Advantech MIC-3392A – High-Performance CompactPCI Processor Board | MIC Series Platform
Engineering Background
The Advantech MIC-3392A is a 6U CompactPCI single-board computer engineered for mission-critical embedded computing environments. Built on the proven MIC (Modular Industrial Computing) platform, this board delivers the processing power of Intel’s Core 2 Duo architecture within the rugged, hot-swap-capable CompactPCI form factor—making it the preferred choice for system integrators in defense, transportation, telecommunications, and industrial automation.
Product Positioning
Designed for procurement engineers who require a long-lifecycle, standards-compliant processor board with deterministic performance, the MIC-3392A bridges legacy CompactPCI infrastructure with modern x86 computing. It is fully compatible with PICMG 2.0 R3.0 and supports both system-slot and peripheral-slot deployment, enabling flexible chassis integration without hardware redesign.
Complete Technical Specifications
- Model / SKU: MIC-3392A
- Manufacturer: Advantech Co., Ltd.
- Form Factor: 6U CompactPCI (PICMG 2.0 R3.0)
- Processor: Intel Core 2 Duo (Merom/Penryn family)
- Bus Interface: 32/64-bit CompactPCI, 33/66 MHz
- Memory: Up to 4 GB DDR2 SDRAM (2 × SODIMM slots)
- Storage: CompactFlash socket + SATA HDD/SSD support
- Graphics: Integrated Intel GMA graphics with VGA output
- Networking: Dual Gigabit Ethernet (Intel 82573L / 82541PI)
- Serial I/O: 2 × RS-232/422/485 COM ports
- USB: 4 × USB 2.0 ports
- Operating System Support: Windows XP/7, VxWorks, Linux (kernel 2.6+)
- Operating Temperature: 0°C to +60°C (standard); -40°C to +85°C (extended, variant-dependent)
- Power Consumption: Typical 25 W (processor + board)
- Weight: Approx. 300 g
- Compliance: CE, FCC Class A, RoHS
- MTBF: >100,000 hours (MIL-HDBK-217F, ground benign)
Proven Application Environments
- Defense & Aerospace: Radar signal processing, mission computers, ground support equipment
- Transportation: Railway control systems, in-vehicle computing, traffic management
- Telecommunications: Media gateways, protocol converters, network appliances
- Industrial Automation: SCADA hosts, PLC co-processors, HMI controllers
- Test & Measurement: Automated test equipment (ATE), data acquisition systems
Engineering Advantages
- PICMG 2.0 R3.0 Compliance: Drop-in replacement for existing CompactPCI chassis without backplane modification
- Hot-Swap Support: Enables live board replacement for high-availability systems with zero downtime
- Dual GbE Ports: Supports redundant network paths and high-throughput data pipelines
- Long Product Lifecycle: Advantech’s 5+ year product availability commitment reduces redesign risk
- Wide OS Ecosystem: Validated BSPs for VxWorks, Linux, and Windows reduce software integration time
- Rugged Thermal Design: Conduction-cooled variant available for sealed enclosure deployments
System Architecture & Signal Flow
The MIC-3392A occupies the system slot (J1/J2 connectors) of a standard 6U CompactPCI chassis. The Intel Core 2 Duo processor communicates with the CompactPCI backplane via the Intel 945GM/ICH7-M chipset, providing PCI bus mastering capability at up to 66 MHz. Front-panel I/O (VGA, USB, COM, GbE) is routed through the board’s front-panel bracket, while rear I/O expansion is available via the J3/J4/J5 connectors for PMC mezzanine modules or custom rear-transition modules (RTMs). The dual Gigabit Ethernet controllers operate independently on separate PCI buses, ensuring network traffic isolation for safety-critical applications.
Sourcing & Quality Verification
- Source: Konmask.com sources MIC-3392A units from authorized Advantech distribution channels and verified secondary-market suppliers with full traceability documentation.
- Inspection: Every board undergoes incoming visual inspection, functional power-on test, and POST verification before shipment.
- Authenticity: Boards are supplied with original Advantech labels, revision markings, and where available, original packaging and documentation.
- Warranty: 90-day functional warranty against DOA and latent defects. Extended warranty available upon request.
Procurement Process
- Submit RFQ: Contact support@konmask.com with your required quantity, delivery timeline, and any special configuration requirements.
- Quotation: Receive a formal quotation within 1 business day including unit price, lead time, and shipping options.
- Order Confirmation: Place order via the Konmask.com storefront or via purchase order (PO) for qualified B2B accounts.
- Inspection & Dispatch: Board is tested, packed with ESD protection, and dispatched with tracking within 2–5 business days.
- After-Sales Support: Technical support available via email and phone for integration assistance.
Technical FAQ
Q: Is the MIC-3392A compatible with 3U CompactPCI chassis?
A: No. The MIC-3392A is a 6U form factor board and requires a 6U CompactPCI chassis with a PICMG 2.0-compliant backplane.
Q: Can the MIC-3392A operate as a peripheral slot board?
A: The MIC-3392A is designed as a system-slot (host) board. Peripheral-slot operation requires a separate system controller; consult Advantech’s chassis compatibility matrix.
Q: What is the maximum RAM supported?
A: The board supports up to 4 GB DDR2 SDRAM across two SODIMM slots (2 × 2 GB).
Q: Is a BSP available for Linux?
A: Yes. Advantech provides a Linux BSP (kernel 2.6.x) with drivers for all on-board peripherals. Contact Konmask.com for access to the BSP package.
Q: What export control classification applies?
A: The MIC-3392A may be subject to EAR (Export Administration Regulations) controls. Buyers are responsible for verifying applicable export license requirements for their jurisdiction.
