Allen-Bradley 2711P-RDT12C4D9 – 12.1″ TFT Touch Screen HMI Display | PanelView Plus 7 Standard Platform
The Allen-Bradley 2711P-RDT12C4D9 is a high-performance human-machine interface (HMI) display terminal from Rockwell Automation’s PanelView Plus 7 Standard series. Designed for demanding industrial environments, this 12.1-inch widescreen TFT touch panel delivers precise operator control, real-time visualization, and seamless integration with Allen-Bradley PLCs and ControlLogix/CompactLogix architectures.
Procurement engineers and system integrators worldwide rely on the 2711P-RDT12C4D9 for its proven reliability in continuous-duty automation applications, its native EtherNet/IP connectivity, and its compatibility with Studio 5000 / FactoryTalk View ME software ecosystems.
Complete Technical Specifications
- Part Number: 2711P-RDT12C4D9
- Series: PanelView Plus 7 Standard
- Manufacturer: Allen-Bradley / Rockwell Automation
- Display Size: 12.1 inch (diagonal) widescreen TFT LCD
- Resolution: 1024 × 768 (XGA)
- Touch Technology: Analog resistive touch screen
- Color Depth: 65,536 colors (16-bit)
- Backlight: LED backlight, rated 50,000 hours MTBF
- Communication: EtherNet/IP (dual-port switch), USB Host × 2, USB Device × 1
- Processor: 1 GHz ARM-based processor
- Memory: 512 MB RAM / 512 MB Flash storage
- Operating System: Windows Embedded Compact 7
- Software: FactoryTalk View ME (pre-installed runtime)
- Input Voltage: 24V DC (18–32V DC operating range)
- Power Consumption: 30W typical
- Operating Temperature: 0°C to +55°C (32°F to 131°F)
- Storage Temperature: -20°C to +70°C
- Humidity: 5% to 95% RH (non-condensing)
- Protection Rating: NEMA 4/4X, 12, 13; IP65 (front panel)
- Vibration: IEC 60068-2-6 compliant
- Shock: IEC 60068-2-27 compliant
- Certifications: UL Listed, CE Marked, cUL, RCM
- Mounting: Panel cutout mount, landscape orientation
- Dimensions (HxWxD): 248 × 330 × 57 mm (approx.)
- Weight: 2.29 kg
- HS Code: 8537.10
Proven Application Environments
- Automotive Manufacturing: Assembly line control, robotic cell HMI, torque monitoring stations
- Food & Beverage: Washdown-rated panel installations, batch process visualization, CIP cycle control
- Oil & Gas: Wellhead control panels, compressor station monitoring, SCADA front-end terminals
- Water & Wastewater: Pump station control, filtration process HMI, remote lift station displays
- Pharmaceutical: GMP-compliant process visualization, clean room panel integration
- Material Handling: Conveyor system control, sortation line HMI, warehouse automation
- Power Generation: Switchgear control panels, generator set monitoring, substation HMI
Engineering Advantages
- Native EtherNet/IP Integration: Dual-port embedded switch enables daisy-chain topology without external switches, reducing panel wiring complexity.
- FactoryTalk View ME Ecosystem: Full compatibility with Studio 5000 Logix Designer and FactoryTalk View Studio for unified engineering workflow.
- IP65 Front Panel Sealing: NEMA 4/4X rating ensures reliable operation in washdown and high-humidity environments without additional enclosure protection.
- LED Backlight Longevity: 50,000-hour rated LED backlight minimizes planned maintenance intervals and reduces lifecycle cost.
- Scalable Platform: Shares application files across PanelView Plus 7 family (6.5″ to 15″), enabling modular HMI architecture upgrades.
- Alarm & Diagnostics: Built-in FactoryTalk Alarms and Events support with historical logging to USB or network share.
- Multi-language Support: Runtime language switching supports global deployment without application re-download.
System Architecture & Signal Flow
The 2711P-RDT12C4D9 operates as a display-only terminal (no integrated logic controller), communicating upstream via EtherNet/IP to Allen-Bradley ControlLogix (1756), CompactLogix (1769), or MicroLogix PLCs. The dual-port Ethernet switch allows the HMI to sit inline on the device-level ring (DLR) or linear EtherNet/IP network without consuming an additional switch port.
Tag-based communication maps PLC controller tags directly to HMI display objects via FactoryTalk View ME tag database, supporting both online (live PLC) and offline (simulation) modes. USB Host ports support application transfer, data logging to USB drives, and peripheral device connection (barcode scanners, printers).
Sourcing & Quality Verification
- All units sourced through verified industrial automation supply channels with full traceability documentation.
- Pre-shipment inspection includes: power-on functional test, display uniformity check, touch calibration verification, and communication port validation.
- Firmware version confirmed and documented prior to dispatch.
- Original manufacturer packaging preserved where available; anti-static packaging applied for all shipments.
- Counterfeit risk mitigation: serial number verification against Rockwell Automation authenticity guidelines.
Procurement Process
- Inquiry: Submit your project requirements and quantity via support@konmask.com or +0086 19859288691.
- Quotation: Receive a formal quotation with lead time, unit price, and shipping options within 24 hours.
- Order Confirmation: Purchase order accepted; payment terms confirmed (T/T, L/C, or platform checkout).
- Quality Inspection: Pre-shipment functional test performed and inspection report issued.
- Shipping: DHL / FedEx / UPS express or sea freight; tracking number provided same day as dispatch.
- After-Sales: 12-month warranty; technical support available for integration and commissioning queries.
Technical FAQ
Q: Is the 2711P-RDT12C4D9 compatible with RSView32 applications?
A: No. RSView32 applications require conversion to FactoryTalk View ME format using the ME Transfer Utility before deployment on PanelView Plus 7 terminals.
Q: Can this panel communicate with third-party PLCs (Siemens, Mitsubishi)?
A: Natively, the panel supports Allen-Bradley protocols (EtherNet/IP, DF1). Third-party PLC communication requires a protocol gateway or OPC server middleware.
Q: What is the difference between 2711P-RDT12C4D9 and 2711P-T12C4D9?
A: The “RDT” suffix denotes a display-only terminal (no keypad), while “T” variants include function keys. Both share the same 12.1″ display and processing hardware.
Q: Is a FactoryTalk View ME license included?
A: The runtime license is embedded in the terminal firmware. A separate FactoryTalk View Studio development license is required for application creation on an engineering workstation.
Q: What is the recommended replacement for end-of-life PanelView Plus 6 units?
A: The PanelView Plus 7 Standard series (including 2711P-RDT12C4D9) is the direct migration path. Existing ME applications are compatible with minimal modification.
