Profibus DP Communication Solution – ABB CI830 3BSE013252R1 | AC800M Series
Where This Product Is Used
The ABB CI830 (3BSE013252R1) is a Profibus DP master/slave communication interface module designed for the ABB AC800M Distributed Control System (DCS). It is deployed across a wide range of industrial environments where deterministic fieldbus communication is critical:
- Oil & Gas Processing Plants — Integrating field instruments, valve positioners, and flow computers via Profibus DP in upstream/downstream facilities.
- Pulp & Paper Mills — Connecting distributed I/O racks and drives across large-footprint production lines.
- Power Generation & Utilities — Coordinating turbine control, boiler management, and substation automation under ABB 800xA platforms.
- Chemical & Petrochemical Plants — Enabling real-time process data exchange between AC800M controllers and Profibus-enabled field devices in hazardous areas.
- Water & Wastewater Treatment — Linking pumping stations, analyzers, and actuators to centralized DCS architectures.
- Mining & Minerals Processing — Supporting conveyor systems, crushers, and mill drives with reliable fieldbus communication.
Technical Specifications
| Part Number | CI830 / 3BSE013252R1 |
| Manufacturer | ABB |
| Series | AC800M DCS |
| Module Type | Profibus DP Communication Interface |
| Protocol | Profibus DP (EN 50170 / IEC 61158) |
| Profibus Role | DP Master (Class 1) |
| Max. Slaves | Up to 125 Profibus DP slave devices |
| Baud Rate | 9.6 kbps – 12 Mbps (auto-detect) |
| Connector | 9-pin D-Sub (DB9) |
| Backplane Interface | AC800M CPU module slot (S800 I/O) |
| Power Supply | Via AC800M backplane (5 VDC) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Weight | Approx. 300 g |
| Dimensions | Standard AC800M module form factor |
| Firmware | Configurable via ABB Control Builder M |
Why Engineers Specify This Model
- Native AC800M Integration — Plugs directly into the AC800M controller rack with zero additional hardware adapters, reducing BOM complexity and commissioning time.
- High Slave Density — Supports up to 125 DP slaves per segment, enabling large-scale I/O architectures without additional master modules.
- Auto Baud Rate Detection — Eliminates manual configuration errors during network commissioning across mixed-speed Profibus segments.
- Deterministic Cycle Times — Guarantees real-time data exchange critical for closed-loop process control in safety-sensitive applications.
- Proven Field Reliability — Widely deployed in ABB 800xA installations globally; extensive installed base ensures long-term spare parts availability and engineering familiarity.
- Control Builder M Compatible — Full configuration, diagnostics, and firmware management via ABB’s standard engineering tool — no third-party software required.
Complete System Bill of Materials
The CI830 is typically specified alongside the following components in an AC800M DCS architecture:
- ABB PM861 / PM864 / PM866 — AC800M CPU processor modules
- ABB TB807 / TB840 — Termination boards for S800 I/O
- ABB AI810 / AO810 / DI810 / DO810 — S800 I/O analog and digital modules
- ABB CI840 / CI854 — Redundant Profibus DP or PROFINET interface modules
- ABB SD821 / SD822 — Power supply units for AC800M racks
- Profibus DP Cable (Type A) — Shielded twisted-pair, 150 Ω impedance
- Profibus DP Bus Terminator / Connector — Active termination at segment ends
- ABB Control Builder M Software — Engineering and configuration platform
Compliance & Industry Standards
- Profibus DP: EN 50170 / IEC 61158 / IEC 61784
- EMC Compliance: CE Marking (EU Directive 2014/30/EU)
- Safety: Designed for use in SIL-rated ABB 800xA Safety systems (verify SIL level with project-specific documentation)
- Environmental: RoHS compliant
- Quality Management: Manufactured under ISO 9001 certified processes
Quality Assurance & Sourcing
At Konmask.com, every ABB CI830 3BSE013252R1 unit is subject to our multi-stage verification process before dispatch:
- ✅ Visual Inspection — PCB, connectors, and housing checked for physical damage or counterfeit indicators
- ✅ Label & Serial Number Verification — Cross-referenced against ABB’s part numbering conventions
- ✅ Functional Power-On Test — Where applicable, modules are bench-tested prior to shipment
- ✅ Original Packaging — Shipped in ESD-safe anti-static bags with protective foam packaging
- ✅ Traceable Sourcing — Sourced from authorized distributors, OEM surplus, or verified industrial decommissions
How to Source This Part
Ready to order or need a formal quotation for your project?
- 📧 Email: support@konmask.com
- 📞 Phone / WhatsApp: +0086 19859288691
- 🌐 Website: https://Konmask.com
- ⏱ Lead Time: In-stock units ship within 1–3 business days; ex-stock quotes provided within 24 hours
- 📦 Shipping: DHL / FedEx / UPS express worldwide; sea freight available for bulk orders
- 💳 Payment: T/T Bank Transfer, PayPal, Western Union, and Trade Assurance accepted
Application-Specific FAQ
Q: Can the CI830 operate as a Profibus DP slave?
A: No. The CI830 functions exclusively as a DP Class 1 Master. For slave functionality within an AC800M system, consult ABB’s CI840A or CI854A modules.
Q: Is the CI830 compatible with ABB 800xA System Version 6.x?
A: Yes. The CI830 is supported under ABB 800xA versions 5.x and 6.x with the appropriate Control Builder M release. Always verify firmware compatibility with your specific 800xA version before installation.
Q: Can I use the CI830 in a redundant Profibus DP configuration?
A: The CI830 itself is a single-channel module. For redundant Profibus DP, ABB recommends the CI840A (redundant DP master). The CI830 can be used in non-redundant segments within a larger redundant DCS architecture.
Q: What is the maximum cable length per Profibus DP segment?
A: At 12 Mbps, maximum segment length is 100 m. At 1.5 Mbps, up to 200 m. At 93.75 kbps, up to 1,200 m. Use repeaters to extend beyond single-segment limits.
Q: Do you provide a warranty on the CI830 3BSE013252R1?
A: Yes. Konmask provides a 12-month warranty on all modules. Defective units are replaced or refunded subject to our returns policy. Contact support@konmask.com for warranty claims.
Q: Can you supply multiple units for a plant-wide spare parts program?
A: Yes. We support bulk and blanket purchase orders. Contact us for volume pricing and lead time commitments.
