Allen-Bradley 1769-OB32T 32-Point Transistor Output Module – 1769 Compact I/O Series
When a transistor output module fails mid-production, the consequences are immediate and costly: conveyor lines halt, robotic arms freeze, and safety interlocks trip — all because 32 discrete output channels can no longer drive solenoids, motor starters, or indicator circuits. In high-throughput manufacturing environments, every minute of unplanned downtime translates directly into scrapped batches, missed delivery windows, and escalating maintenance costs. The Allen-Bradley 1769-OB32T is the precision component that keeps those 32 channels alive, reliable, and responsive — making it one of the most operationally critical modules in any Compact I/O rack.
Within the 1769 Compact I/O family, the 1769-OB32T occupies a high-density output position, offering 32 sourcing transistor outputs in a single compact slot — a density that reduces rack footprint while maximizing I/O capacity. Globally, the 1769 Compact I/O platform is deployed across hundreds of thousands of MicroLogix and CompactLogix control systems in automotive, food & beverage, material handling, and process industries, making the 1769-OB32T one of the most widely specified discrete output modules in the Allen-Bradley ecosystem.
Technical Specifications
- Catalog Number: 1769-OB32T
- Series: 1769 Compact I/O
- Output Type: Sourcing (PNP) Transistor
- Number of Outputs: 32 points
- Output Voltage Range: 10–28.8V DC
- Output Current per Point: 0.5A maximum
- Total Module Current: 4A maximum (all outputs ON)
- Output Groups: 2 groups of 16 points
- Backplane Current Draw (5V DC): 120 mA
- Backplane Current Draw (24V DC): 0 mA
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C
- Relative Humidity: 5–95% non-condensing
- Dimensions (H × W × D): 118 × 35 × 87 mm (approx.)
- Weight: 400 g (approx.)
- Certifications: UL, CE, CSA (verify with current Rockwell documentation)
Key Features & Benefits
- High-Density 32-Point Output: Maximizes I/O capacity per slot, reducing overall rack size and wiring complexity in space-constrained panels.
- Sourcing (PNP) Transistor Outputs: Compatible with the majority of industrial sensors and actuators wired for sourcing logic, simplifying field device integration.
- Dual Output Groups: Two independently powered groups of 16 outputs allow zone-based power isolation for safety or maintenance without shutting down the entire module.
- Fast Switching Response: Transistor technology enables rapid on/off cycling suitable for high-speed conveyor control, pulse-width modulation, and time-critical sequencing.
- Compact I/O Plug-and-Play Architecture: Side-mount bus connector allows hot-swap-capable expansion without rewiring the backplane, minimizing maintenance downtime.
- Diagnostic LED Indicators: Per-point output status LEDs provide instant visual fault identification during commissioning and troubleshooting.
- Wide Operating Temperature Range: Rated for 0–60°C ambient, suitable for both climate-controlled control rooms and harsher factory-floor enclosures.
Industry & Equipment Applications
- Automotive Manufacturing: Body-in-white welding lines, paint shop conveyor control, assembly robot I/O expansion.
- Food & Beverage: Filling machine solenoid valve control, packaging line actuator sequencing, CIP system valve outputs.
- Material Handling & Logistics: Sortation conveyor diverter control, pallet transfer system outputs, warehouse AGV interface.
- Water & Wastewater Treatment: Pump station valve control, dosing system actuator outputs, SCADA-integrated process control.
- Pharmaceutical & Life Sciences: Cleanroom equipment control, batch process valve sequencing, GMP-compliant automation systems.
- Machine Tool & OEM Equipment: CNC auxiliary output control, spindle brake/clutch actuation, safety relay output interfacing.
