Process Automation PCB Solution – ABB GJR2363900R1000 88VT02B-E | AC500 Series
Where This Product Is Used
The ABB GJR2363900R1000 88VT02B-E Printed Circuit Board is a core control component deployed across demanding industrial environments where signal integrity and system uptime are non-negotiable. Typical deployment sites include:
- Oil & Gas Plants – Distributed control of wellhead, pipeline, and refinery automation loops
- Power Generation & Utilities – Turbine governor control, boiler management, and grid-tie protection systems
- Chemical & Petrochemical Facilities – Continuous process control requiring SIL-rated board-level redundancy
- Pulp & Paper Mills – High-cycle I/O scanning for web tension and dryer section control
- Water & Wastewater Treatment – SCADA-integrated pump station and dosing control panels
- Automotive Manufacturing – Robotic cell controllers and conveyor sequencing within ABB AC500-based architectures
Technical Specifications
| Part Number | GJR2363900R1000 |
| Variant / Revision | 88VT02B-E |
| Manufacturer | ABB Ltd. |
| Product Family | AC500 / Advant / DCS Control Series |
| Component Type | Printed Circuit Board (PCB) |
| Form Factor | Plug-in module board |
| Operating Temperature | 0 °C to +60 °C (standard industrial range) |
| Weight | 550 g (approx.) |
| Condition Available | New OEM / Tested Surplus / Refurbished |
| Country of Origin | Germany / Sweden (ABB production) |
| Compliance | CE, RoHS |
Why Engineers Specify This Model
- Drop-in Replacement – Direct hardware-compatible substitute for installed AC500 / Advant DCS racks; no firmware re-flashing required in most configurations
- Proven Field Reliability – ABB’s industrial PCB manufacturing meets IPC-A-610 Class 3 workmanship standards for mission-critical applications
- Long Service Life – Conformal-coated board construction resists humidity, vibration, and airborne contaminants common in plant environments
- Reduced Downtime Risk – Stocking a spare GJR2363900R1000 88VT02B-E eliminates multi-week OEM lead times during unplanned outages
- Backward Compatibility – Revision 88VT02B-E maintains signal and connector compatibility with earlier rack generations
Complete System Bill of Materials
For a fully operational ABB AC500 / Advant DCS control node, engineers typically source the following alongside this PCB:
- AC500 CPU Module (e.g., PM573, PM583, PM595)
- AC500 I/O Expansion Modules (DI, DO, AI, AO)
- Rack / Backplane Assembly (TB511, TB521 series)
- 24 VDC Power Supply Module
- Communication Interface Card (CS31, PROFIBUS, Modbus)
- Programming Cable & Automation Builder License
Contact support@konmask.com for bundled BOM pricing.
Compliance & Industry Standards
- CE Marking – EU Low Voltage and EMC Directives
- RoHS 2 (2011/65/EU) – Restriction of Hazardous Substances compliant
- IEC 61131-2 – Programmable controllers: equipment requirements and tests
- IEC 61508 / IEC 61511 – Functional safety (SIL) framework compatibility
- UL 508 – Industrial control equipment (where applicable)
Quality Assurance & Sourcing
Every ABB GJR2363900R1000 88VT02B-E unit shipped from Konmask.com undergoes the following verification process:
- Visual inspection against IPC-A-610 Class 3 criteria
- Component-level continuity and power-rail testing
- Functional bench test in an ABB-compatible rack environment (surplus/refurbished units)
- Anti-static packaging with humidity indicator card
- Traceable documentation: test report, serial number log, and certificate of conformance available on request
How to Source This Part
- Add to Cart – Select quantity and condition (New / Surplus / Refurbished) above
- Request a Quote – For orders of 2+ units or urgent delivery, email support@konmask.com for volume pricing
- Lead Time – In-stock units ship within 1–3 business days; EXW Xiamen, China. DHL / FedEx express available
- Payment – T/T Bank Transfer, PayPal, and major credit cards accepted
- Export Compliance – We handle CN customs export documentation; buyer responsible for import duties
Application-Specific FAQ
Q: Is GJR2363900R1000 88VT02B-E compatible with the ABB Advant OCS / MOD 300 platform?
A: This board is designed for the AC500 / Advant controller family. Compatibility with MOD 300 depends on rack generation — contact us with your rack part number for confirmation.
Q: Can I use a refurbished board in a SIL 2 loop?
A: Refurbished boards are supplied with full test documentation. Final SIL validation must be performed by your functional safety engineer per IEC 61508 site assessment requirements.
Q: What is the warranty on this PCB?
A: New OEM units carry a 12-month warranty. Tested surplus and refurbished units carry a 90-day warranty. Extended warranty available on request.
Q: Do you provide installation support?
A: We provide datasheet, wiring diagrams, and configuration notes. On-site commissioning support can be arranged through our partner network — inquire via email.
