Industrial Drive Control Panel Mounting Solution – ABB DPMP-02 (3AXD50000009374) | ACS880 Series
Where This Product Is Used
The ABB DPMP-02 control panel mounting platform is engineered for industrial environments where the ACS880 drive’s control panel must be relocated from the drive unit to a cabinet door, enclosure panel, or remote mounting surface. Typical deployment scenarios include:
- Motor Control Centers (MCC): Mounting the ACS880 control panel flush on MCC door for operator access without opening the cabinet.
- Process Automation Panels: Integrating drive HMI into centralized control desks in water treatment, HVAC, and conveyor systems.
- OEM Machine Builds: Machine builders embedding the panel into custom enclosures for pumps, fans, compressors, and hoists.
- Retrofit Projects: Upgrading legacy drive installations where panel accessibility is a safety or ergonomic requirement.
- Hazardous Area Enclosures: Positioning the control interface on the exterior of sealed enclosures to minimize door-open events.
Technical Specifications
| Part Number | DPMP-02 |
| ABB Order Code | 3AXD50000009374 |
| Compatible Drive Series | ABB ACS880 (all frame sizes supporting DPMP) |
| Mounting Type | Door / Panel Surface Mount |
| Weight | 120 g |
| Material | Engineering-grade plastic housing |
| IP Rating (installed) | IP54 (front face, panel-mounted) |
| Cable Extension Required | Yes – DPMP extension cable (sold separately) |
| Country of Origin | Finland / EU |
| RoHS Compliant | Yes |
Why Engineers Specify This Model
- OEM-Designed Fit: Precision-molded to accept the ACS880 assistant control panel with zero modification — no drilling adapters or custom brackets required.
- IP54 Front Protection: Maintains ingress protection rating when panel-mounted, critical for dusty or wash-down environments.
- Reduced Downtime: Operators can access drive parameters, fault logs, and start/stop functions without opening the main enclosure, reducing arc-flash exposure risk.
- Compact Footprint: Minimal panel cutout requirement preserves enclosure structural integrity and available real estate.
- ABB Genuine Part: Ensures full compatibility with ACS880 firmware and panel communication protocol — no third-party compatibility risks.
Complete System Bill of Materials
For a complete door-mount control panel installation on ACS880 drives, engineers typically specify:
- ABB DPMP-02 / 3AXD50000009374 — Control Panel Mounting Platform (this item)
- ABB ACS-AP-I or ACS-AP-W — Assistant Control Panel (if not already included with drive)
- ABB DPMP Extension Cable — 1 m, 3 m, or 5 m (order code varies by length)
- M4 panel mounting hardware — 4× screws (typically supplied with DPMP-02)
Compliance & Industry Standards
- RoHS 2011/65/EU compliant
- CE marked (as part of ACS880 drive system)
- Designed to IEC 61800-5-1 (safety requirements for adjustable speed electrical power drive systems)
- Compatible with UL 508A panel builder requirements when used with UL-listed ACS880 drives
Quality Assurance & Sourcing
Konmask.com sources ABB drive accessories directly from authorized ABB distribution channels and verified industrial surplus inventories. Every unit undergoes:
- Visual inspection for housing cracks, connector damage, and label integrity
- Part number and order code cross-verification against ABB’s official product catalog
- Anti-static packaging for safe transit
- Batch traceability records retained for 3 years
We do not sell counterfeit, refurbished-as-new, or unverified grey-market parts.
How to Source This Part
Ready to order the ABB DPMP-02 (3AXD50000009374)? Here’s how to proceed:
- Add to Cart: Click the order button above for standard stock orders.
- Request a Quote: For bulk quantities (>5 units) or project BOM pricing, email support@konmask.com.
- Lead Time: In-stock units ship within 1–3 business days. Out-of-stock lead time is 2–4 weeks via ABB distribution.
- Export & Cross-Border: We ship globally. Contact us for export documentation, HS code confirmation, and freight options.
Application-Specific FAQ
Q: Is DPMP-02 compatible with ACS580 or ACS380 drives?
A: No. The DPMP-02 is designed exclusively for the ACS880 series. ACS580 uses a different panel mounting kit (DPMP-01 or equivalent). Always verify the drive model before ordering.
Q: Does the DPMP-02 include the extension cable?
A: No. The mounting platform and extension cable are separate accessories. The cable length depends on the distance between the drive and the panel cutout location.
Q: Can I mount the panel on a 2 mm steel door?
A: Yes. The DPMP-02 is designed for standard enclosure door thicknesses (1.5–3 mm). Ensure the panel cutout dimensions match ABB’s installation drawing (available in the ACS880 hardware manual).
Q: What is the maximum cable extension length supported?
A: ABB supports up to 5 m extension cable for the ACS880 control panel without signal degradation under standard conditions.
Q: Is this part available with a warranty?
A: Yes. Konmask.com provides a 12-month warranty against manufacturing defects on all genuine ABB accessories.
