Allen-Bradley 1746-NO8V Analog Voltage Output Module – SLC 500 Series
Imagine a high-speed bottling line suddenly losing precise fill-level control, or a chemical dosing system outputting unregulated voltage to its actuators — the consequences range from costly product waste to catastrophic process failure. In modern industrial automation, the analog output module is the critical bridge between the controller’s digital logic and the physical world of drives, valves, and positioners. Without a reliable, spec-accurate module like the Allen-Bradley 1746-NO8V, entire production lines grind to a halt.
The 1746-NO8V is Allen-Bradley’s 8-channel analog voltage output module purpose-built for the SLC 500 modular I/O platform — one of the most widely deployed small-to-mid-range PLC families in global manufacturing. Offering ±10V DC output resolution across eight independent channels, this module occupies a trusted position in process control, motion coordination, and drive speed reference applications across automotive, food & beverage, water treatment, and discrete manufacturing industries worldwide.
Technical Specifications
- Part Number: 1746-NO8V
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: SLC 500 Modular I/O
- Output Type: Analog Voltage
- Number of Channels: 8
- Output Range: ±10V DC
- Resolution: 12-bit (including sign bit)
- Output Current (max): 5 mA per channel
- Backplane Current Draw: 150 mA @ 5V DC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5% to 95% non-condensing
- Module Slot Width: Single-slot
- Compatibility: SLC 500 fixed and modular chassis
- Certifications: UL, CSA, CE
Note: All specifications are sourced from official Allen-Bradley/Rockwell Automation documentation. Konmask.com does not fabricate or modify published specifications.
Key Features & Benefits
- 8 Independent Voltage Output Channels — Simultaneously control up to 8 analog devices from a single module slot, maximizing chassis density and reducing wiring complexity.
- ±10V DC Bipolar Output — Supports both positive and negative voltage references, essential for reversible drive control and servo positioning applications.
- 12-Bit Resolution — Delivers fine-grained output precision for demanding process control loops where coarse steps cause instability.
- Single-Slot Form Factor — Conserves valuable SLC 500 chassis slots, leaving room for expansion as your system grows.
- Direct SLC 500 Backplane Integration — Plug-and-play compatibility with all SLC 500 modular chassis; no external power supply required for the module itself.
- Proven Field Reliability — Designed to Rockwell Automation’s industrial-grade standards, with a track record spanning decades of continuous operation in harsh environments.
Industry & Equipment Applications
- Automotive Manufacturing: Speed reference signals to variable frequency drives (VFDs) on conveyor and assembly lines.
- Food & Beverage: Proportional valve control for liquid filling, mixing ratio regulation, and temperature setpoint output.
- Water & Wastewater Treatment: Pump speed modulation and chemical dosing actuator control.
- Chemical Processing: Continuous process variable setpoint transmission to field instruments and control valves.
- HVAC & Building Automation: Damper actuator positioning and chiller setpoint control integrated with SLC 500 building management systems.
- Discrete Manufacturing: Tension control, web guiding, and servo amplifier reference in printing and converting machinery.
System Integration & Compatible Parts
The 1746-NO8V is designed to operate within the broader Allen-Bradley SLC 500 ecosystem. Compatible and commonly paired components include:
- SLC 500 Processors: 1747-L20, 1747-L30, 1747-L40, 1747-L511, 1747-L514, 1747-L524, 1747-L531, 1747-L532, 1747-L541, 1747-L542, 1747-L543, 1747-L551, 1747-L552, 1747-L553
- SLC 500 Chassis: 1746-A4, 1746-A7, 1746-A10, 1746-A13
- Power Supplies: 1746-P1, 1746-P2, 1746-P3, 1746-P4, 1746-P5, 1746-P6, 1746-P7
- Complementary Analog Input Modules: 1746-NI4, 1746-NI8, 1746-NI16I
- Programming Software: RSLogix 500 / Studio 5000 Logix Designer (legacy compatibility)
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley 1746-NO8V module undergoes a rigorous multi-stage verification process before shipment:
- Visual Inspection: Physical examination for damage, corrosion, counterfeit markings, and label authenticity.
- Functional Bench Test: Each module is powered up and channel outputs are verified against published specifications using calibrated test equipment.
- Firmware & Revision Check: Hardware revision is documented and disclosed to the buyer prior to shipment.
- ESD-Safe Packaging: Modules are packed in anti-static bags with foam cushioning to prevent transit damage.
- Traceability Documentation: Test records and inspection reports are available upon request for MRO and OEM procurement teams.
How to Order
- Submit an inquiry via the Contact / Request a Quote form on this page, or email support@konmask.com.
- Provide your required quantity, hardware revision preference (if any), and delivery timeline.
- Receive a formal quotation with lead time, shipping options, and payment terms within 1 business day.
- Confirm the order and receive tracking information upon dispatch.
We support T/T bank transfer, PayPal, and other B2B payment methods. Export documentation (commercial invoice, packing list, COO) is provided as standard.
Why Choose Konmask.com?
- Specialist Industrial Focus: We exclusively source and supply PLC, DCS, and industrial automation components — this is our only business.
- Global Reach: We ship to over 50 countries with experience in export compliance, customs documentation, and international freight coordination.
- Transparent Stock & Lead Times: Real-time availability communicated at inquiry stage — no bait-and-switch.
- Technical Pre-Sales Support: Our team includes engineers with hands-on SLC 500 experience who can advise on compatibility and integration.
- Competitive Pricing for MRO & OEM: Volume pricing available for maintenance, repair, and operations buyers and system integrators.
Frequently Asked Questions
Q: Is the 1746-NO8V compatible with all SLC 500 chassis?
A: Yes. The 1746-NO8V is compatible with all SLC 500 modular chassis (1746-A4, A7, A10, A13) and does not require a dedicated slot type.
Q: What is the difference between 1746-NO8V and 1746-NO8I?
A: The 1746-NO8V provides voltage outputs (±10V DC), while the 1746-NO8I provides current outputs (4–20 mA). Selection depends on your field device input type.
Q: Can I use this module with a MicroLogix controller?
A: No. The 1746-NO8V is designed for the SLC 500 modular I/O backplane and is not compatible with MicroLogix fixed I/O controllers.
Q: Do you supply new, refurbished, or surplus units?
A: We supply both new-in-box and tested surplus/refurbished units. Condition is clearly stated in the quotation. All units pass our QA process regardless of condition.
Q: How long does shipping take?
A: Standard international shipping is 5–10 business days via DHL/FedEx/UPS. Express options are available. Lead time depends on stock availability confirmed at inquiry.
Q: Can you provide a certificate of conformance or test report?
A: Yes. Test reports and inspection documentation are available upon request for procurement and quality teams.
