Advantech MIC-3395MILS3-P8E Industrial Motherboard | Replacement, Equivalent & Selection Guide
The Advantech MIC-3395MILS3-P8E is a high-performance CompactPCI Serial (CPCI-S.0) industrial motherboard designed for demanding automation, defense, and transportation applications. This page provides full technical specifications, compatible replacement models, and a structured selection guide to help engineers and procurement teams make the right sourcing decision.
Technical Specifications
- Part Number: MIC-3395MILS3-P8E
- Series: MIC-3395
- Brand: Advantech
- Form Factor: CompactPCI Serial (CPCI-S.0), 6U
- Processor: Intel® Core™ i7/i5/i3 (3rd Gen, Ivy Bridge)
- Chipset: Intel® QM77
- Memory: Up to 16 GB DDR3 SO-DIMM, 1600 MHz
- Storage: 1× mSATA, 1× CFast slot
- Display: VGA, DVI-I
- Expansion: 8× PCIe x1 via backplane (P8E suffix)
- I/O: 4× USB 3.0, 2× GbE LAN, 2× RS-232/422/485 COM
- Operating Temperature: -40°C to +85°C (MIL-grade)
- Power Input: CompactPCI Serial backplane power
- Weight: ~3.6 kg (with chassis)
- Certifications: CE, FCC, MIL-STD-810G
- OS Support: Windows 10 IoT, Linux, VxWorks
Compatible Replacement & Equivalent Models
If the MIC-3395MILS3-P8E is unavailable or end-of-life, the following models offer functional equivalence or direct drop-in replacement:
- Advantech MIC-3395MILS3-P4E — Same board, 4× PCIe slots variant; suitable when fewer expansion slots are required.
- Advantech MIC-3392 — Predecessor 6U CPCI-S.0 board with Intel® Sandy Bridge; compatible backplane pinout.
- Kontron VX3042 — 6U VPX alternative with similar Ivy Bridge CPU; requires VPX backplane.
- Emerson/Artesyn ATCA-7365 — ATCA form factor equivalent for telecom-grade deployments.
- GE Intelligent Platforms IPN250 — CompactPCI equivalent for rugged military applications.
Contact Konmask.com to verify pin-compatibility and firmware requirements before substitution.
Why Choose the Original Model
- MIL-grade temperature range (-40°C to +85°C) ensures reliability in extreme environments.
- Intel® QM77 chipset provides long-term supply chain stability and driver support.
- 8× PCIe x1 expansion (P8E) maximizes I/O density for complex control architectures.
- Advantech’s WISE-PaaS ecosystem integration enables IIoT-ready deployments.
- Proven in defense, rail, and energy automation projects worldwide.
Typical Applications
- Railway signaling and train control systems (TCMS)
- Military and defense embedded computing
- Industrial automation and SCADA controllers
- Power grid monitoring and substation automation
- Medical imaging and diagnostic equipment
- Transportation infrastructure management
System Compatibility
- Backplane: CompactPCI Serial (CPCI-S.0) 6U backplane with P8 connector
- Chassis: Advantech MIC-5600 series, MIC-5700 series
- OS: Windows 10 IoT Enterprise, Ubuntu 20.04 LTS, Wind River VxWorks 7
- BSP: Advantech-provided Board Support Package available for Linux and VxWorks
- Software: Compatible with Advantech WISE-PaaS, Node-RED, and standard SCADA platforms
Selection Guide
| Requirement | Recommended Model | Reason |
|---|---|---|
| Max PCIe expansion (8 slots) | MIC-3395MILS3-P8E | P8E suffix = 8× PCIe x1 |
| Fewer slots, lower cost | MIC-3395MILS3-P4E | P4E suffix = 4× PCIe x1 |
| Standard temp range (0–60°C) | MIC-3395S3-P8E | Commercial grade variant |
| VPX form factor needed | Kontron VX3042 | Compatible CPU, different bus |
| Legacy CPCI (non-serial) | Advantech MIC-3392 | Backward-compatible predecessor |
Quality Assurance & Sourcing
- All units sourced from authorized distributors or verified surplus channels.
- Each board undergoes functional power-on testing and visual inspection before shipment.
- Authenticity verified via Advantech serial number lookup where applicable.
- Packaging: ESD-safe anti-static bag + foam-lined carton.
- Warranty: 90-day return-to-base warranty on all stocked units.
How to Order
- Confirm your backplane connector type (P4 or P8) and chassis model.
- Specify OS and BSP requirements (Windows IoT / Linux / VxWorks).
- Contact [email protected] or call +0086 19859288691 for stock availability and lead time.
- Submit PO with full part number: MIC-3395MILS3-P8E.
- Receive order confirmation with tracking within 1 business day.
Replacement & Compatibility FAQ
Q: Can MIC-3395MILS3-P4E replace MIC-3395MILS3-P8E?
A: Yes, if your application uses 4 or fewer PCIe expansion cards. The CPU, memory, and I/O are identical.
Q: Is this board compatible with older CompactPCI (non-serial) backplanes?
A: No. CPCI-S.0 (CompactPCI Serial) uses a different connector standard than legacy CPCI. An adapter or new backplane is required.
Q: What is the end-of-life status of MIC-3395?
A: Advantech has transitioned to newer platforms (MIC-3396 series). MIC-3395 units are available as new-old-stock (NOS) or refurbished. Contact us for current inventory.
Q: Can I run Windows 11 on this board?
A: Windows 11 requires TPM 2.0 and a supported CPU generation. The Ivy Bridge CPU on MIC-3395 does not officially support Windows 11. Windows 10 IoT LTSC is recommended.
Q: Do you provide a Certificate of Conformance (CoC)?
A: Yes, CoC is available upon request for all orders.
