Allen-Bradley 2198-S160-ERS3 Single-Axis Servo Drive Module – Kinetix 5700 Series
When a servo axis goes offline on a high-speed packaging line, a robotic welding cell, or a precision CNC machining center, production does not simply slow down — it stops entirely. Every minute of unplanned downtime translates directly into scrapped product, missed delivery windows, and escalating maintenance costs. The Allen-Bradley 2198-S160-ERS3 is the single-axis servo drive module engineered to eliminate that risk, delivering the precise torque, speed, and position control that modern automated machinery demands without compromise.
Within the Kinetix 5700 servo drive family — Rockwell Automation’s flagship multi-axis motion platform — the 2198-S160-ERS3 occupies the high-power single-axis tier, rated at 160 A continuous output current. It is designed for demanding servo applications where a dedicated axis drive is required rather than a shared DC-bus multi-axis configuration. Globally, the Kinetix 5700 series is deployed across automotive assembly, semiconductor fabrication, food and beverage processing, and logistics automation, making the 2198-S160-ERS3 one of the most sought-after replacement and expansion modules in the industrial automation market.
Technical Specifications
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number / SKU: 2198-S160-ERS3
- Series: Kinetix 5700
- Drive Type: Single-Axis Servo Drive Module
- Continuous Output Current: 160 A
- Communication Interface: EtherNet/IP (ERS3 designation)
- DC Bus Architecture: Shared DC bus compatible within Kinetix 5700 system
- Controller Compatibility: Rockwell Automation ControlLogix / CompactLogix with Logix 5000 motion instructions
- Feedback Support: Multi-turn absolute encoder, single-turn absolute encoder, incremental encoder (motor-dependent)
- Safety: Integrated Safe Torque-Off (STO) — SIL 2 / PLd capable
- Mounting: Panel mount, DIN rail compatible within Kinetix 5700 system frame
- Weight: Approx. 200 g (module only)
- Compliance: CE, UL, cUL
Note: Specifications above are based on published Rockwell Automation documentation. Always verify against the official product bulletin (2198-UM002) for your specific application requirements.
Key Features & Benefits
- High-Current Single-Axis Architecture: 160 A continuous rating supports large-frame servo motors in heavy-duty applications without the complexity of multi-axis bus sharing.
- EtherNet/IP Connectivity (ERS3): Native EtherNet/IP integration enables seamless communication with Studio 5000 Logix Designer, supporting CIP Motion for deterministic, high-bandwidth motion control.
- Integrated Safe Torque-Off (STO): Hardware-level safety function meets SIL 2 / PLd requirements, reducing the need for external safety contactors and simplifying machine safety architecture.
- Shared DC Bus Compatibility: Operates within the Kinetix 5700 shared DC bus system, enabling regenerative energy sharing between axes and reducing overall power consumption.
- Plug-and-Play with Rockwell Ecosystem: Auto-configuration via Studio 5000 and Add-On Profiles (AOPs) dramatically reduces commissioning time.
- Compact, Modular Design: Standardized form factor integrates directly into existing Kinetix 5700 system frames, simplifying spare parts management and field replacement.
- Advanced Diagnostics: Real-time fault logging and predictive maintenance data accessible via Logix Designer and FactoryTalk software suite.
Industry & Equipment Applications
- Automotive Manufacturing: Robotic welding positioners, transfer press lines, engine assembly torque stations
- Packaging & Labeling: High-speed case packers, form-fill-seal machines, rotary indexing tables
- Semiconductor & Electronics: Wafer handling robots, PCB drilling and routing machines, pick-and-place systems
- Food & Beverage Processing: Servo-driven filling lines, slicing and portioning equipment, conveyor synchronization
- Logistics & Warehousing: Automated storage and retrieval systems (AS/RS), sortation conveyors, palletizing robots
- CNC Machining: Multi-axis machining centers requiring high-torque, high-precision axis control
- Printing & Converting: Web tension control, register control, die-cutting servo axes
System Integration & Compatible Parts
The 2198-S160-ERS3 is designed to operate within the broader Rockwell Automation Kinetix 5700 ecosystem. Typical compatible components include:
- DC Bus Power Supply: 2198-Pxxx series (e.g., 2198-P031, 2198-P070, 2198-P141)
- Regenerative Bus Supply: 2198-RPxxx series for energy recovery applications
- Servo Motors: Allen-Bradley MPL, MPM, MPAR, MPAS series (ERS3-compatible feedback)
- Controllers: ControlLogix 5580 (1756-L8x), CompactLogix 5380 (5069-L3x)
- Communication Modules: 1756-EN2T, 1756-EN3TR for EtherNet/IP network infrastructure
- Cables & Connectors: 2090-series motor power and feedback cables
Contact our technical team at support@konmask.com for system compatibility verification before ordering.
