Genuine Agilent 5517DC30 / 5517D-C19 Laser Head | 5517 Series – Verified Source
Konmask.com supplies authentic Agilent (Keysight) 5517DC30 and 5517D-C19 laser heads — precision helium-neon laser sources engineered for high-accuracy interferometric measurement systems. Each unit is sourced through verified channels and undergoes our in-house quality inspection before dispatch.
Part Numbers Covered: 4022.456.48221 | 4022.454.71615 | 4022.454.71616
Technical Specifications
- Model: 5517DC30 / 5517D-C19
- Part Numbers: 4022.456.48221 / 4022.454.71615 / 4022.454.71616
- Type: Two-frequency HeNe Laser Head
- Series: Agilent / Keysight 5517 Laser Series
- Wavelength: 632.991 nm (vacuum)
- Frequency Split: DC30 variant — up to 3.0 MHz; C19 variant — up to 1.9 MHz
- Output Power: Typically 0.5 mW
- Beam Diameter: ~6 mm (1/e²)
- Operating Temperature: 10 °C – 40 °C
- Warm-up Time: ≤ 20 minutes to full specification
- Weight: Approx. 2.6 kg
- Compatible Controllers: Agilent/Keysight 5505A, 5506A, 5508A, 10885A
Our 4-Step Quality Verification Process
- Source Authentication — Every unit is traced to an authorized distributor or OEM-certified channel. No grey-market or counterfeit stock.
- Visual & Mechanical Inspection — Housing, connectors, labels, and serial numbers are checked against Agilent/Keysight factory standards.
- Functional Power-On Test — Laser output is verified to confirm the unit powers on and produces a stable beam within specification.
- Secure Packaging & Documentation — Units are packed in anti-static, shock-absorbing materials with inspection records included.
Key Features & Benefits
- ✅ Genuine OEM Part — Agilent / Keysight factory-manufactured, not a clone or substitute
- ✅ Dual-Model Coverage — Covers both 5517DC30 and 5517D-C19 variants under one listing for easy procurement
- ✅ Drop-in Replacement — Direct replacement for existing 5517-series laser heads with no system reconfiguration required
- ✅ Stable Frequency Output — Critical for sub-nanometer positioning accuracy in semiconductor and precision manufacturing
- ✅ Long Service Life — HeNe laser tube rated for extended operational hours under normal use conditions
- ✅ Traceable Calibration — Wavelength traceable to NIST/SI standards for metrology compliance
Typical Applications
- Semiconductor wafer stage positioning and lithography alignment
- CNC machine tool calibration and volumetric error mapping
- Coordinate Measuring Machine (CMM) laser scale verification
- Precision optics and photonics R&D laboratories
- Aerospace component dimensional inspection
- National metrology institute (NMI) reference standards
Compatible System Components
- Laser Controllers: Agilent/Keysight 5505A, 5506A, 5508A, 10885A
- Interferometer Optics: 10702A, 10703A, 10705A, 10706A, 10715A, 10716A
- Measurement Boards: Agilent E1826A, 10897B, 10898A
- Receivers: 10780A, 10780C, 10780F
- Environmental Compensation: 10717A Wavelength Tracker, 10737A Refractometer
Global Sourcing & Shipping Capabilities
Konmask.com ships worldwide from our warehouse in China. We support the following logistics options:
- Express (DHL / FedEx / UPS): 3–7 business days to most destinations
- Air Freight: Available for bulk or urgent orders
- Sea Freight: Cost-effective option for large-volume procurement
- Export Documentation: Commercial invoice, packing list, and CO (Certificate of Origin) provided upon request
- Customs Support: HS Code 9013.20 (laser devices); we assist with customs declarations
Certifications & Compliance Statement
- CE Marking: Compliant with EU Machinery Directive and Low Voltage Directive (as per OEM documentation)
- FDA / CDRH: Class IIIa / Class 3R laser product per 21 CFR 1040.10
- RoHS: Agilent/Keysight production units comply with RoHS Directive 2011/65/EU
- ISO 9001: Konmask.com operates under ISO 9001-aligned quality management practices for sourcing and inspection
- Laser Safety: Operators must follow IEC 60825-1 laser safety guidelines during installation and use
How to Order
- Confirm Part Number — Verify your required P/N: 4022.456.48221, 4022.454.71615, or 4022.454.71616
- Request a Quote — Contact us at [email protected] for volume pricing or lead time confirmation
- Place Order — Add to cart and complete checkout, or send a purchase order via email
- Receive & Verify — Inspect the unit upon arrival; our team supports any post-delivery technical questions
📞 Phone / WhatsApp: +0086 19859288691
📧 Email: [email protected]
🌐 Website: https://Konmask.com
Authenticity & Trust FAQ
Q: Are these genuine Agilent / Keysight parts?
A: Yes. All units are sourced from verified OEM or authorized distribution channels. We do not sell clones, refurbished-as-new, or unbranded substitutes.
Q: Can you provide a certificate of authenticity?
A: We provide inspection records and sourcing documentation. For formal COA requirements, please contact us before ordering.
Q: What if the unit does not meet specifications upon arrival?
A: We offer a return and replacement policy. Contact [email protected] within 7 days of receipt with photos and a description of the issue.
Q: Do you offer warranty?
A: A 90-day functional warranty is provided on all laser heads sold through Konmask.com, covering defects attributable to the unit itself under normal operating conditions.
Q: Can you source other Agilent / Keysight laser or interferometer parts?
A: Yes. We maintain an extensive sourcing network for the full Agilent/Keysight 5500-series ecosystem. Send your BOM or part list to [email protected].
