Engineering Background
The Allen-Bradley 150-F108NBDB is part of Rockwell Automation’s SMC-Flex platform — a field-proven, full-voltage soft-start motor controller engineered for demanding industrial environments. Designed to reduce mechanical stress during motor start/stop cycles, it extends drivetrain life and minimizes inrush current, making it the preferred choice for procurement engineers specifying reliable motor control in process, manufacturing, and infrastructure applications.
Product Positioning
The 150-F108NBDB targets 108A continuous-duty applications up to 600VAC, with integrated DeviceNet (NBDB suffix) communications for seamless integration into Allen-Bradley/Rockwell control architectures. It replaces traditional star-delta starters and across-the-line contactors where soft-start, current limiting, and network diagnostics are required.
Complete Technical Specifications
| Parameter | Value |
|---|---|
| Part Number / SKU | 150-F108NBDB |
| Series / Platform | SMC-Flex |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Continuous Current Rating | 108 A |
| Supply Voltage | 200–600 VAC, 3-Phase, 50/60 Hz |
| Control Voltage | 100–240 VAC |
| Communication Option | DeviceNet (NBDB) |
| Enclosure Type | Open / Panel Mount (IP00) |
| Start Modes | Soft Start, Current Limit, Full Voltage, Preset Slow Speed |
| Stop Modes | Soft Stop, Coast-to-Rest, Braking |
| Protection Features | Electronic Overload, Phase Loss, Stall, Jam, Underload |
| Bypass Contactor | Internal (built-in) |
| Approvals / Certifications | UL, CE, CSA |
| Weight | ~15 kg |
| Catalog / Series Code | 150-F (Frame F) |
Proven Application Environments
- Pumping Systems: Water treatment, irrigation, and HVAC chilled-water pumps — eliminates water hammer on start/stop.
- Conveyor & Material Handling: Reduces belt slip and mechanical shock on heavy-load conveyors.
- Compressors & Blowers: Limits inrush current and extends compressor valve life.
- Fans & Ventilation: Smooth acceleration prevents gearbox and coupling fatigue.
- Mixers & Agitators: Controlled torque ramp-up protects shaft seals and couplings.
- Oil & Gas / Petrochemical: Reliable operation in high-cycle, continuous-duty environments.
Engineering Advantages
- Integrated DeviceNet Port: Native network connectivity for real-time diagnostics, parameter configuration, and predictive maintenance via RSLogix / Studio 5000.
- Built-in Bypass Contactor: Eliminates external bypass wiring, reduces panel footprint, and lowers BOM cost.
- Comprehensive Motor Protection: Electronic overload, phase loss, jam, stall, and underload protection in a single device — no separate overload relay required.
- Adjustable Ramp Parameters: Independently configurable start/stop ramp times and current limit levels for precise process tuning.
- Energy Savings Mode: Reduces motor losses at light loads via voltage reduction algorithm.
- Compact Frame F Design: Optimized for standard MCC (Motor Control Center) bucket installation.
System Architecture & Signal Flow
The 150-F108NBDB operates as a three-phase power switching device inserted between the main disconnect and the motor terminals. The internal SCR (thyristor) stack controls voltage ramp-up during starting; the built-in bypass contactor closes at full speed to eliminate SCR heat dissipation during run. The DeviceNet interface connects to the plant-level PLC (e.g., Allen-Bradley ControlLogix / CompactLogix) via a standard DeviceNet trunk cable, enabling parameter read/write, fault logging, and remote start/stop commands. Control wiring connects to the 100–240 VAC control circuit for hardwired start/stop/enable signals.
Sourcing & Quality Verification
- All units sourced through authorized industrial distribution channels or verified surplus with full traceability documentation.
- Each unit inspected for: correct nameplate data, intact terminal blocks, undamaged SCR stack, firmware version compatibility, and DeviceNet port integrity.
- Serialization and date codes verified against Rockwell Automation production records where applicable.
- Konmask.com maintains a zero-tolerance policy on counterfeit components — all Allen-Bradley products are subject to multi-point authentication before listing.
Procurement Process
- Confirm Part Number: Verify 150-F108NBDB matches your motor FLA (Full Load Amps) and voltage requirements. Contact our engineering team if sizing assistance is needed.
- Request Quote / Stock Check: Email support@konmask.com or call +0086 19859288691 for lead time and volume pricing.
- Place Order: Secure checkout via Konmask.com. Purchase orders (PO) accepted for qualified B2B accounts.
- Shipping: Worldwide DHL / FedEx / UPS express shipping. Export documentation (commercial invoice, packing list, COO) provided for customs clearance.
- After-Sales Support: Technical commissioning support available via email. Warranty claims processed within 5 business days.
Technical FAQ
Q: What is the difference between 150-F108NBDB and 150-F108NBD?
A: The NBDB suffix indicates the DeviceNet communication option board is factory-installed. The NBD variant does not include the DeviceNet module.
Q: Can this unit be used with a VFD (Variable Frequency Drive)?
A: No. The SMC-Flex is a soft-starter, not a variable speed drive. It controls voltage during start/stop only. For variable speed operation, an Allen-Bradley PowerFlex VFD is recommended.
Q: Is the internal bypass contactor replaceable?
A: Yes. The bypass contactor is a field-replaceable component. Contact Rockwell Automation or Konmask for the correct replacement part number.
Q: What PLC platforms are compatible with the DeviceNet port?
A: Any Allen-Bradley PLC with a DeviceNet scanner module (e.g., 1756-DNB for ControlLogix, 1769-SDN for CompactLogix). Third-party DeviceNet masters are also supported per the ODVA DeviceNet specification.
Q: What is the warranty period?
A: Konmask.com provides a 90-day functional warranty on all verified surplus units. New/sealed units carry the original Rockwell Automation warranty.
