Industrial Network Communication Solution – Allen-Bradley 1761-NET-AIC | MicroLogix Series
Where This Product Is Used
The Allen-Bradley 1761-NET-AIC is a dedicated communication adaptor engineered for industrial environments where reliable DH-485 network connectivity is critical. It is widely deployed in the following application scenarios:
- Automotive Assembly Lines – Bridges MicroLogix PLCs to SCADA systems via RS-232, enabling real-time production monitoring and fault diagnostics.
- Food & Beverage Processing Plants – Connects SLC 500 controllers to HMI panels across multi-node DH-485 networks for recipe management and batch control.
- Water & Wastewater Treatment Facilities – Provides reliable RS-232 to DH-485 protocol conversion for remote pump station monitoring and control.
- Pharmaceutical Manufacturing – Integrates MicroLogix 1000/1100/1200/1500 controllers into validated control architectures requiring audit-trail communication.
- Building Automation & HVAC Systems – Links legacy SLC 5/03 and 5/04 processors to modern BMS gateways without controller replacement.
- Material Handling & Conveyor Systems – Enables multi-drop DH-485 network topologies for coordinated conveyor sequencing and sortation logic.
Technical Specifications
| Attribute | Value |
|---|---|
| Part Number | 1761-NET-AIC |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Series | MicroLogix / SLC 500 |
| Function | DH-485 to RS-232 Communication Adaptor |
| Network Protocol | DH-485 (Data Highway 485) |
| Serial Interface | RS-232C (DB-9 connector) |
| DH-485 Port | RJ45 (8-pin modular) |
| Baud Rate | 1,200 – 19,200 bps (auto-detect) |
| Max Network Nodes | 32 nodes per DH-485 segment |
| Power Supply | Powered via DH-485 network or external 24 VDC |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (W×H×D) | Compact DIN-rail compatible form factor |
| Weight | Approx. 200 g |
| Certifications | UL Listed, CE Marked, cUL |
Why Engineers Specify This Model
- Seamless Protocol Bridging – Converts RS-232 serial communication to DH-485 network protocol without additional software configuration, reducing commissioning time.
- Multi-Drop Network Support – Supports up to 32 addressable nodes on a single DH-485 segment, ideal for distributed I/O architectures.
- Plug-and-Play Compatibility – Natively compatible with MicroLogix 1000, 1100, 1200, 1500 and SLC 5/01, 5/02, 5/03, 5/04 processors.
- Robust Industrial Design – Rated for wide temperature ranges and harsh industrial environments; no fan or moving parts for maintenance-free operation.
- Legacy System Integration – Extends the operational life of existing SLC 500 and MicroLogix installations without costly controller upgrades.
- RSLinx & RSLogix Compatible – Works directly with Rockwell Automation software tools for programming, monitoring, and diagnostics.
Complete System Bill of Materials
For a complete MicroLogix / SLC 500 communication node, engineers typically specify:
- 1761-NET-AIC – Communication Adaptor (this unit)
- 1761-CBL-PM02 or 1761-CBL-AP00 – MicroLogix programming cable
- 1747-CP3 – SLC 500 RS-232 programming cable
- 1761-L32BWA / 1761-L32AAA – MicroLogix 1200 controller (host PLC)
- 1747-L553 – SLC 5/05 processor (Ethernet-capable host)
- 1784-U2DHP – USB to DH+ / DH-485 interface (PC-side)
- 1761-NET-ENI – Ethernet interface for MicroLogix (alternative network path)
Compliance & Industry Standards
- UL 508 – Industrial Control Equipment
- CE Directive – EMC Directive 2014/30/EU & Low Voltage Directive 2014/35/EU
- cUL – Canadian Standards compliance
- RoHS Compliant – Restriction of Hazardous Substances
- IEC 61131-2 – Programmable Controllers: Equipment Requirements and Tests
- NEMA ICS 2 – Industrial Control Devices, Controllers and Assemblies
Quality Assurance & Sourcing
Every 1761-NET-AIC unit offered by Konmask.com undergoes a rigorous pre-shipment verification process:
- Visual inspection for physical damage, label integrity, and connector condition
- Functional power-on test confirming LED status indicators operate correctly
- Communication loop-back test verifying RS-232 and DH-485 port integrity
- Traceability documentation available upon request (date code, lot number)
- Sourced from authorized distributors and verified surplus channels with full chain-of-custody records
- Packaging inspected and resealed to OEM standards where applicable
How to Source This Part
Konmask.com maintains stock of the Allen-Bradley 1761-NET-AIC for immediate dispatch. To place an order or request a formal quotation:
- Online: Add to cart directly from this page and proceed to checkout
- Email RFQ: support@konmask.com – include quantity, required delivery date, and project details
- Phone / WhatsApp: +0086 19859288691 (Monday–Friday, 09:00–18:00 CST)
- Bulk Orders: Volume pricing available for orders of 5+ units – contact us for a tiered quote
- Lead Time: In-stock units ship within 1–2 business days; expedited shipping available on request
Application-Specific FAQ
Q: Can the 1761-NET-AIC connect a MicroLogix 1100 to a PC running RSLinx Classic?
A: Yes. Connect the 1761-NET-AIC between the MicroLogix 1100’s DH-485 port and the PC’s RS-232 COM port. Configure RSLinx Classic with the “DH-485” driver and select the appropriate COM port and baud rate.
Q: How many 1761-NET-AIC adaptors can exist on a single DH-485 network?
A: The DH-485 network supports up to 32 nodes total. Each 1761-NET-AIC occupies one node address, so the number of adaptors is limited by your total node budget.
Q: Is the 1761-NET-AIC compatible with SLC 5/05 processors?
A: The SLC 5/05 has a built-in Ethernet port and typically does not require the 1761-NET-AIC. However, it can be used to bridge the SLC 5/05’s RS-232 channel to a DH-485 network segment if required by the system architecture.
Q: What cable is required to connect the 1761-NET-AIC to a MicroLogix controller?
A: Use the 1761-CBL-PM02 (mini-DIN 8-pin to DB-9) or 1761-CBL-AP00 cable depending on your MicroLogix model’s communication port type.
Q: Does Konmask.com provide a warranty on this part?
A: Yes. All units carry a 90-day functional warranty. Extended warranty options are available — contact support@konmask.com for details.
