ABB MPRC086444-001 — Measurement Process Board | AC800M DCS Platform
Engineering Background: The ABB MPRC086444-001 (part number 086444-001) is a dedicated Measurement Process Board engineered for ABB’s AC800M Distributed Control System (DCS) platform — one of the most widely deployed process automation architectures in power generation, oil & gas, pulp & paper, and chemical processing industries. This board serves as a critical signal conditioning and measurement interface layer within the AC800M controller cabinet.
Product Positioning: Designed for procurement engineers and MRO specialists sourcing verified replacement or expansion modules for existing AC800M installations. Konmask.com supplies this module with full traceability documentation, enabling fast integration into live production environments with minimal downtime risk.
Complete Technical Specifications
- Part Number: 086444-001
- ABB Catalog Number: MPRC086444-001
- Module Type: Measurement Process Board
- Platform Compatibility: ABB AC800M DCS
- Form Factor: PCB / Plug-in Module
- Weight: 380 g (approx.)
- Manufacturer: ABB Ltd. (Switzerland)
- Country of Origin: Sweden / EU (ABB production)
- Condition: New / Refurbished-Tested (specify at inquiry)
- Warranty: 12-month Konmask quality warranty
- Lead Time: In-stock — ships within 1–3 business days
Proven Application Environments
- Power plant DCS control cabinets (coal, gas, hydro, nuclear auxiliary systems)
- Oil & gas upstream/downstream process control loops
- Pulp & paper mill automation systems
- Chemical and petrochemical batch/continuous process control
- Water treatment and municipal utility SCADA/DCS integration
- Pharmaceutical manufacturing process monitoring
Engineering Advantages
- Drop-in Replacement: Direct form-fit-function replacement for existing AC800M installations — no firmware reconfiguration required in most deployments.
- Signal Integrity: Precision measurement circuitry ensures accurate analog signal conditioning critical for closed-loop process control.
- Proven Reliability: ABB AC800M platform has a documented MTBF exceeding industry benchmarks for process DCS hardware.
- Reduced Downtime: In-stock availability at Konmask eliminates typical 8–16 week OEM lead times for obsolete or long-lead ABB modules.
- Backward Compatibility: Compatible with legacy AC800M firmware revisions and Freelance/800xA engineering environments.
System Architecture & Signal Flow
Within the AC800M architecture, the MPRC086444-001 Measurement Process Board interfaces between field-level sensors/transmitters and the main processor module (PM8xx series). It handles analog input signal conditioning, scaling, and digitization before passing process values to the controller’s execution environment. The board communicates via the AC800M internal backplane bus, ensuring deterministic data transfer aligned with the controller’s scan cycle.
Typical signal flow: Field Sensor → Terminal Unit → MPRC086444-001 → AC800M Backplane → PM8xx Processor → 800xA/Freelance SCADA
Sourcing & Quality Verification
- Source Traceability: All modules sourced from decommissioned plant upgrades, authorized distributors, or OEM-certified channels.
- Incoming Inspection: 100% visual inspection, PCB integrity check, and functional power-on test prior to shipment.
- Anti-Counterfeit Measures: Label verification, date code cross-reference, and component-level spot checks performed on every unit.
- Documentation Package: Certificate of conformance, test report, and packing list included with every shipment.
- Export Compliance: ECCN classification reviewed; export documentation available for international orders.
Procurement Process
- Submit RFQ: Email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Receive Quote: Konmask responds within 4 business hours with pricing, lead time, and availability confirmation.
- Order Confirmation: Purchase order accepted via email; proforma invoice issued for prepayment or NET terms (qualified accounts).
- Quality Hold & Ship: Unit reserved, final QC completed, and shipped via DHL/FedEx with tracking number provided.
- After-Sales Support: 12-month warranty coverage; technical support available via email and phone.
Technical FAQ
Q: Is the MPRC086444-001 compatible with ABB 800xA?
A: Yes. The AC800M platform is the hardware foundation for 800xA deployments. This board is compatible with 800xA engineering and runtime environments.
Q: Can this board be used with Freelance DCS?
A: The MPRC086444-001 is specific to the AC800M hardware family. Freelance uses a different controller architecture (AC900F/AC700F). Please confirm your controller model before ordering.
Q: What is the difference between 086444-001 and MPRC086444-001?
A: 086444-001 is ABB’s internal part number; MPRC086444-001 is the full catalog/ordering number. Both refer to the identical module.
Q: Do you provide a test report?
A: Yes. A functional test report is included with every shipment at no additional charge.
Q: What are your payment terms?
A: T/T (wire transfer) prepayment is standard. NET-30 terms available for qualified institutional buyers with approved credit application.
