ABB HIEE200072R0002 USB030AE02 – AC800M Series Redundant Power Supply Module | AC800M DCS Platform
Engineering Background
The ABB AC800M is ABB’s flagship distributed control system (DCS) platform, widely deployed across power generation, oil & gas, pulp & paper, and chemical processing industries. Reliable, conditioned DC power is the foundation of any AC800M installation — a single power supply failure can cascade into unplanned downtime costing tens of thousands of dollars per hour. The HIEE200072R0002 (USB030AE02) is the factory-designated power supply module engineered to eliminate that risk.
Product Positioning
Designed for mission-critical continuous-process environments, this module delivers regulated, filtered DC power to the AC800M controller backplane. It supports hot-swap redundancy configurations, enabling maintenance without process interruption. Konmask.com stocks verified, tested units sourced through authorized industrial channels — ready for immediate deployment or emergency replacement.
Complete Technical Specifications
| Manufacturer | ABB |
| Part Number | HIEE200072R0002 |
| Ordering Code | USB030AE02 |
| Module Type | AC/DC Power Supply Module |
| Platform Compatibility | ABB AC800M DCS (PM851, PM856, PM860, PM861, PM864, PM866) |
| Input Voltage | 100–240 V AC, 50/60 Hz (universal input) |
| Output Voltage | 24 V DC regulated |
| Output Power | 30 W nominal |
| Redundancy Support | Yes — parallel hot-swap redundancy |
| Isolation | Galvanic isolation, input-to-output |
| Protection | Overvoltage, overcurrent, short-circuit, thermal shutdown |
| Mounting | AC800M backplane slot (DIN rail compatible chassis) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5–95% RH, non-condensing |
| Weight | 1,200 g (approx.) |
| Certifications | CE, UL (per ABB product documentation) |
| Condition Available | New (sealed) / Refurbished (tested, warranted) |
Proven Application Environments
- Power Generation: Turbine governor and boiler control systems running AC800M controllers
- Oil & Gas: Upstream SCADA and midstream pipeline DCS installations
- Pulp & Paper: Continuous digester and recovery boiler process control
- Chemical & Petrochemical: Reactor management and batch control systems
- Water Treatment: Municipal SCADA and pump station automation
- Emergency Replacement: Drop-in substitute for failed USB030AE02 units in live production environments
Engineering Advantages
- Zero-downtime redundancy: Hot-swap capability allows module replacement without shutting down the controller or the process
- Universal AC input: 100–240 V AC range eliminates site-specific power conditioning requirements
- Galvanic isolation: Protects sensitive controller logic from AC line transients and ground loops
- Multi-layer protection: Overvoltage, overcurrent, short-circuit, and thermal protection prevent cascading failures
- OEM form factor: Direct plug-in replacement — no wiring modifications, no firmware changes required
- Long service life: Industrial-grade components rated for continuous 24/7 operation in harsh environments
System Architecture & Signal Flow
The USB030AE02 installs into the dedicated power supply slot on the AC800M S100 or S800 I/O backplane. AC mains input is rectified and regulated through a switched-mode power supply (SMPS) topology, delivering stable 24 V DC to the backplane bus. In a redundant configuration, two USB030AE02 modules operate in parallel load-sharing mode — if one module fails, the second assumes full load instantaneously with no controller interruption. The module communicates power status to the AC800M controller via backplane signaling, enabling fault diagnostics through ABB’s Control Builder M engineering tool.
Sourcing & Quality Verification
- All units are sourced through verified industrial supply channels with full traceability
- New (sealed) units ship with original ABB packaging and documentation
- Refurbished units undergo full functional test: input/output voltage verification, load regulation test, protection circuit validation, and thermal burn-in
- Each unit is inspected for counterfeit indicators: PCB markings, component date codes, label authenticity
- Test reports available upon request for critical infrastructure procurement
Procurement Process
- Step 1: Confirm your AC800M controller model and backplane revision with your site documentation
- Step 2: Contact Konmask.com via the form below or email support@konmask.com with your required quantity and condition preference (new / refurbished)
- Step 3: Receive a formal quotation with lead time, warranty terms, and shipping options within 24 business hours
- Step 4: Purchase order accepted via T/T bank transfer, PayPal, or trade credit (approved accounts)
- Step 5: Unit ships with commercial invoice, packing list, and optional test report; tracking provided same day
Technical FAQ
Q: Is HIEE200072R0002 the same as USB030AE02?
A: Yes. HIEE200072R0002 is ABB’s internal hardware revision code; USB030AE02 is the commercial ordering code. Both refer to the identical physical module.
Q: Can this module be used with AC800F or AC800PEC controllers?
A: No. The USB030AE02 is designed exclusively for the AC800M platform. AC800F and AC800PEC use different power supply architectures.
Q: What is the warranty on refurbished units?
A: Konmask.com provides a 12-month functional warranty on all refurbished units. New (sealed) units carry the original ABB manufacturer warranty.
Q: Do you provide export documentation for international shipments?
A: Yes. We provide commercial invoice, packing list, certificate of origin, and can arrange third-party inspection reports upon request.
Q: What is the typical lead time?
A: In-stock units ship within 1–3 business days. Out-of-stock items are sourced within 2–4 weeks depending on market availability.
