Industrial Storage Solution – ADVANTECH 610H IPC-610L E5300 | Compact Flash
Purpose-built Compact Flash storage for the ADVANTECH IPC-610L industrial chassis paired with the Intel E5300 processor. Engineered for shock-resistant, fanless, and vibration-tolerant embedded computing environments where rotating media is not an option.
Where This Product Is Used
The ADVANTECH 610H IPC-610L E5300 Compact Flash is deployed across demanding industrial and infrastructure environments, including:
- Factory Automation & PLC Host Systems — Serves as the OS and program storage drive inside IPC-610L rack-mount controllers managing production lines, conveyor systems, and robotic cells.
- SCADA & HMI Workstations — Provides reliable, write-cycle-optimized storage for SCADA runtime environments where unplanned shutdowns must not corrupt the OS image.
- Machine Vision & Inspection Systems — Supports high-speed image-capture workstations requiring deterministic I/O latency without mechanical drive interference.
- Transportation & Railway Control Cabinets — Withstands vibration and wide temperature swings in trackside and on-board computing enclosures.
- Energy & Utilities Substations — Operates reliably in EMI-rich environments typical of power distribution and grid-edge automation panels.
- Medical Device Manufacturing — Meets the uptime and data-integrity requirements of embedded controllers on regulated production equipment.
Technical Specifications
| Parameter | Value |
|---|---|
| Brand | ADVANTECH |
| Compatible Chassis | IPC-610L (610H form factor) |
| Compatible CPU | Intel Pentium Dual-Core E5300 |
| Storage Type | Compact Flash (CF) |
| Interface | CF Type I / IDE (via CF-to-IDE adapter) |
| Form Factor | Compact Flash Card |
| Operating Temperature | 0°C to 60°C (standard industrial grade) |
| Shock Resistance | 1000G / 0.5ms (typical CF spec) |
| Vibration Resistance | 20G peak-to-peak |
| Weight | 300 g (packaged) |
| SKU | 610H IPC-610L E5300 |
Why Engineers Specify This Model
- Drop-in Compatibility — Matched to the IPC-610L chassis and E5300 CPU combination; no BIOS tuning or driver conflicts.
- No Moving Parts — Eliminates HDD failure modes (head crash, bearing wear) in 24/7 industrial duty cycles.
- Deterministic Boot — Consistent POST and OS load times critical for PLC and SCADA watchdog timers.
- Low Power Draw — Reduces thermal load inside sealed or poorly ventilated control cabinets.
- Long Lifecycle Availability — ADVANTECH maintains extended product availability commitments aligned with industrial project timelines (5–10 year horizons).
- Proven Platform — IPC-610L with E5300 is a widely deployed baseline in Asian and global factory automation; replacement CF units are a known maintenance SKU.
Complete System Bill of Materials
Typical BOM for an IPC-610L E5300 control workstation using this Compact Flash:
- ADVANTECH IPC-610L — 4U rackmount industrial chassis
- Intel Pentium Dual-Core E5300 — Host CPU
- ADVANTECH 610H IPC-610L E5300 Compact Flash — This item
- DDR2 ECC RAM (2 GB / 4 GB) — System memory
- CF-to-IDE or CF-to-SATA adapter card — Storage interface bridge
- ADVANTECH PCM-9362 or compatible SBC — (if SBC-based configuration)
- 24 VDC DIN-rail PSU — Panel power supply
- Ethernet switch (managed, industrial grade) — Network backbone
Compliance & Industry Standards
- CE Marking — EMC Directive 2014/30/EU
- FCC Part 15 Class A — Radiated emissions compliance
- RoHS 2 Compliant — Restriction of Hazardous Substances
- ISO 9001 Manufacturing — ADVANTECH certified production facilities
- CompactFlash Association (CFA) Standard — CF 6.0 specification compliant
Quality Assurance & Sourcing
Konmask.com sources ADVANTECH Compact Flash modules through authorized distribution channels and verified secondary-market suppliers with full traceability. Every unit undergoes:
- Visual inspection for connector integrity and label authenticity
- Functional read/write verification prior to dispatch
- Anti-static packaging with humidity indicator card
- Batch-level documentation retained for warranty and audit purposes
We do not supply remarked, refurbished-as-new, or counterfeit components. Authenticity queries are welcome before purchase.
How to Source This Part
- Add to Cart — Place your order directly on this page for in-stock units.
- Request a Quote — For volume orders (5+ units) or project BOM pricing, email support@konmask.com.
- Lead Time — Standard orders ship within 3–7 business days. Expedited options available on request.
- Export & Cross-border — We support international shipments with commercial invoice and packing list documentation for customs clearance.
- Technical Pre-sales — Contact us to confirm compatibility with your specific IPC-610L revision or OS image before ordering.
Application-Specific FAQ
Q: Is this CF card compatible with Windows XP Embedded and Windows 7 Embedded Standard?
A: Yes. The IPC-610L E5300 platform was widely deployed with both XP Embedded and WES7. The CF card functions as a standard IDE storage device and is OS-agnostic.
Q: What capacity options are available?
A: Please contact us to confirm current stock capacities (typically 2 GB, 4 GB, or 8 GB). Capacity requirements depend on your OS image and application footprint.
Q: Can this replace a failed HDD in an existing IPC-610L system?
A: Yes, with a CF-to-IDE adapter. This is a common field upgrade to eliminate mechanical drive failure risk in aging systems.
Q: Do you provide OS pre-loading services?
A: We can discuss custom pre-load arrangements for volume orders. Contact us with your OS image and configuration requirements.
Q: What is the warranty period?
A: 12 months from date of shipment, covering manufacturing defects. Does not cover damage from incorrect installation or ESD mishandling.
