replacement: Designed to ABB factory tolerances for direct swap without axis recalibration risk.
- Dual Part Number Coverage: Covers both 3HAC043569-001 and 3HAC043569-004 references, eliminating cross-reference confusion during procurement.
- Reliable Torque Transmission: Maintains axis positioning accuracy critical for path repeatability in high-cycle applications.
- Reduced Downtime: Ready-to-ship stock minimizes mean time to repair (MTTR) for urgent breakdown scenarios.
Industry & Equipment Applications
- Automotive Manufacturing: Spot welding, arc welding, and body assembly lines using ABB IRB 4600 robots.
- Electronics Assembly: High-precision pick-and-place and PCB handling cells.
- Food & Beverage: Hygienic packaging and palletizing lines with IRB 4600 variants.
- Metal Fabrication: Cutting, grinding, and deburring applications requiring consistent axis torque.
- General Industrial Automation: Any facility operating ABB IRB 4600 robots requiring axis motor maintenance.
System Integration & Compatible Parts
The 3HAC043569-001 motor integrates directly with the IRB 4600 axis gearbox assembly. When replacing this motor, consider inspecting or simultaneously sourcing the following related components to ensure full drivetrain integrity:
- IRB 4600 Axis Gearbox Unit
- ABB Motor Sealing Kit (axis-specific)
- Encoder / Resolver Assembly for IRB 4600
- Axis Brake Module
- Robot Controller Spare Parts (IRC5 / OmniCore)
Contact our technical team to confirm compatibility with your specific IRB 4600 payload and reach variant.
Our Quality Assurance Process
- Source Verification: All parts are sourced from authorized ABB distributors or certified refurbishment centers.
- Visual & Dimensional Inspection: Each unit is inspected for pinion tooth integrity, shaft runout, and connector condition before dispatch.
- Traceability: Batch and serial documentation available upon request for MRO and audit compliance.
- Packaging: Anti-static, shock-resistant packaging to protect precision motor components during international transit.
How to Order
- Submit your inquiry via the Contact / RFQ form on this page.
- Provide your robot serial number and axis number for compatibility confirmation.
- Receive a formal quotation with lead time and shipping options within 24 business hours.
- Confirm order and receive proforma invoice for payment processing.
- Parts dispatched with full tracking and commercial documentation.
Why Choose Konmask.com?
- Industrial Automation Specialists: Focused exclusively on PLC, DCS, robot, and drive components — not a generalist marketplace.
- Global B2B Supply: Serving MRO buyers, system integrators, and OEM service teams across 30+ countries.
- Technical Pre-Sales Support: Our engineers verify part compatibility before you commit to a purchase.
- Fast Inquiry Response: Dedicated B2B team responds to all RFQs within one business day.
- Secure International Shipping: DHL, FedEx, and UPS express options with full export documentation.
Frequently Asked Questions
Q: What is the difference between 3HAC043569-001 and 3HAC043569-004?
A: These are ABB’s internal revision references for the same Motor with Pinion Type C assembly used in the IRB 4600. Both part numbers are interchangeable for the same axis application. Always confirm with your robot’s BOM or service manual.
Q: Is this motor compatible with all IRB 4600 variants?
A: The Type C pinion designation applies to specific axis positions within the IRB 4600 family. Please provide your robot’s full model designation (e.g., IRB 4600-20/2.50) and axis number when submitting your inquiry for exact confirmation.
Q: Do you supply new or refurbished units?
A: We supply both new OEM and professionally refurbished units depending on availability and your budget requirements. Condition is clearly stated in the formal quotation.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. For sourced or refurbished units, lead time is typically 5–15 business days. Urgent requirements can be accommodated — please flag in your inquiry.
Q: Can you provide a warranty?
A: Yes. New OEM units carry the standard ABB warranty. Refurbished units carry a Konmask.com 90-day functional warranty. Terms are detailed in the quotation.
