Allen-Bradley 1762-IF4 Analog Input Module – MicroLogix 1100/1200/1400 Expansion Series
When a MicroLogix controller loses its analog input capability, the consequences ripple immediately through the production floor: process variables go blind, PID loops open, and operators are left managing critical equipment by guesswork. Temperature drifts unchecked, flow rates exceed safe limits, and batch quality collapses — all because four analog channels went dark. The Allen-Bradley 1762-IF4 exists precisely to prevent this scenario, delivering reliable, high-resolution analog signal acquisition that keeps your control loop closed and your process in spec.
Within the MicroLogix 1762 I/O expansion family, the 1762-IF4 occupies the role of the workhorse analog front-end: four independently configurable current/voltage input channels that integrate directly into the MicroLogix 1100, 1200, and 1400 backplane without additional gateways or signal converters. Globally, this module has been deployed across tens of thousands of OEM machines and retrofit projects, making it one of the most field-proven analog expansion modules in the Rockwell Automation portfolio.
Technical Specifications
- Part Number: 1762-IF4
- Manufacturer: Allen-Bradley / Rockwell Automation
- Series: MicroLogix 1762 Expansion I/O
- Compatible Controllers: MicroLogix 1100, 1200, 1400
- Number of Input Channels: 4 (differential)
- Input Signal Ranges: 0–10 V DC, ±10 V DC, 0–20 mA, 4–20 mA (per channel, software-selectable)
- Resolution: 12-bit (0–4095 counts)
- Input Impedance (Voltage): ≥ 1 MΩ
- Input Impedance (Current): 250 Ω
- Conversion Time: Approximately 10 ms per channel
- Operating Temperature: 0 °C to +60 °C (32 °F to 140 °F)
- Storage Temperature: -40 °C to +85 °C
- Relative Humidity: 5–95% non-condensing
- Power Consumption: 75 mA @ 5 V DC (from controller backplane)
- Dimensions (H × W × D): 90 × 40 × 87 mm (approx.)
- Weight: 200 g (approx.)
- Certifications: UL, CE, C-Tick
- Enclosure Rating: Open type (panel-mount)
Key Features & Benefits
- 4 Independent Differential Analog Inputs — each channel configurable for voltage or current, eliminating the need for external signal conditioners in mixed-signal environments.
- 12-Bit Resolution — provides 4096 discrete levels per channel, sufficient for precise PID control, flow measurement, and temperature monitoring in most industrial processes.
- Software-Selectable Input Ranges — switch between 0–10 V, ±10 V, 0–20 mA, and 4–20 mA via RSLogix 500/Micro without hardware jumpers, reducing commissioning time.
- Direct Backplane Integration — snaps onto the MicroLogix 1762 expansion bus; no additional power supply or communication wiring required.
- Compact DIN-Rail Form Factor — 40 mm wide module fits into tight panel layouts alongside other 1762 I/O modules.
- Open-Circuit & Over-Range Detection — module flags out-of-range or broken-wire conditions in the input data file, enabling fault-tolerant ladder logic.
- RoHS Compliant — meets environmental directives for global export and installation.
Industry & Equipment Applications
- Food & Beverage: Temperature and pressure monitoring in pasteurization, mixing, and filling lines.
- Water & Wastewater: Flow transmitter and level sensor inputs for pump station control.
- HVAC & Building Automation: Duct pressure, CO₂, and humidity sensor integration.
- Oil & Gas: Wellhead pressure and flow measurement in remote RTU panels.
- Packaging Machinery: Tension control, web-guide feedback, and servo drive analog command signals.
- Chemical Processing: pH, conductivity, and dissolved oxygen transmitter inputs.
- Material Handling: Load cell and weigh-scale analog signal acquisition.
System Integration & Compatible Parts
The 1762-IF4 is designed to work within the Allen-Bradley MicroLogix 1762 expansion ecosystem. Common companion modules and accessories include:
- 1762-OW8 — 8-Point Relay Output Module
- 1762-IQ16 — 16-Point 24 V DC Sink/Source Input Module
- 1762-OB16 — 16-Point 24 V DC Source Output Module
- 1762-OF4 — 4-Point Analog Output Module (paired with IF4 for closed-loop control)
- 1762-IR4 — 4-Point RTD/Resistance Input Module
- 1761-CBL-PM02 — MicroLogix Programming Cable
- 1763-L16BWA / 1764-LRP — MicroLogix 1100 / 1200 CPUs
If you need help selecting compatible expansion modules or verifying firmware compatibility, contact our technical team at support@konmask.com.
Our Quality Assurance Process
Every 1762-IF4 unit shipped from Konmask.com passes through a documented inspection workflow:
- Visual Inspection: Housing, terminal blocks, and backplane connector checked for physical damage, corrosion, or missing components.
- Label & Marking Verification: Catalog number, series letter, and firmware revision confirmed against Rockwell Automation documentation.
- Authenticity Check: Holographic labels, PCB markings, and component profiles cross-referenced to identify counterfeit risk.
- Functional Test (where applicable): Surplus units are bench-tested for backplane communication and channel response prior to dispatch.
- Packaging: Anti-static bag + foam-lined carton with desiccant for international shipment.
How to Order
- Submit an inquiry via the “Get a Quote” button on this page, or email support@konmask.com.
- Provide your required quantity, delivery timeline, and destination country.
- Our team will respond within 1 business day with availability, lead time, and a formal quotation.
- Upon order confirmation, we arrange export documentation, packaging, and shipment via your preferred carrier (DHL, FedEx, UPS, or sea freight).
For urgent requirements or large-volume orders, call us directly at +0086 19859288691.
Why Choose Konmask.com?
- ✅ Specialized in Industrial Automation Components — PLC modules, DCS cards, drives, and HMI parts from leading global brands.
- ✅ New & Surplus Stock — factory-sealed new units and inspected surplus, clearly labeled so you know exactly what you’re buying.
- ✅ Global Export Experience — we ship to 60+ countries with full commercial invoice, packing list, and COO documentation.
- ✅ Technical Pre-Sales Support — our engineers help you confirm compatibility before you commit to a purchase.
- ✅ Responsive Communication — inquiries answered within 24 hours, Monday–Saturday.
Frequently Asked Questions
Q: Is the 1762-IF4 compatible with MicroLogix 1000?
A: No. The 1762-IF4 uses the 1762 expansion bus, which is only supported by MicroLogix 1100, 1200, and 1400 controllers. MicroLogix 1000 does not support 1762 expansion I/O.
Q: Can I mix voltage and current inputs on the same module?
A: Yes. Each of the four channels is independently configurable for voltage (0–10 V or ±10 V) or current (0–20 mA or 4–20 mA) via the RSLogix 500 channel configuration dialog.
Q: How many 1762-IF4 modules can I connect to one MicroLogix controller?
A: The maximum number of 1762 expansion modules per controller depends on the CPU model and total I/O point budget. MicroLogix 1400 supports up to 7 expansion modules. Consult publication 1762-UM001 for exact limits.
Q: Do you supply the module with a warranty?
A: New factory-sealed units carry the original manufacturer warranty. Surplus units are sold with Konmask.com’s 90-day inspection guarantee. Contact us for details.
Q: What programming software is required?
A: RSLogix 500 (version 7.0 or later) or RSLogix Micro is required to configure the 1762-IF4 channel parameters and map data to the controller’s input file.
Q: Can you provide an export certificate of origin?
A: Yes. We provide a Certificate of Origin (COO) for all international shipments upon request.
