ABB HITE303166R1 / HITE515100 / IDB761A – Distributed Control Board | AC800M DCS Platform
Engineering Background
The ABB AC800M is ABB’s flagship distributed control system (DCS) platform, widely deployed in power generation, oil & gas, pulp & paper, and chemical process industries. The HITE303166R1 / HITE515100 / IDB761A is a core control board assembly within this platform, responsible for inter-module communication, I/O signal arbitration, and real-time process data routing between the controller CPU and field I/O modules.
Product Positioning
This board is a direct replacement and spare part for existing AC800M installations. It is sourced from decommissioned or surplus industrial systems, fully inspected, and verified for functional integrity before listing. Procurement engineers managing aging DCS infrastructure will find this a cost-effective alternative to new OEM supply with lead times of 16–26 weeks.
Complete Technical Specifications
| Manufacturer | ABB (ASEA Brown Boveri) |
| Part Numbers | HITE303166R1 / HITE515100 / IDB761A |
| Platform | AC800M DCS |
| Module Type | Control / Communication Board |
| Form Factor | PCB Assembly, rack-mount compatible |
| Weight | 460 g (net) |
| Country of Origin | Sweden |
| Condition | Used / Surplus – Tested & Verified |
| Warranty | 90-day functional warranty |
| Certifications | CE (original OEM) |
| Compatible Systems | ABB AC800M, Symphony Plus, Freelance DCS |
| Communication Interface | ModuleBus / Optical Ethernet (platform-dependent) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -25°C to +70°C |
| Humidity | 5–95% RH, non-condensing |
| Power Supply | Supplied via backplane (24 VDC nominal) |
Proven Application Environments
- Power Generation: Turbine governor control, boiler management systems, and plant-wide DCS integration
- Oil & Gas: Upstream SCADA integration, compressor control, and pipeline monitoring
- Pulp & Paper: Continuous process control, digester management, and recovery boiler automation
- Chemical Processing: Batch reactor control, safety interlock systems (SIS-adjacent), and distillation column management
- Water Treatment: WWTP automation, pump station control, and remote I/O expansion
Engineering Advantages
- Drop-in Replacement: Identical form, fit, and function to OEM specification — no firmware re-flashing required in most AC800M configurations
- Immediate Availability: In-stock and ready to ship within 1–3 business days, bypassing OEM lead times of 16–26 weeks
- Cost Efficiency: 40–70% below new OEM list price, enabling budget-conscious MRO procurement without compromising system integrity
- Pre-shipment Testing: Each unit undergoes visual inspection, connector integrity check, and functional bench test before dispatch
- Traceability: Full documentation package available on request (test report, photos, serial number record)
System Architecture & Signal Flow
Within the AC800M rack architecture, the IDB761A board interfaces directly with the PM8xx controller module via the internal ModuleBus backplane. It manages signal arbitration between the CPU and downstream S800 I/O modules, handling both digital and analog signal conditioning. The HITE515100 sub-assembly provides the physical layer interface for optical or copper Ethernet communication to the plant network, while HITE303166R1 is the primary PCB carrier integrating both functions.
Signal flow: Field Instruments → S800 I/O → IDB761A (via backplane) → PM8xx CPU → Plant DCS Network
Sourcing & Quality Verification
- All units sourced from documented industrial decommissioning projects or certified surplus dealers
- Visual inspection: PCB surface, solder joints, connector pins, and component integrity
- Functional test: Power-on verification and communication handshake test where applicable
- ESD-safe packaging: Anti-static bag + foam insert + double-wall carton
- Counterfeit mitigation: Part markings, date codes, and PCB silkscreen verified against OEM reference
Procurement Process
- Confirm compatibility: Provide your AC800M system version and existing part number for cross-reference verification
- Request quotation: Contact support@konmask.com for volume pricing, lead time, and documentation package
- Place order: Purchase via this listing or via B2B invoice (T/T, L/C accepted)
- Shipment: DHL / FedEx Express with full tracking; export documentation (commercial invoice, packing list, COO) included
- Incoming inspection: We recommend a 48-hour incoming inspection window before installation
Technical FAQ
Q: Is this a new or refurbished part?
A: This is a tested surplus unit. It is not new OEM stock. Condition is clearly stated as Used/Surplus – Tested & Verified.
Q: Will this work with my AC800M firmware version?
A: The IDB761A is hardware-compatible across AC800M generations. Firmware compatibility depends on your PM8xx controller version. Contact us with your system details for confirmation.
Q: Can you provide a test report?
A: Yes. A pre-shipment test report and photographic record are available upon request at no additional charge.
Q: What is the lead time?
A: In-stock units ship within 1–3 business days from Xiamen, China. DHL Express delivery to most destinations: 3–7 business days.
Q: Do you accept returns?
A: Yes, within 30 days of receipt if the unit is found to be non-functional on arrival and the issue is confirmed by our technical team.
