ADVANTECH MIC-3392MILS | PICMG 1.3 Full-Size SHB Motherboard | Replacement, Equivalent & Selection Guide
The ADVANTECH MIC-3392MILS is a full-size PICMG 1.3 System Host Board (SHB) designed for demanding industrial computing applications. Built on the Intel® Core™ i7/i5/i3 (Sandy Bridge / Ivy Bridge) platform, it delivers high-performance processing, robust I/O expansion, and long-lifecycle support — making it a preferred choice for automation, machine vision, and embedded control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | MIC-3392MILS |
| Form Factor | Full-Size PICMG 1.3 SHB |
| CPU Support | Intel® Core™ i7 / i5 / i3 (LGA1155, Sandy Bridge / Ivy Bridge) |
| Chipset | Intel® QM77 / HM77 |
| Memory | Up to 16 GB DDR3 1333/1600 MHz (2× SO-DIMM) |
| Graphics | Intel® HD Graphics (VGA, DVI, LVDS via backplane) |
| Storage Interface | 2× SATA III (6 Gb/s), 1× mSATA |
| Expansion | 1× PCIe x16, 4× PCIe x1, 1× PCI (via PICMG 1.3 backplane) |
| Ethernet | 2× Intel® GbE LAN (82574L) |
| USB | 4× USB 3.0, 4× USB 2.0 |
| Serial Ports | 2× RS-232/422/485 (COM1/COM2) |
| Operating Temperature | 0°C to 60°C |
| Power Input | Via PICMG 1.3 backplane |
| OS Support | Windows 7/10, Linux, WES7 |
| Dimensions | 338 mm × 122 mm (Full-Size SHB) |
Compatible Replacement & Equivalent Models
If the MIC-3392MILS is discontinued, out of stock, or over budget, the following models offer compatible or equivalent functionality:
| Model | Brand | Form Factor | CPU Platform | Key Difference |
|---|---|---|---|---|
| MIC-3392MILS | ADVANTECH | PICMG 1.3 Full-Size | Intel LGA1155 | Original model |
| MIC-3392F | ADVANTECH | PICMG 1.3 Full-Size | Intel LGA1155 | Fanless variant |
| MIC-3395 | ADVANTECH | PICMG 1.3 Full-Size | Intel LGA1150 (Haswell) | Next-gen upgrade |
| MIC-3397 | ADVANTECH | PICMG 1.3 Full-Size | Intel LGA1151 (Skylake) | 6th/7th Gen upgrade |
| PCIE-9150 | ADLINK | PICMG 1.3 Full-Size | Intel LGA1155 | Cross-brand equivalent |
| SHB106 | Axiomtek | PICMG 1.3 Full-Size | Intel LGA1155 | Cross-brand equivalent |
Note: Always verify backplane pinout and BIOS compatibility before substitution. Contact Konmask for pre-sales validation.
Why Choose the Original MIC-3392MILS
- Proven Reliability: ADVANTECH’s industrial-grade design with extended lifecycle support.
- PICMG 1.3 Compliance: Full compatibility with standard PICMG 1.3 backplanes and chassis.
- Dual GbE: Redundant network connectivity for mission-critical applications.
- Wide OS Support: Compatible with Windows, Linux, and embedded OS variants.
- Flexible I/O: USB 3.0, dual RS-232/422/485, SATA III, and mSATA onboard.
- Long-Term Availability: Konmask maintains stock of legacy and current ADVANTECH SHB modules.
Typical Applications
- Industrial automation and PLC-integrated control systems
- Machine vision and image processing platforms
- Railway and transportation computing
- Medical imaging and diagnostic equipment
- Defense and aerospace embedded computing
- SCADA and HMI workstations
System Compatibility
The MIC-3392MILS is compatible with PICMG 1.3-compliant backplanes and chassis. Verified compatible systems include:
- ADVANTECH MIC-5302 / MIC-5304 / MIC-5308 chassis
- ADVANTECH PCA-6113 / PCA-6114 backplanes
- Standard 14-slot and 20-slot PICMG 1.3 passive backplanes from major vendors
Confirm slot configuration and power delivery with your backplane vendor before deployment.
Selection Guide
Use this guide to determine whether the MIC-3392MILS or an alternative best fits your project:
| Requirement | Recommended Model |
|---|---|
| Direct drop-in replacement (LGA1155) | MIC-3392MILS or MIC-3392F |
| Higher CPU performance (Haswell) | MIC-3395 |
| Latest platform (Skylake/Kaby Lake) | MIC-3397 |
| Cross-brand ADLINK equivalent | PCIE-9150 |
| Cross-brand Axiomtek equivalent | SHB106 |
| Fanless / low-power variant | MIC-3392F |
Not sure which model fits your system? Contact our engineers for a free selection consultation.
