ABB PIB-03 (3HS0864-01 / 3HS1170-01 / 3HNA023282-001 / 3HAC047577-002) Robot Drive Board Axis 4/5/6 Type D | Replacement, Equivalent & Selection Guide
The ABB PIB-03 is a precision robot drive interface board designed for Axis 4, 5, and 6 (Type D) on ABB industrial robots. Cross-referenced under part numbers 3HS0864-01, 3HS1170-01, 3HNA023282-001, and 3HAC047577-002, this board is a critical component in ABB’s servo drive chain. Konmask.com specializes in sourcing, verifying, and supplying genuine and compatible replacements for this module.
Technical Specifications
- Manufacturer: ABB Robotics
- Part Name: PIB-03 — Power Interface Board / Drive Board
- Cross-Reference Part Numbers: 3HS0864-01 | 3HS1170-01 | 3HNA023282-001 | 3HAC047577-002
- Applicable Axes: Axis 4, Axis 5, Axis 6
- Drive Type: Type D
- Application: ABB Industrial Robot Servo Drive System
- Form Factor: PCB Module
- Weight: ~500 g (packaged)
- Origin: Sweden (ABB Robotics)
Compatible Replacement & Equivalent Models
The following part numbers are confirmed cross-references or functional equivalents for the ABB PIB-03 drive board. Always verify firmware revision and robot model compatibility before substitution:
- 3HS0864-01 — Original ABB part number (early revision)
- 3HS1170-01 — Revised ABB part number (later production run)
- 3HNA023282-001 — ABB OEM catalog reference
- 3HAC047577-002 — ABB spare parts catalog number
- Third-party compatible boards may be available — contact Konmask for verified alternatives
Why Choose the Original Model
- Factory-calibrated for ABB servo drive tolerances on Axis 4/5/6
- Full compatibility with ABB IRC5 and S4C+ controller firmware
- Eliminates re-tuning and axis calibration after replacement
- Backed by ABB’s quality and traceability standards
- Reduces downtime risk versus unverified third-party alternatives
Typical Applications
- ABB IRB 6400 / IRB 6600 / IRB 6650 series robots (Axis 4–6)
- ABB IRB 4400 / IRB 4600 series (wrist drive axes)
- Automotive body welding and assembly lines
- Foundry and heavy-duty material handling robots
- Servo drive board replacement during preventive maintenance
- Emergency repair to minimize production line downtime
System Compatibility
- Controller: ABB IRC5, S4C+
- Drive Series: Type D (Axis 4, 5, 6)
- Communication: ABB internal drive bus
- Firmware: Compatible with standard ABB robot firmware revisions — confirm revision with your robot serial number
Selection Guide
Use the table below to confirm the correct part for your robot:
- Step 1: Identify your robot model and serial number
- Step 2: Confirm the faulty axis (Axis 4, 5, or 6) and drive type (Type D)
- Step 3: Match your existing board’s part number to the cross-reference list above (3HS0864-01 / 3HS1170-01 / 3HNA023282-001 / 3HAC047577-002)
- Step 4: Check firmware revision compatibility with your IRC5 or S4C+ controller
- Step 5: Contact Konmask if you need a verified equivalent or have a non-standard configuration
Quality Assurance & Sourcing
- All units sourced from authorized ABB distributors or verified surplus channels
- Each board inspected and tested before shipment
- Traceability documentation available on request
- Packaging: anti-static ESD bag + foam-padded carton
- Warranty: 90-day replacement warranty against DOA or manufacturing defects
How to Order
- Add to cart directly, or contact us for bulk/project pricing
- Provide your robot model, serial number, and existing part number for fastest processing
- Lead time: in-stock units ship within 1–3 business days; sourced units 5–15 business days
- Email: support@konmask.com
- Phone/WhatsApp: +0086 19859288691
Replacement & Compatibility FAQ
Q: Can 3HS0864-01 and 3HS1170-01 be used interchangeably?
A: In most cases yes — they are successive revisions of the PIB-03 board. Confirm with your robot’s service manual or contact us.
Q: Is 3HAC047577-002 the same as 3HNA023282-001?
A: These are different catalog reference formats for the same functional board. Cross-check with your ABB spare parts list.
Q: Will this board work on Axis 1, 2, or 3?
A: No. The PIB-03 Type D is specifically designed for Axis 4, 5, and 6. Different drive boards are required for Axes 1–3.
Q: Do you offer exchange/repair service?
A: Yes — contact us for board repair or exchange pricing.
