ABB 3HAC15859-3 / 3HAC050495-001 – Arm Extender 450mm | IRB 6600 / IRB 6650 Platform
The ABB 3HAC15859-3 (cross-reference: 3HAC050495-001, assembly ref: 3HAC038666-003) is an OEM-specification Arm Extender measuring 450 mm engineered exclusively for ABB’s IRB 6600 and IRB 6650 heavy-duty industrial robot series. Procurement engineers sourcing replacement mechanical linkage components for high-payload automation cells will find this part a direct, drop-in solution requiring no field modification.
Complete Technical Specifications
- Primary Part Number: 3HAC15859-3
- Cross-Reference / Alternate PN: 3HAC050495-001
- Assembly Reference: 3HAC038666-003
- Description: Arm Extender
- Extension Length: 450 mm
- Compatible Robot Series: ABB IRB 6600 / IRB 6650
- Manufacturer: ABB Robotics (Sweden)
- Country of Origin: Sweden (SE)
- Part Category: Mechanical Linkage / Structural Robot Component
- Condition: New / Surplus New / Refurbished (specify at inquiry)
- Weight (approx.): 100 g (shipping weight; actual part weight varies)
- Requires Shipping: Yes — physical component
Proven Application Environments
- Automotive body-in-white welding and assembly lines
- Heavy-payload material handling and palletizing cells
- Foundry and press-tending applications with IRB 6600F variants
- Aerospace structural component machining and riveting fixtures
- General-purpose 6-axis robot cells requiring extended reach configuration
- Preventive maintenance overhaul programs for IRB 6600 / 6650 fleets
Engineering Advantages
- OEM Dimensional Accuracy: Manufactured to ABB’s original tolerances — ensures correct axis-3 geometry and TCP repeatability after installation.
- Direct Drop-In Replacement: No machining or shimming required; interfaces directly with existing upper-arm casting and lower-arm pivot.
- High-Strength Alloy Construction: Designed to withstand the dynamic loads of IRB 6600’s 175–300 kg payload range.
- Dual Part-Number Coverage: 3HAC15859-3 and 3HAC050495-001 are interchangeable references — reduces procurement confusion across different BOM revisions.
- Minimizes Downtime: Stocked for immediate dispatch, reducing robot offline time versus waiting for OEM lead times.
System Architecture & Signal Flow
The Arm Extender is a passive structural component within the IRB 6600’s lower-arm assembly. It connects the axis-2 gearbox output flange to the axis-3 pivot housing, effectively extending the robot’s reach envelope by 450 mm. No electrical or signal routing passes through this component; however, correct installation torque on all fasteners is critical to maintaining the robot’s rated repeatability (±0.05 mm for IRB 6600). Refer to ABB Product Manual 3HAC026876-001 for installation procedure and torque specifications.
Sourcing & Quality Verification
- Source Traceability: Parts sourced from authorized ABB distributors, certified MRO suppliers, or decommissioned OEM production lines.
- Inspection Protocol: Each unit undergoes dimensional verification and visual inspection prior to dispatch.
- Documentation Available: Certificate of conformance, packing list, and part-number label photos provided on request.
- Anti-Counterfeit Policy: Konmask.com does not trade in counterfeit or non-OEM-spec parts. All listings are clearly marked with condition grade.
Procurement Process
- Step 1 — Confirm Compatibility: Verify your robot’s serial number and arm configuration against ABB’s spare parts catalog (SPARC) or contact our engineering team.
- Step 2 — Request Quote: Submit your PO number, required quantity, and delivery deadline via email or the contact form below.
- Step 3 — Order Confirmation: Receive proforma invoice with lead time, shipping method, and Incoterms within 24 business hours.
- Step 4 — Dispatch & Tracking: Parts shipped with full tracking; export documentation (commercial invoice, packing list, HS code 8473.30) included for cross-border shipments.
- Step 5 — After-Sales Support: 30-day return window for unused parts in original packaging; technical installation queries answered by our engineering team.
Technical FAQ
Q: Is 3HAC15859-3 the same as 3HAC050495-001?
A: Yes. These are two ABB part numbers referencing the same physical component across different BOM revisions. Both are valid for ordering.
Q: Does this fit the IRB 6650S (shelf-mounted variant)?
A: Compatibility depends on the specific IRB 6650S configuration. Please provide your robot’s full type designation (e.g., IRB 6650S-90/3.9) for confirmation.
Q: What is the expected service life?
A: ABB does not publish a fixed service life for this structural component. Replacement is typically triggered by visible deformation, cracking, or following a collision event. Inspect per ABB maintenance schedule 3HAC026876-001.
Q: Can you supply multiple units for a fleet overhaul?
A: Yes. Volume pricing is available for orders of 3+ units. Contact us with your fleet size and timeline.
Q: What Incoterms do you offer?
A: We support EXW, FOB Xiamen, and CIF to major ports. DDP available for select destinations — inquire at time of order.
