ABB IIRMR02 Residual Current Circuit Breaker | Replacement, Equivalent & Selection Guide
The ABB IIRMR02 is a Residual Current Circuit Breaker (RCBO) engineered for reliable ground-fault and overcurrent protection in industrial and commercial electrical systems. This page provides a comprehensive selection guide, compatible replacement models, and technical specifications to help engineers and procurement teams make informed sourcing decisions.
Technical Specifications
- Manufacturer: ABB
- Model / SKU: IIRMR02
- Product Type: Residual Current Circuit Breaker (RCBO)
- Series: IIRMR
- Function: Combined overcurrent & residual current protection
- Mounting: DIN Rail
- Weight: 1,110 g
- Standards: IEC 61009 / EN 61009
- Origin: ABB Group (Global Manufacturing)
Compatible Replacement & Equivalent Models
The following models are commonly evaluated as replacements or equivalents for the ABB IIRMR02. Always verify electrical ratings, trip characteristics, and mounting dimensions before substitution:
- ABB F202 Series – ABB’s modular RCCB line; verify pole count and sensitivity rating
- ABB DS201 Series – RCBO with integrated overcurrent protection; direct functional equivalent candidate
- Schneider Electric iID / iDPN Vigi – Cross-brand RCBO equivalent; confirm frame size and breaking capacity
- Siemens 5SU1 Series – Compatible RCBO for DIN rail; check tripping class and rated current
- Legrand DX³ RCBO – European-standard equivalent; verify sensitivity (30 mA / 300 mA)
- Eaton FAZ-NA / PXF Series – North American and IEC variants; confirm terminal compatibility
Note: Konmask.com recommends consulting the original datasheet and your system engineer before replacing safety-critical components.
Why Choose the Original ABB IIRMR02
- ✅ OEM-grade reliability – manufactured to ABB’s stringent quality standards
- ✅ Certified performance – fully compliant with IEC 61009 for residual current protection
- ✅ Seamless integration – plug-and-play compatibility with ABB IIRMR series accessories
- ✅ Traceability – full batch traceability and factory test records available on request
- ✅ Long service life – designed for demanding industrial duty cycles
Typical Applications
- Industrial control panels and MCC (Motor Control Centers)
- Commercial building distribution boards
- Machine tool and automation system protection
- HVAC and pump motor branch circuit protection
- Renewable energy and solar inverter installations
- Data center and critical infrastructure power distribution
System Compatibility
- ABB IIRMR Series – Native series; full accessory and auxiliary contact compatibility
- ABB System pro M compact® – Compatible with modular DIN rail system
- IEC 60715 DIN Rail – Standard 35 mm DIN rail mounting
- TN-S / TN-C-S / TT earthing systems – Suitable for common European and Asian grid configurations
Selection Guide
Use the following criteria to confirm the ABB IIRMR02 is the right choice — or to identify the correct replacement:
- Step 1 – Rated Current (In): Match the ampere rating to your circuit load calculation
- Step 2 – Residual Current Sensitivity (IΔn): Confirm 30 mA (personnel protection) or 300 mA (equipment protection)
- Step 3 – Poles: Verify 1P+N, 2P, 3P, or 4P configuration matches your panel design
- Step 4 – Breaking Capacity (Icn): Ensure rated short-circuit breaking capacity meets prospective fault current at installation point
- Step 5 – Trip Characteristic: Select Type B, C, or D curve based on load type (resistive, inductive, motor)
- Step 6 – Voltage Rating: Confirm 230 V / 400 V AC compatibility with your supply
- Step 7 – Certifications: Verify CE, CCC, or other regional marks required for your project
Quality Assurance & Sourcing
All ABB IIRMR02 units supplied by Konmask.com are sourced through verified industrial distribution channels. Each unit undergoes incoming inspection including:
- Visual and dimensional verification against OEM specifications
- Packaging and label authenticity check
- Batch traceability documentation
- Optional: third-party test report available upon request
We do not supply grey-market, refurbished, or counterfeit components. All products are covered by our standard warranty and return policy.
How to Order
- SKU: IIRMR02
- Minimum Order Quantity: 1 unit
- Lead Time: In-stock items ship within 1–3 business days; contact us for bulk order lead times
- Payment: T/T, PayPal, credit card, and trade terms available for qualified buyers
- Shipping: Worldwide express and sea freight options; DDP available for select regions
- RFQ / Bulk Inquiry: Email [email protected] or call +0086 19859288691
Replacement & Compatibility FAQ
Q: Can I replace the ABB IIRMR02 with an ABB DS201?
A: The DS201 is a functional RCBO equivalent. Verify the rated current, sensitivity, and pole configuration match your installation before substituting.
Q: Is the IIRMR02 compatible with third-party auxiliary contacts?
A: ABB recommends using IIRMR series accessories. Third-party accessories may fit physically but are not guaranteed to meet safety certification requirements.
Q: What is the difference between RCBO and RCCB?
A: An RCBO (Residual Current Circuit Breaker with Overcurrent protection) combines residual current protection with overcurrent/short-circuit protection in a single device. An RCCB provides only residual current protection and requires a separate MCB for overcurrent protection.
Q: How do I verify the authenticity of an ABB IIRMR02?
A: Check the ABB hologram label, verify the serial number via ABB’s official product verification portal, and request a certificate of conformity from your supplier.
Q: Does Konmask.com offer cross-reference support?
A: Yes. Contact our technical team with your existing part number and application requirements, and we will identify the best equivalent or replacement option.