System Integration & Compatible Parts
The 1769-OB32T integrates directly into any 1769 Compact I/O rack and is compatible with the following Allen-Bradley controllers and accessories:
- Compatible Controllers: MicroLogix 1500 (1764 series), CompactLogix L1x/L2x/L3x/L4x/L5x families
- Companion Input Modules: 1769-IQ32 (32-point 24VDC sink/source input), 1769-IQ16 (16-point input)
- Power Supplies: 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4
- End Caps: 1769-ECR (right end cap), 1769-ECL (left end cap)
- Communication Adapters: 1769-ADN (DeviceNet), 1769-SDN (DeviceNet scanner), EtherNet/IP via CompactLogix backplane
- Programming Software: RSLogix 500 (MicroLogix), Studio 5000 Logix Designer (CompactLogix)
Our Quality Assurance Process
At Konmask.com, every Allen-Bradley 1769-OB32T unit undergoes a structured verification process before shipment:
- Source Verification: Units are sourced from authorized distributors or verified surplus channels with full traceability documentation.
- Visual & Physical Inspection: Enclosure integrity, connector condition, label authenticity, and firmware revision labels are checked against Rockwell Automation reference standards.
- Functional Pre-Test: Where applicable, modules are bench-tested on a live 1769 rack to confirm output channel operation and backplane communication.
- Anti-Static Packaging: All modules are shipped in ESD-safe bags with foam cushioning inside double-wall cartons to prevent transit damage.
- Documentation Package: Each shipment includes a packing list, inspection record, and available datasheet or certificate of conformance upon request.
How to Order
- Submit an Inquiry: Use the contact form or email support@konmask.com with your required quantity, delivery timeline, and destination country.
- Receive a Quotation: Our technical sales team will respond within 1 business day with pricing, lead time, and shipping options.
- Confirm & Pay: Orders are confirmed upon receipt of a purchase order or advance payment via T/T, PayPal, or other agreed methods.
- Shipment & Tracking: We ship via DHL, FedEx, UPS, or sea freight depending on order size and urgency. Tracking numbers are provided upon dispatch.
- After-Sales Support: Our engineering team is available for installation guidance, compatibility questions, and warranty claims.
Why Choose Konmask.com?
- Industrial Automation Specialists: We focus exclusively on PLC, DCS, and automation hardware — not a generalist marketplace.
- Global B2B Supply: Serving system integrators, OEMs, and MRO buyers across Asia, Europe, the Middle East, and the Americas.
- Fast Inquiry Response: Dedicated technical sales team responds to RFQs within 1 business day.
- Competitive Pricing: Direct sourcing relationships allow us to offer market-competitive pricing on both new and surplus inventory.
- Reliable Logistics: Experienced in export documentation, customs compliance, and international freight for industrial components.
- Long-Term Partnership: We support your projects from initial BOM sourcing through ongoing MRO replenishment.
Frequently Asked Questions
Q: Is the 1769-OB32T compatible with CompactLogix L3x controllers?
A: Yes. The 1769-OB32T is fully compatible with all CompactLogix controllers that support the 1769 Compact I/O bus, including the L30E, L32E, L35E, and L35CR variants.
Q: What is the difference between 1769-OB32T and 1769-OB32?
A: The 1769-OB32T uses transistor (solid-state) outputs rated for 0.5A per point, while the 1769-OB32 is also a transistor output module but with different current ratings and group configurations. Always verify the exact catalog suffix against your application’s current and voltage requirements.
Q: Can I mix 1769-OB32T modules with relay output modules in the same rack?
A: Yes. The 1769 Compact I/O architecture allows mixing of different module types within the same rack, subject to total backplane power budget constraints.
Q: Do you supply modules with a warranty?
A: Yes. We offer a standard warranty period on all modules. Please contact us for specific warranty terms applicable to new versus surplus stock.
Q: Can you provide an export-ready invoice and packing list for customs clearance?
A: Yes. We routinely prepare commercial invoices, packing lists, and certificates of origin for international shipments. Contact us to discuss specific country requirements.
Q: What is the minimum order quantity (MOQ)?
A: We accept single-unit inquiries. There is no minimum order quantity for standard stock items.
