Discrete Control & Mixed I/O Solution — Allen-Bradley 1762-IQ8OW6 | MicroLogix 1200 Series
Where This Product Is Used
The Allen-Bradley 1762-IQ8OW6 is a 14-point digital combination I/O module designed for the MicroLogix 1200 platform. It is deployed across a wide range of industrial automation environments where both discrete sensing and relay-switched outputs are required on a single compact module:
- Conveyor & Material Handling Systems — reading proximity sensors and switching motor contactors or solenoid valves
- Packaging Machinery — coordinating photoelectric sensor inputs with relay-driven actuators and reject gates
- HVAC & Building Automation — monitoring digital status inputs (door contacts, flow switches) and controlling fan relays or damper actuators
- Water & Wastewater Treatment — interfacing with level switches, float sensors, and pump relay outputs
- Food & Beverage Processing — managing wash-down-rated sensor inputs alongside relay outputs for agitators and conveyors
- Machine Tool & Press Control — reading limit switches and E-stop inputs while driving relay-controlled safety circuits
- OEM Panel Builders — standardizing on a single mixed I/O module to reduce wiring complexity and panel footprint
Technical Specifications
| Attribute | Value |
|---|---|
| Catalog Number | 1762-IQ8OW6 |
| Series / Platform | MicroLogix 1200 |
| Total I/O Points | 14 (8 Inputs + 6 Outputs) |
| Input Type | DC Sink/Source (24 VDC) |
| Input Voltage Range | 10–30 VDC |
| Input Current (per point) | 7 mA @ 24 VDC |
| Output Type | Relay (Form C) |
| Output Voltage Range | 5–265 VAC / 5–125 VDC |
| Output Current Rating | 2 A per point (resistive) |
| Backplane Current Draw | 75 mA @ 5 VDC |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Relative Humidity | 5–95% (non-condensing) |
| Module Weight | Approx. 250 g |
| Certifications | UL, CE, CSA |
| Mounting | MicroLogix 1200 expansion bus |
Why Engineers Specify This Model
- Mixed I/O in One Slot — eliminates the need for separate input and output modules, reducing panel space and BOM cost
- Relay Outputs for Voltage Flexibility — Form C relays switch both AC and DC loads without additional interface relays, simplifying wiring
- Sink/Source Input Compatibility — accepts both NPN and PNP sensors without rewiring, maximizing sensor sourcing flexibility
- Proven MicroLogix 1200 Ecosystem — seamless integration with 1762-series expansion bus; no additional configuration hardware required
- Robust Industrial Rating — rated for 0–60 °C ambient, suitable for most machine-side and panel-mount environments
- Long Product Lifecycle — Allen-Bradley MicroLogix 1200 remains widely supported with available spare parts and firmware
Complete System Bill of Materials
For a complete MicroLogix 1200 discrete control system using the 1762-IQ8OW6, engineers typically specify:
- 1762-L24BWA / 1762-L40BWA — MicroLogix 1200 base controller (24 or 40 I/O)
- 1762-IQ8OW6 — This module (14-point digital combo I/O expansion)
- 1762-OW16 — 16-point relay output expansion (if additional relay capacity needed)
- 1762-IQ16 — 16-point DC input expansion (for high-density sensor applications)
- 1761-CBL-PM02 — RS-232 programming cable for RSLogix 500 / Studio 5000 Logix Designer
- 1762-MM1 — Memory module for program backup and transfer
- 24 VDC DIN-rail power supply — 1606-XLP series or equivalent (2 A minimum recommended)
- 1492-CABLE series — Pre-wired I/O cables for rapid termination
Compliance & Industry Standards
- UL Listed — UL 508 (Industrial Control Equipment)
- CE Marked — EN 61131-2 (Programmable Controllers), EMC Directive 2014/30/EU
- CSA Certified — C22.2 No. 142 (Process Control Equipment)
- RoHS Compliant — Directive 2011/65/EU
- ATEX / IECEx — Not rated for hazardous locations; install in suitable enclosure per local code if required
Quality Assurance & Sourcing
At Konmask.com, every Allen-Bradley module is subject to a multi-point verification process before dispatch:
- Visual inspection for physical damage, label integrity, and connector condition
- Firmware version and catalog number cross-check against Rockwell Automation documentation
- Functional power-on test where applicable
- Anti-static packaging with humidity indicator card for long-distance shipment
- Traceability documentation available on request (batch records, test reports)
We source from authorized distributors, factory-surplus channels, and verified industrial resellers. Counterfeit-risk screening is applied to all Allen-Bradley catalog numbers.
How to Source This Part
- In-Stock Orders — Add to cart and complete checkout; most orders ship within 1–3 business days
- Bulk / Project Quotes — Email [email protected] with your BOM and required delivery date for a volume price
- Urgent / Emergency Orders — Call or WhatsApp +0086 19859288691 for same-day processing options
- International Shipping — We ship to most countries via DHL Express, FedEx, and UPS; duties and taxes are buyer’s responsibility unless otherwise agreed
- Lead Time for Out-of-Stock — Typical sourcing lead time is 5–15 business days; contact us to confirm availability before ordering
Application-Specific FAQ
Q: Can the 1762-IQ8OW6 be used with a MicroLogix 1100?
A: No. The 1762 expansion bus is exclusive to the MicroLogix 1200 and 1500 LRP/LXP controllers. It is not compatible with MicroLogix 1100 or 1000.
Q: How many 1762-IQ8OW6 modules can I add to one MicroLogix 1200 system?
A: The MicroLogix 1200 supports up to 6 expansion modules on the 1762 bus, subject to backplane current budget. Verify total current draw does not exceed the controller’s 5 VDC backplane supply rating.
Q: Are the relay outputs rated for inductive loads such as motor starters?
A: Yes, but derate accordingly. For inductive AC loads, the relay output is rated at 1.5 A; use a snubber circuit or MOV across the coil to extend relay contact life.
Q: What programming software is required?
A: RSLogix 500 (v7.0 or later) or RSLogix Micro. The module is auto-configured by the controller upon power-up; no separate I/O configuration file is needed.
Q: Is this module available as a factory-new or refurbished unit?
A: We stock both. Please specify your preference at checkout or in your inquiry. All units are tested and verified regardless of condition grade.
Q: Can you provide a certificate of conformance or test report?
A: Yes. Request documentation at the time of order or email [email protected] with your order number.
