ABB GJR2332300R0200 – Advant Controller 31 Control Module | AC31 Series Platform
Engineering Background
The ABB Advant Controller 31 (AC31) series represents ABB’s modular, rack-based programmable automation platform engineered for demanding industrial process and discrete manufacturing environments. Designed to IEC 61131-3 standards, the AC31 family delivers deterministic scan-cycle performance, robust I/O expansion, and seamless integration into ABB’s broader Advant OCS distributed control architecture.
Product Positioning
The GJR2332300R0200 is a central control module within the AC31 platform, serving as the processing core for logic execution, program storage, and inter-module communication. It is the preferred replacement and upgrade unit for engineers maintaining legacy AC31 installations or commissioning new control panels requiring proven ABB automation DNA. Konmask.com supplies this module to MRO procurement teams, system integrators, and OEM panel builders globally.
Complete Technical Specifications
| Part Number | GJR2332300R0200 |
| Manufacturer | ABB (ASEA Brown Boveri) |
| Series / Platform | Advant Controller 31 (AC31) |
| Module Type | Central Control Module (CPU) |
| Programming Standard | IEC 61131-3 |
| Communication Interface | RCOM / Advant Fieldbus (AF100) compatible |
| Operating Voltage | 24 V DC (nominal) |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Relative Humidity | 5 % to 95 % (non-condensing) |
| Protection Class | IP20 (panel-mounted) |
| Approvals / Certifications | CE, UL (refer to nameplate) |
| Weight | Approx. 400 g |
| Country of Origin | Germany / Sweden (ABB manufacturing) |
| Condition | New / Refurbished-to-OEM-spec (specify at order) |
Proven Application Environments
- Pulp & paper process lines requiring high-availability PLC control
- Water & wastewater treatment SCADA integration nodes
- Chemical plant batch sequencing and interlock logic
- Power generation auxiliary control panels
- Automotive body-shop conveyor and transfer-line automation
- Marine and offshore control systems certified to DNV/GL standards
- MRO replacement for existing AC31 rack installations
Engineering Advantages
- Deterministic Scan Cycle: Consistent cycle-time execution critical for safety-related interlock sequences.
- Modular Rack Architecture: Hot-swap compatible within AC31 rack; minimises downtime during maintenance windows.
- Advant Fieldbus (AF100) Native: Peer-to-peer communication without gateway overhead, reducing latency in distributed I/O topologies.
- IEC 61131-3 Compliance: Supports Ladder Diagram (LD), Function Block Diagram (FBD), and Structured Text (ST) — portable logic across ABB platforms.
- Long Service Life: ABB’s industrial-grade component selection ensures MTBF exceeding 100,000 hours in rated conditions.
- Backward Compatibility: Drop-in replacement for earlier R0100 revision in most AC31 rack configurations (verify firmware revision before installation).
System Architecture & Signal Flow
The GJR2332300R0200 occupies the CPU slot of the AC31 rack. On power-up, the module performs a self-diagnostic ROM/RAM check before entering RUN mode. Program execution follows a fixed scan cycle: Input Read → Program Execution → Output Write → Communication Servicing. The AF100 fieldbus port handles peer-to-peer data exchange with remote I/O racks and HMI nodes at up to 2 Mbit/s. Configuration and programming are performed via the ABB Control Builder or legacy AMPL/GrafCet toolchain connected through the front-panel programming port.
Sourcing & Quality Verification
- Authorised Supply Chain: Konmask sources ABB modules through verified distributor channels and certified MRO partners — no grey-market or counterfeit risk.
- Pre-shipment Inspection: Every unit undergoes visual inspection, label verification (part number, revision, serial number), and functional power-on test where applicable.
- Packaging: ESD-safe anti-static bag + foam-lined carton; humidity indicator card included for long-haul shipments.
- Documentation: Certificate of conformity and test report available on request for regulated industries.
- Warranty: 12-month Konmask warranty covering manufacturing defects; DOA replacement within 7 business days.
Procurement Process
- Confirm Part Number & Revision: Cross-reference GJR2332300R0200 against your existing rack label or ABB spare-parts list. Note the R0200 hardware revision requirement.
- Request a Quote: Contact support@konmask.com with quantity, required delivery date, and Incoterms preference (EXW / DAP / DDP available).
- Order Confirmation: Pro-forma invoice issued within 1 business day; payment via T/T, PayPal, or credit card.
- Lead Time: In-stock units ship within 2–3 business days; sourced units 7–15 business days depending on origin warehouse.
- Export Compliance: ABB automation hardware may be subject to export control regulations (EAR/ECCN). Konmask handles all export documentation for compliant cross-border shipments.
Technical FAQ
Q: Is GJR2332300R0200 compatible with the AC31 07 KR 91 rack?
A: Yes. The R0200 revision is the standard control module for the AC31 07 KR 91 and 07 KR 51 rack families. Always verify the rack backplane revision label before installation.
Q: Can I use Control Builder M to program this module?
A: No. GJR2332300R0200 uses the legacy ABB AMPL / GrafCet toolchain or the older Control Builder (non-M). Control Builder M targets the AC500 platform. Confirm your engineering toolchain before ordering.
Q: What is the difference between R0100 and R0200 revisions?
A: R0200 incorporates an updated EPROM firmware revision with improved communication stack stability. In most installations R0200 is a direct drop-in for R0100; however, verify with your ABB system documentation for safety-critical applications.
Q: Do you provide a test report?
A: Yes. A functional test report and certificate of conformity are available upon request at no additional charge for orders of 1 unit or more.
Q: Can Konmask supply multiple units for a plant-wide MRO programme?
A: Yes. Volume pricing and blanket-order agreements are available. Contact our B2B procurement desk for framework contract terms.
